Automatic Transaxle System (F4A42): Wiring — Hyundai Sonata V рестайлинг (2007-2010)

Automatic Transaxle System (F4A42): Wiring Hyundai Sonata V рестайлинг

Automatic Trans 5 illustrations ~608 words

SCHEMATIC DIAGRAM

Refer to DTC P0707 .

Refer to DTC P0711 .

Refer to DTC P0717 .

Refer to DTC P0731 .

Refer to DTC P0741 .

Scheme 232: MONITOR SCANTOOL DATA

Connect scantool to data link connector (DLC)
Engine "ON".
Monitor the "TCC SOL. VALVE" parameter on the scantool
Select "D RANGE" and Operate "TCC SOLENOID DUTY" more than 85%
Does "TCC SOLENOID DUTY" follow the reference data? YES Fault is intermittent caused by poor contact in the sensor's and/or TCM (PCM)'s connector or was repaired and TCM (PCM) memory was not cleared. Thoroughly check connectors for looseness, poor connection, bending, corrosion, contamination, deterioration or damage. Repair or replace as necessary and go to " «VERIFICATION OF VEHICLE REPAIR»(ref-286597-S13045283032008060300000) " procedure. NO Go to " «TERMINAL & CONNECTOR INSPECTION»(ref-286597-S16660237852008060300000) " procedure.

Refer to DTC P0741 .

Scheme 233: MONITOR SCANTOOL DATA

Connect scantool to data link connector (DLC).
Engine "ON".
Monitor the "LR SOL. VALVE" parameter on the scantool.
Shift gear position 1st to 2nd. Specification : 1st --> 0%, 2nd --> 100%
Does "LR SOLENOID DUTY" follow the reference data? YES Fault is intermittent caused by poor contact in the sensor's and/or TCM (PCM)'s connector or was repaired and TCM (PCM) memory was not cleared. Thoroughly check connectors for looseness, poor connection, bending, corrosion, contamination, deterioration or damage. Repair or replace as necessary and go to " «VERIFICATION OF VEHICLE REPAIR»(ref-286597-S02449386822008060300000) " procedure. NO Go to " «TERMINAL & CONNECTOR INSPECTION»(ref-286597-S41910553632008060300000) " procedure.

Refer to DTC P0741 .

Scheme 234: MONITOR SCANTOOL DATA

Connect scantool to data link connector (DLC)
Engine "ON".
Monitor the "UD SOL. VALVE" parameter on the scantool.
Shift gear position "N" to "D". Specification : P/N --> 100%, D --> 0.0%
Does "UD SOLENOID DUTY" follow the reference data? YES Fault is intermittent caused by poor contact in the sensor's and/or TCM (PCM)'s connector or was repaired and TCM (PCM) memory was not cleared. Thoroughly check connectors for looseness, poor connection, bending, corrosion, contamination, deterioration or damage. Repair or replace as necessary and go to " «VERIFICATION OF VEHICLE REPAIR»(ref-286597-S19268284122008060300000) " procedure. NO Go to " «TERMINAL & CONNECTOR INSPECTION»(ref-286597-S05251538502008060300000) " procedure.

Refer to DTC P0741 .

Scheme 235: MONITOR SCANTOOL DATA

Connect scantool to data link connector (DLC)
Engine "ON".
Monitor the "2nd SOL. VALVE" parameter on the scantool.
Shift gear position 1st to 2nd. Specification : 1st gear --> 100%, 2nd gear --> 0.0%
Does "2nd SOLENOID DUTY" follow the reference data? YES Fault is intermittent caused by poor contact in the sensor's and/or TCM (PCM)'s connector or was repaired and TCM (PCM) memory was not cleared. Thoroughly check connectors for looseness, poor connection, bending, corrosion, contamination, deterioration or damage. Repair or replace as necessary and go to " «VERIFICATION OF VEHICLE REPAIR»(ref-286597-S20331809082008060300000) " procedure. NO Go to " «TERMINAL & CONNECTOR INSPECTION»(ref-286597-S02390691772008060300000) " procedure.

Refer to DTC P0741 .

Scheme 236: MONITOR SCANTOOL DATA

Connect scantool to data link connector (DLC).
Engine "ON".
Monitor the "OD SOL. VALVE" parameter on the scantool.
Shift gear position 2nd to 3rd. Specification : 2nd gear --> 100%, 3rd gear --> 0.0% Does "OD SOLENOID DUTY" follow the reference data? YES Fault is intermittent caused by poor contact in the sensor's and/or TCM (PCM)'s connector or was repaired and TCM (PCM) memory was not cleared. Thoroughly check connectors for looseness, poor connection, bending, corrosion, contamination, deterioration or damage. Repair or replace as necessary and go to " «VERIFICATION OF VEHICLE REPAIR»(ref-286597-S15708183162008060300000) " procedure. NO Go to " «TERMINAL & CONNECTOR INSPECTION»(ref-286597-S35377766642008060300000) " procedure.

Refer to DTC U0001 .
