CAN System (Type 1): Overview Infiniti FX45 I

Communication Devices 15 illustrations ~425 words

SYSTEM DESCRIPTION

CAN (Controller Area Network) is a serial communication line for real time application. It is an on-vehicle multiplex communication line with high data communication speed and excellent error detection ability. Many electronic control units are equipped onto a vehicle, and each control unit shares information and links with other control units during operation (not independent). In CAN communication, control units are connected with 2 communication lines (CAN H line, CAN L line) allowing a high rate of information transmission with less wiring. Each control unit transmits/receives data but selectively reads required data only.

Scheme 26

Scheme 26: COMPONENT PARTS AND HARNESS CONNECTOR LOCATION

Scheme 27

Scheme 27: WIRING DIAGRAM - CAN

Scheme 28

Scheme 28

Scheme 29

Scheme 29: WORK FLOW

Scheme 30

Scheme 30

Scheme 31

Scheme 31
  1. When there are no indications of BCM, METER A/C AMP or IPDM E/R on SELECT SYSTEM display of CONSULT-II, print the SELECT SYSTEM.
  2. Print all the data of SELF-DIAG RESULTS for ENGINE, A/T, BCM, METER A/C AMP, ABS, and IPDM E/R displayed on CONSULT-II.
  3. Print all the data of DATA MONITOR (CAN DIAG SUPPORT MNTR) for ENGINE, A/T, BCM, METER A/C AMP, ABS, and IPDM E/R displayed on CONSULT-II.
  4. Attach the printed sheet of SELECT SYSTEM, SELF-DIAG RESULTS and DATA MONITOR (CAN DIAG SUPPORT MNTR) onto the check sheet. Refer to «CHECK SHEET»(ref-179061-S24723931222005062900000) .
  5. Based on the indications of SELECT SYSTEM and the results of DATA MONITOR (CAN DIAG SUPPORT MNTR), put marks V onto the items with No indication, NG, or UNKWN in the check sheet table. Refer to «CHECK SHEET»(ref-179061-S24723931222005062900000) . NOTE: If NG is displayed on CAN COMM as DATA MONITOR (CAN DIAG SUPPORT MNTR) for the diagnosed control unit, replace the control unit. The DATA MONITOR (CAN DIAG SUPPORT MNTR) items, which are not in check sheet table, are not related to diagnostic procedure on service manual. So it is not necessary to check the status of DATA MONITOR (CAN DIAG SUPPORT MNTR) items which are not indicated in check sheet table.
  6. Check CAN communication line of the integrated display system.
  7. Attach the CAN DIAG MONITOR check sheet onto the check sheet. Refer to «CHECK SHEET»(ref-179061-S24723931222005062900000) .
  8. Mark the NG or UNKWN item of the check sheet table with v from the result of CAN DIAG MONITOR check sheet. Refer to «CHECK SHEET»(ref-179061-S24723931222005062900000) . NOTE: If NG is displayed on CAN COMM as CAN DIAG MNTR for the diagnosed control unit, replace the control unit.
  9. According to the check sheet results (example), start inspection. Refer to «CHECK SHEET RESULTS (EXAMPLE)»(ref-179061-S20066605002005062900000) .

Scheme 32

Scheme 32: Check Sheet

Scheme 33

Scheme 33

Scheme 34

Scheme 34: Check Sheet Results (Example)

Scheme 35

Scheme 35

Scheme 36

Scheme 36

Scheme 37

Scheme 37

Scheme 38

Scheme 38

Scheme 39

Scheme 39

Scheme 40

Scheme 40
