Hybrid Control System - Hev: Adjustments Hyundai Sonata VI

Adjustment

1. Refer to " «BRAKE SYSTEM»(ref-419444) " .

Clutch Pressure Sensor Calibration

Note. HCU need to be learnt the kissing point at both ends of the clutch to reduce shock while engine power is connected to the transaxle. So perform the Clutch Pressure Sensor Calibration after installing the CPS, HCU, engine or hybrid drive motor.

[Condition]

Scheme 20

Scheme 21

Scheme 22

1. Hybrid Motor and HSG Resolver Calibration: "Completed" state
2. "READY" Lamp ON
3. "P" Range
4. Oil Temperature: 30 ~ 80°C (86 ~ 176°F)
5. SOC: 30 ~ 80%
6. No DTC
