Hybrid Motor Control System - Hev: Specifications Hyundai Sonata VI

Engine Control Systems 4 illustrations

Specification

[HYBRID DRIVE MOTOR]

ItemResistance (ohms)
Pin 1-210.5~12.8 (20~30°C)
Pin 4-628.8~35.2 (20~30°C)
Pin 1-724.3~29.7 (20~30°C)

HYBRID DRIVE MOTOR RESISTANCE CHART

[HSG]

ItemResistance (ohms)
Pin 1-614.2~17.4 (20~30°C)
Pin 2-721.6~32.0 (20~30°C)
Pin 3-826.1~32.0 (20~30°C)

RESISTANCE CHART (HSG)

Scheme 68

Scheme 68: Resolver Sensor (Hybrid Drive Motor)
Scheme 68: Resolver Sensor (Hybrid Drive Motor)

Scheme 69

Scheme 69: Resolver Sensor (HSG)
Scheme 69: Resolver Sensor (HSG)

[Hybrid Drive Motor]

ItemResistance (kohms)
Pin 9-10120.4 ~ 133.1 (20~30°C)

RESISTANCE SPECIFICATIONS

[HSG]

ItemResistance (kohms)
Pin 4-9120.4 ~ 133.1 (20~30°C)

RESISTANCE CHART (HSG)

Scheme 70

Scheme 70: Motor Temperature Sensor (Hybrid Drive Motor)
Scheme 70: Motor Temperature Sensor (Hybrid Drive Motor)

Scheme 71

Scheme 71: Motor Temperature Sensor (HSG)
Scheme 71: Motor Temperature Sensor (HSG)
