CAN System (Type 5): Overview Infiniti FX45 I

Communication Devices 22 illustrations ~468 words

SYSTEM DESCRIPTION

CAN (Controller Area Network) is a serial communication line for real time application. It is an on-vehicle multiplex communication line with high data communication speed and excellent error detection ability. Many electronic control units are equipped onto a vehicle, and each control unit shares information and links with other control units during operation (not independent). In CAN communication, control units are connected with 2 communication lines (CAN H line, CAN L line) allowing a high rate of information transmission with less wiring. Each control unit transmits/receives data but selectively reads required data only.

Scheme 283

Scheme 283: COMPONENT PARTS AND HARNESS CONNECTOR LOCATION

Scheme 284

Scheme 284: SCHEMATIC

Scheme 285

Scheme 285: WIRING DIAGRAM - CAN

Scheme 286

Scheme 286

Scheme 287

Scheme 287

Scheme 288

Scheme 288: WORK FLOW

Scheme 289

Scheme 289

Scheme 290

Scheme 290
  1. When there are no indications of "BCM", "METER A/C AMP", "AUTO DRIVE POS." or "IPDM E/R" on "SELECT SYSTEM" display of CONSULT-II, print the "SELECT SYSTEM".
  2. Print all the data of "SELF-DIAG RESULTS" for "ENGINE", "A/T", "ALL MODE 4WD", "BCM", "METER A/C AMP", "ABS", "AUTO DRIVE POS.", and "IPDM E/R" displayed on CONSULT-II.
  3. Print all the data of "DATA MONITOR (CAN DIAG SUPPORT MNTR)" for "ENGINE", "A/T", "ALL MODE 4WD", "BCM", "METER A/C AMP", "ABS", "AUTO DRIVE POS.", and "IPDM E/R" displayed on CONSULT-II.
  4. Attach the printed sheet of "SELECT SYSTEM", "SELF-DIAG RESULTS" and "DATA MONITOR (CAN DIAG SUPPORT MNTR)" onto the check sheet. Refer to " «CHECK SHEET»(ref-179065-S12533657912005062900000) ".
  5. Based on the indications of "SELECT SYSTEM" and the results of "DATA MONITOR (CAN DIAG SUPPORT MNTR)", put marks "v" onto the items with "No indication", "NG", or "UNKWN" in the check sheet table. Refer to " «CHECK SHEET»(ref-179065-S12533657912005062900000) ". NOTE: If "NG" is displayed on "CAN COMM" as "DATA MONITOR (CAN DIAG SUPPORT MNTR)" for the diagnosed control unit, replace the control unit. The "DATA MONITOR (CAN DIAG SUPPORT MNTR)" items, which are not in check sheet table, are not related to diagnostic procedure on service manual. So it is not necessary to check the status of "DATA MONITOR (CAN DIAG SUPPORT MNTR)" items which are not indicated in check sheet table.
  6. Check CAN communication line of the integrated display system. Refer to «CAN COMMUNICATION»(ref-179060) .
  7. Attach the CAN DIAG MONITOR check sheet onto the check sheet. Refer to «CHECK SHEET»(ref-179065-S12533657912005062900000) .
  8. Mark the "NG" or "UNKWN" item of the check sheet table with V from the result of CAN DIAG MONITOR check sheet. Refer to " «CHECK SHEET»(ref-179065-S12533657912005062900000) ". NOTE: If "NG" is displayed on "CAN COMM" as "CAN DIAG MNTR" for the diagnosed control unit, replace the control unit. Refer to «CAN COMMUNICATION»(ref-179060) .
  9. According to the check sheet results (example), start inspection. Refer to " «CHECK SHEET RESULTS (EXAMPLE)»(ref-179065-S33881505212005062900000) ".

Scheme 291

Scheme 291: CHECK SHEET

Scheme 292

Scheme 292

Scheme 293

Scheme 293: CHECK SHEET RESULTS (EXAMPLE)

Scheme 294

Scheme 294

Scheme 295

Scheme 295

Scheme 296

Scheme 296

Scheme 297

Scheme 297

Scheme 298

Scheme 298

Scheme 299

Scheme 299

Scheme 300

Scheme 300

Scheme 301

Scheme 301

Scheme 302

Scheme 302

Scheme 303

Scheme 303

Scheme 304

Scheme 304
