Specification
| Throttle angle(°) | Output Voltage (V) |
| TPS1 | TPS2 |
| 0 | 0.50 | 4.50 |
| 10 | 0.96 | 4.05 |
| 20 | 1.41 | 3.59 |
| 30 | 1.87 | 3.14 |
| 40 | 2.32 | 2.68 |
| 50 | 2.78 | 2.23 |
| 60 | 3.23 | 1.77 |
| 70 | 3.69 | 1.32 |
| 80 | 4.14 | 0.86 |
| 90 | 4.60 | 0.41 |
| 98 | 4.65 | 0.35 |
| C.T (0) | 0.50 | 4.50 |
| W.O.T (86) | 4.41 | 0.59 |
VOLTAGE SPECIFICATION - THROTTLE POSITION SENSOR
Scheme 197
| Item | Specification |
| Coil Resistance (ohms) | 0.3 ~100 [20°C (68°F)] |
PART SPECIFICATION - ETC MOTOR
Scheme 198
Scheme 199
Specifications
| Pressure [kPa (kgf/cm 2 , psi)] | Output Voltage (V) |
| 32.5 (0.33, 4.71) | 0.5 |
| 284 (2.90, 41.19) | 4.5 |
Scheme 200
Scheme 201
Scheme 201: Signal Waveform
Scheme 202
Scheme 203
| Temperature | Resistance (kohms) |
| °C | °F |
| 40 | 40 | 40.93 ~ 48.35 |
| 20 | 4 | 13.89 ~ 16.03 |
| 0 | 32 | 5.38 ~ 6.09 |
| 10 | 50 | 3.48 ~ 3.90 |
| 20 | 68 | 2.31 ~ 2.57 |
| 40 | 104 | 1.08 ~ 1.21 |
| 50 | 122 | 1.56 ~ 1.74 |
| 60 | 140 | 0.54 ~ 0.62 |
| 80 | 176 | 0.29 ~ 0.34 |
Scheme 204
Scheme 205
Scheme 206
| Temperature [°C (°F)] | Resistance (kohms) |
| 40(-40) | 841.2~1019.3 |
| 20(-4) | 263.8~306.5 |
| 0(32) | 92.4~102.8 |
| 10(50) | 57.0~62.2 |
| 20(68) | 36.2~38.8 |
| 40(104) | 15.3~16.7 |
| 50(122) | 10.3~11.4 |
| 60(140) | 7.1~8.0 |
| 80(176) | 3.5~4.0 |
Scheme 207
Scheme 208
| Pressure [kPa (kg/cm 2 /psi)] | Resistance (kohms) |
| 32.5 (0.33, 4.71) | 0.5 |
| 284 (2.90, 41.19) | 4.5 |
Scheme 209
Scheme 210
| Temperature | Resistance (kohms) |
| °C | °F |
| 40 | 40 | 48.14 |
| 20 | 4 | 14.13 ~ 16.83 |
| 0 | 32 | 5.79 |
| 20 | 68 | 2.31 ~ 2.59 |
| 40 | 104 | 1.15 |
| 60 | 140 | 0.59 |
| 80 | 176 | 0.32 |
Scheme 211
Scheme 212
| Item | Specification |
| Coil Resistance (ohms) | 774 ~ 946 [20°C (68°F)] |
Scheme 213
Scheme 214
This example shows a typical Crankshaft Position Sensor (CKPS) and Camshaft Position Sensor (CMPS) waveform at idle. The PCM controls the injection and ignition timing by using these signals.
Generally CKPS signal is used to detect the piston's position and CMPS signal is used to detect the Top Dead Center of each cylinder.
Scheme 215
Scheme 216
| Item | Specification |
| Resistance (Mohms) | 4.87 |
Scheme 217
Scheme 218
Scheme 219
- Turn the ignition switch OFF and disconnect the battery negative (-) cable.
- Remove the intake manifold (Refer to «INTAKE MANIFOLD»(/hyundai/veloster/i-2011-2015/remont/blowers-superchargers-turbochargers/#intake-system-exhaust-system-turbo) ).
- Disconnect the Knock Sensor (A).
- Remove the installation bolt (B), and then remove the sensor from the cylinder block.
| Item | Specification |
| Heater Resistance (ohms) | 2.4 ~ 4.0 [20°C (68°F)] |
PART SPECIFICATION - HO2S (BANK 1/SENSOR 1) LINEAR TYPE
| Item | Specification |
| Heater Resistance (ohms) | Approx. 9.0 [20°C (68°F)] |
| A/F Ratio (lambda) | Output Voltage (V) |
| RICH | 0.6 ~ 1.0 |
| LEAN | 0 ~ 0.4 |
PART SPECIFICATION - HO2S (BANK 1/SENSOR 2) BINARY TYPE
| Item | Specification |
| Heater Resistance (ohms) | Approx. 9.0 [20°C (68°F)] |
Scheme 220
Scheme 221
| Accelerator Position | Output Voltage (V) |
| APS1 | APS2 |
| C.T | 0.7 ~ 0.8 | 0.29 ~ 0.46 |
| W.O.T | 3.85 ~ 4.35 | 1.93 ~ 2.18 |
Scheme 222
Scheme 223
Scheme 224
| Item | Specification |
| Coil Resistance (ohms) | 1.5 ± 0.075 [20°C (68°F)] |
| Item | Specification |
| Coil Resistance (ohms) | 22.0 ~ 26.0 [20°C (68°F)] |
Scheme 225
Scheme 226
| Item | Specification |
| Coil Resistance (ohms) | 6.9 ~ 7.9 [20°C (68°F)] |
Scheme 227
Scheme 228
| Item | Specification |
| Coil Resistance (ohms) | 28.3 ~ 31.1 [20°C (68°F)] |
Scheme 229
Scheme 230
| Item | Specification |
| Coil Resistance(ohms) | 28.3 ~ 31.1 [20°C (68°F)] |
Scheme 231
Scheme 232
| Item | Specification |
| Coil Resistance (ohms) | 0.5 [20°C (68°F) |
Scheme 233
Scheme 233: Signal Waveform
Scheme 234
Scheme 235
| Item | Specification |
| Coil Resistance (ohms) | 19.5 ~ 22.5 [20°C (68°F)] |
Scheme 236
Scheme 237
