System Description
CAN (Controller Area Network) is a serial communication line for real time application. It is an on-vehicle multiplex communication line with high data communication speed and excellent error detection ability. Many electronic control units are equipped onto a vehicle, and each control unit shares information and links with other control units during operation (not independent). In CAN communication, control units are connected with 2 communication lines (CAN H line, CAN L line) allowing a high rate of information transmission with less wiring. Each control unit transmits/receives data but selectively reads required data only.
Scheme 351
Scheme 352
Scheme 353
Scheme 354
Scheme 355
Scheme 356
Scheme 357
Scheme 358
- When there are no indications of "AIR PRESSURE MONITOR", "INTELLIGENT KEY", "BCM", "METER A/C AMP", "AUTO DRIVE POS." or "IPDM E/R" on "SELECT SYSTEM" display of CONSULT-II, print the "SELECT SYSTEM".
- Print all the data of "SELF-DIAG RESULTS" for "ENGINE", "A/T", "AIR PRESSURE MONITOR", "ALL MODE 4WD", "ICC", "INTELLIGENT KEY", "BCM", "METER A/C AMP", "ABS", "AUTO DRIVE POS.", and "IPDM E/R" displayed on CONSULT-II.
- Print all the data of "DATA MONITOR (CAN DIAG SUPPORT MNTR)" for "ENGINE", "A/T", "AIR PRESSURE MONITOR", "ALL MODE 4WD", "ICC", "INTELLIGENT KEY", "BCM", "METER A/C AMP", "ABS", "AUTO DRIVE POS.", and "IPDM E/R" displayed on CONSULT-II.
- Attach the printed sheet of "SELECT SYSTEM", "SELF-DIAG RESULTS" and "DATA MONITOR (CAN DIAG SUPPORT MNTR)" onto the check sheet. Refer to " «CHECK SHEET»(ref-179066-S02061168362005062900000) ".
- Based on the indications of "SELECT SYSTEM" and the results of "DATA MONITOR (CAN DIAG SUPPORT MNTR)", put marks "v" onto the items with "No indication", "NG", or "UNKWN" in the check sheet table. Refer to " «CHECK SHEET»(ref-179066-S02061168362005062900000) ". NOTE: If "NG" is displayed on "CAN COMM" as "DATA MONITOR (CAN DIAG SUPPORT MNTR)" for the diagnosed control unit, replace the control unit. The "DATA MONITOR (CAN DIAG SUPPORT MNTR)" items, which are not in check sheet table, are not related to diagnostic procedure on service manual. So it is not necessary to check the status of "DATA MONITOR (CAN DIAG SUPPORT MNTR)" items which are not indicated in check sheet table.
- Check CAN communication line of the navigation system. Refer to «CAN COMMUNICATION LINE CHECK»(ref-179100-S17695046392005063000000) .
- Attach the CAN DIAG SUPPORT MONITOR check sheet onto the check sheet. Refer to " «CHECK SHEET»(ref-179066-S02061168362005062900000) ".
- Mark the "NG" or "UNKWN" item of the check sheet table with "v" from the result of CAN DIAG SUPPORT MONITOR check sheet. Refer to " «CHECK SHEET»(ref-179066-S02061168362005062900000) ". NOTE: If "NG" is displayed on "CAN COMM" as "CAN DIAG SUPPORT MONITOR" for the diagnosed control unit, replace the control unit. Refer to «CAN COMMUNICATION LINE CHECK»(ref-179100-S17695046392005063000000)
- According to the check sheet results (example), start inspection. Refer to " «CHECK SHEET RESULTS (EXAMPLE)»(ref-179066-S34685781162005062900000) ".
