CAN System (Type 3): Overview Infiniti FX45 I

Communication Devices 31 illustrations ~498 words

SYSTEM DESCRIPTION

CAN (Controller Area Network) is a serial communication line for real time application. It is an on-vehicle multiplex communication line with high data communication speed and excellent error detection ability. Many electronic control units are equipped onto a vehicle, and each control unit shares information and links with other control units during operation (not independent). In CAN communication, control units are connected with 2 communication lines (CAN H line, CAN L line) allowing a high rate of information transmission with less wiring. Each control unit transmits/receives data but selectively reads required data only.

Scheme 141

Scheme 141: COMPONENT PARTS AND HARNESS CONNECTOR LOCATION

Scheme 142

Scheme 142: SCHEMATIC

Scheme 143

Scheme 143: WIRING DIAGRAM - CAN

Scheme 144

Scheme 144

Scheme 145

Scheme 145

Scheme 146

Scheme 146: WORK FLOW

Scheme 147

Scheme 147

Scheme 148

Scheme 148
  1. When there are no indications of AIR PRESSURE MONITOR, INTELLIGENT KEY, BCM, METER A/C AMP, AUTO DRIVE POS or IPDM E/R on SELECT SYSTEM display of CONSULT-II, print the SELECT SYSTEM.
  2. Print all the data of SELF-DIAG RESULTS for ENGINE, A/T, AIR PRESSURE MONITOR, ICC, INTELLIGENT KEY, BCM, METER A/C AMP, ABS, AUTO DRIVE POS, and IPDM E/R displayed on CONSULT-II.
  3. Print all the data of DATA MONITOR (CAN DIAG SUPPORT MNTR) for ENGINE, A/T, AIR PRESSURE MONITOR, ICC, INTELLIGENT KEY, BCM, METER A/C AMP, ABS, AUTO DRIVE POS, and IPDM E/R displayed on CONSULT-II.
  4. Attach the printed sheet of SELECT SYSTEM, SELF-DIAG RESULTS and DATA MONITOR (CAN DIAG SUPPORT MNTR) onto the check sheet. Refer to «CHECK SHEET»(ref-179063-S19947149282005062900000) .
  5. Based on the indications of SELECT SYSTEM and the results of DATA MONITOR (CAN DIAG SUPPORT MNTR), put marks V onto the items with No indication, NG, or UNKWN in the check sheet table. Refer to «CHECK SHEET»(ref-179063-S19947149282005062900000) . NOTE: If NG is displayed on CAN COMM as DATA MONITOR (CAN DIAG SUPPORT MNTR) for the diagnosed control unit, replace the control unit. The DATA MONITOR (CAN DIAG SUPPORT MNTR) items, which are not in check sheet table, are not related to diagnostic procedure on service manual. So it is not necessary to check the status of DATA MONITOR (CAN DIAG SUPPORT MNTR) items which are not indicated in check sheet table.
  6. Check CAN communication line of the navigation system. Refer to «CAN COMMUNICATION LINE CHECK»(ref-179100-S17695046392005063000000) .
  7. Attach the CAN DIAG SUPPORT MONITOR check sheet onto the check sheet. Refer to «CHECK SHEET»(ref-179063-S19947149282005062900000) .
  8. Mark the NG or UNKWN item of the check sheet table with V from the result of CAN DIAG SUPPORT MONITOR check sheet. Refer to «CHECK SHEET»(ref-179063-S19947149282005062900000) NOTE: If NG is displayed on CAN COMM as CAN DIAG SUPPORT MONITOR for the diagnosed control unit, replace the control unit. Refer to «CAN COMMUNICATION LINE CHECK»(ref-179100-S17695046392005063000000) .
  9. According to the check sheet results (example), start inspection. Refer to «CHECK SHEET RESULTS (EXAMPLE)»(ref-179063-S35119583782005062900000) .

Scheme 149

Scheme 149: Check Sheet

Scheme 150

Scheme 150

Scheme 151

Scheme 151

Scheme 152

Scheme 152: Check Sheet Results (Example)
