SPECIFICATION
| Item | F4A42 | |
|---|---|---|
| Torque converter type | 3-element, 1-stage, 2-phase type | |
| Transaxle type | 4-speed forward, 1-speed reverse | |
| Engine displacement | 2.4L GSL | |
| Gear ratio | 1st | 2.842 |
| 2nd | 1.529 | |
| 3rd | 1.000 | |
| 4th | 0.712 | |
| Reverse | 2.480 | |
| Final gear ratio | 3.770 | |
| Shift pattern | Variable | |
| Shift range | 4range ( P-R-N-D) + Sports mode | |
| Shift range valve | PWM; 5EA (Duty control), VFS | |
| Stall speed | 2100~2900 RPM | |
| Planetary gear | 2EA (Output planetary/Overdrive planetary) | |
| Clutch | 3EA | |
| Brake | 2EA | |
| OWE | 1EA | |
GENERAL SPECIFICATION
TIGHTENING TORQUE
| ITEM | N.m | Kgf.cm |
|---|---|---|
| Wiring harness bracket | 20 ~ 26 | 200 ~ 260 |
| Control cable bracket bolt | 20 ~ 26 | 200 ~ 260 |
| Eye bolt | 27 ~ 33 | 270 ~ 330 |
| Oil cooler feed tube | 10 ~ 12 | 100 ~ 120 |
| Input shaft speed sensor | 10 ~ 12 | 100 ~ 120 |
| Output shaft speed sensor | 10 ~ 12 | 100 ~ 120 |
| Manual control lever | 18 ~ 25 | 180 ~ 250 |
| Transaxle range switch | 10 ~ 12 | 100 ~ 120 |
| Speedometer gear | 4 ~ 6 | 40 ~ 60 |
| Valve body cover | 8 ~ 10 | 80 ~ 100 |
| Valve body mounting bolt | 10 ~ 12 | 100 ~ 120 |
| Oil temperature sensor | 10 ~ 12 | 100 ~ 120 |
| Manual control shaft detent | 5 ~ 7 | 50 ~ 70 |
| Rear cover | 20 ~ 26 | 200 ~ 260 |
| Torque converter housing | 42 ~ 54 | 420 ~ 540 |
| Oil pump | 20 ~ 26 | 200 ~ 260 |
| Transfer drive gear | 16 ~ 22 | 160 ~ 220 |
| Output shaft lock nut | 160 ~ 180 | 1600 ~ 1800 |
| Output shaft bearing retainer | 20 ~ 26 | 200 ~ 260 |
| Oil filler plug | 29 ~ 34 | 290 ~ 340 |
| Oil drain plug | 40 ~ 50 | 400 ~ 500 |
| Transfer drive gear lock nut | 180 ~ 210 | 1800 ~ 2100 |
| Differential drive gear to subframe bolts | 130 ~ 140 | 1300 ~ 1400 |
| Valve body | 10 ~ 12 | 100 ~ 120 |
| Solenoid valve support | 5 ~ 7 | 50 ~ 70 |
| Plate | 5 ~ 7 | 50 ~ 70 |
| Pressure check plug | 8 ~ 10 | 80 ~ 100 |
| Front roll stopper bracket to subframe bolts | 40 ~ 55 | 400 ~ 550 |
| Front roll stopper insulator bolt and nut | 50 ~ 65 | 500 ~ 650 |
| Front roll stopper bracket to transaxle bolts | 60 ~ 80 | 600 ~ 800 |
| Rear roll stopper bracket | 40 ~ 55 | 400 ~ 550 |
| Rear roll stopper insulator bolt and nut | 50 ~ 65 | 500 ~ 650 |
| Rear roll stopper bracket to transaxle bolts | 60 ~ 80 | 600 ~ 800 |
| Transaxle mounting sub bracket nut | 60 ~ 80 | 600 ~ 800 |
| Transaxle mounting bracket bolts | 40 ~ 55 | 400 ~ 550 |
| Transaxle mounting insulator bolt | 90 ~ 110 | 900 ~ 1100 |
TIGHTENING TORQUE
TORQUE CONVERTER AND SHAFT
The torque converter consists of a impeller (pump), turbine and stator assembly in a single unit. The pump is connected to the engine crankshaft and turns as the engine turns. This drawing force is transmitted to the turbine through the oil which is recycled by the stator.
The transmission has two parallel shafts; the input shaft and the output shaft. Both shafts are in line with the engine crankshaft. The input shaft includes the overdrive clutch, reverse clutch, underdrive clutch, one way clutch, 2ND brake, low & reverse brake, overdrive planetary carrier, output planetary carrier and transfer drive gear. The output shaft includes the transfer driven gear.
HALL TYPE SENSOR: SPECIFICATION
| Air gap (mm) | Input shaft speed sensor | 1.3 |
|---|---|---|
| Output shaft speed sensor | 0.85 | |
| Coil Resistance | Input shaft speed sensor | Over 1Mohms |
| Output shaft speed sensor | Over 1Mohms | |
| Peak-Peak Voltage | N High | 4.8~5.2V |
| Low | 0.8V |
HALL TYPE SENSOR SPECIFICATION
Scheme 126
Scheme 127
Scheme 128
Scheme 129
Scheme 130
Oil Temperature Sensor
The oil temperature sensor is of the thermistor type, and senses the automatic transaxle fluid temperature. Using the signal from this sensor, TCM (PCM) controls the shift pattern optimally during shift. In order to operate the damper clutch, this signal is also referred.
- Range of temperature : -40°C~145°C
- Type : Separated type (High / Low temperature)
- Standard value of internal resistance
| Temp.[°C (°F)] | Resistance (kohms) | Temp.[0C (°F)] | Resistance (kohms) |
|---|---|---|---|
| 40 (-40) | 139.5 | 80 (176) | 1.08 |
| 20 (-4) | 47.7 | 100 (212) | 0.63 |
| 0 (32) | 18.6 | 120 (248) | 0.38 |
| 20 (68) | 8.1 | 140 (284) | 0.25 |
| 40 (104) | 3.8 | 160 (320) | 0.16 |
| 60 (140) | 1.98 |
OIL TEMPERATURE SENSOR SPECIFICATION
Scheme 131
Inhibitor Switch
- Type : Rotary contact type
- Range of temperature : -40°C~145°C (-40°F~293°F)
Scheme 132
Scheme 133
TORQUE CONVERTER STALL TEST
This test measures the maximum engine speed when the selector lever is in the D or R position. The torque converter stalls to test the operation of the torque converter, starter motor, one-way clutch operation, the holding performance of the clutches, and brakes in the transaxle.
| CAUTION | Do not let anybody stand in front of or behind the vehicle while this test is being carried out |
- Check the automatic transmission fluid level and temperature, and the engine coolant temperature. Fluid level : At the HOT mark on the oil level gauge Fluid temperature : 80~100°C (176~212°F) Engine coolant temperature : 80~100°C (176~212°F)
- Prevent all the wheels from moving during the test.
- Pull the parking brake lever up, with the brake pedal fully depressed.
- Start the engine.
- Move the selector lever to the "D" position, fully depress the accelerator pedal and take a reading of the maximum engine speed at this time. Stall speed : 2,100~2,900 RPM CAUTION: The throttle should not be left fully open for any more than five seconds. If carrying out the stall test two or more times, move the selector lever to the "N" position and run the engine at 1,000 r/min to let the automatic transaxle fluid cool down before carrying out subsequent tests.
- Move the selector lever to the "R" position and carry out the same test again.
Scheme 134
- Stall speed is too high in both "D" and "R" ranges Low line pressure Low & reverse brake (B) slippage
- Stall speed is to high in "D" range only Underdrive clutch (C) slippage
- Stall speed is too high in "R" range only Reverse clutch (A) slippage
- Stall speed too low in both "D" and "R" ranges Malfunction of torque converter (D) Insufficient engine output
| BRAKE | DATA VALUE |
|---|---|
| Operation | ON |
| Non-operation | OFF |
SPECIFICATION CHART
Scheme 135
Scheme 136
Scheme 137
- Connect scantool to data link connector (DLC).
- Ignition "ON" & Engine "OFF".
- Monitor the "BRAKE LAMP SWITCH" parameter on the scantool.
- Depress and release Foot Brake.
- Does "STOP LAMP SWITCH" follow the reference data? YES Fault is intermittent caused by poor contact in the sensor's and/or TCM (PCM)'s connector or was repaired and TCM (PCM) memory was not cleared. Thoroughly check connectors for looseness, poor connection, bending, corrosion, contamination, deterioration or damage. Repair or replace as necessary and go to " «VERIFICATION VEHICLE REPAIR»(ref-286597-S09991540052008060300000) " procedure. NO Inspect wiring harness and connector.
| Inspection condition | Reference value | |
|---|---|---|
| IG KEY ON and Engine OFF | Shift lever: P | P, N |
| Shift lever: R | R | |
| Shift lever: N | P, N | |
| Shift lever: D | D | |
SPECIFICATION CHART
Scheme 138
Scheme 139
- Connect scantool to data link connector (DLC).
- Ignition "ON" & Engine "OFF".
- Monitor the "TRANSAXLE RANGE SWITCH" parameter on the scantool.
- Move selector lever from "P" range to other range.
- Does "TRANSAXLE RANGE SWITCH" follow the reference data? YES Fault is intermittent caused by poor contact in the sensor's and/or TCM (PCM)'s connector or was repaired and TCM (PCM) memory was not cleared. Thoroughly check connectors for looseness, poor connection, bending, corrosion, contamination, deterioration or damage. Repair or replace as necessary and go to " «VERIFICATION VEHICLE REPAIR»(ref-286597-S09991540052008060300000) " procedure. NO Go to " «TERMINAL & CONNECTOR INSPECTION»(ref-286597-S16068953442008060300000) " procedure.
Refer to DTC P0707 .
| Temp.[°C (°F)] | Resistance (kohms) | Temp.[°C (°F)] | Resistance (kohms) |
|---|---|---|---|
| 40 (-40) | 139.5 | 80 (176) | 1.08 |
| 20 (-4) | 47.7 | 100 (212) | 0.63 |
| 0 (32) | 18.6 | 120 (248) | 0.38 |
| 20 (68) | 8.1 | 140 (284) | 0.25 |
| 40 (104) | 3.8 | 160 (320) | 0.16 |
| 60 (140) | 1.98 |
SPECIFICATION CHART
Scheme 140
Scheme 141
- Connect scantool to data link connector (DLC).
- Engine "ON".
- Monitor the "TRANSAXLE FLUID TEMPERATURE SENSOR" parameter on the scantool. Specification : Increasing Gradually
- Does "TRANSAXLE FLUID TEMPERATURE SENSOR" follow the reference data? YES Fault is intermittent caused by poor contact in the sensor's and/or TCM (PCM)'s connector or was repaired and TCM (PCM) memory was not cleared. Thoroughly check connectors for looseness, poor connection, bending, corrosion, contamination, deterioration or damage. Repair or replace as necessary and go to " «VERIFICATION VEHICLE REPAIR»(ref-286597-S08046124662008060300000) " procedure. NO Go to " «TERMINAL & CONNECTOR INSPECTION»(ref-286597-S40213682912008060300000) " procedure.
Refer to DTC P0711 .
Refer to DTC P0711 .
Input shaft & Output shaft speed sensor
- Type : Hall sensor
- Current consumption : 22mA (MAX)
- sensor body and sensor connector have been unified as one.
Scheme 142
Scheme 143
Scheme 144
- Connect scantool to data link connector (DLC).
- Engine "ON".
- Monitor the "INPUT SPEED SENSOR" parameter on the scantool
- Driving at speed of over 30 Km/h (19 mph). Specification : Increasing Gradually
- Does "input speed sensor" follow the reference data? YES Fault is intermittent caused by poor contact in the sensor's and/or TCM (PCM)'s connector or was repaired and TCM (PCM) memory was not cleared. Thoroughly check connectors for looseness, poor connection, bending, corrosion, contamination, deterioration or damage. Repair or replace as necessary and go to " «VERIFICATION VEHICLE REPAIR»(ref-286597-S29397485612008060300000) " procedure. NO Go to " «TERMINAL & CONNECTOR INSPECTION»(ref-286597-S03763899712008060300000) " procedure.
Input shaft & Output shaft speed sensor
- Type : Hall sensor
- Current consumption : 22mA (MAX)
- Sensor body and sensor connector have been unified as one.
Scheme 145
- Connect scantool to data link connector (DLC).
- Engine "ON".
- Monitor the "OUTPUT SPEED SENSOR" parameter on the scantool.
- Driving at speed of over 30 Km/h (19 mph). Specification : Increasing Gradually
- Does "output speed sensor" follow the reference data? YES Fault is intermittent caused by poor contact in the sensor's and/or TCM (PCM)'s connector or was repaired and TCM (PCM) memory was not cleared. Thoroughly check connectors for looseness, poor connection, bending, corrosion, contamination, deterioration or damage. Repair or replace as necessary and go to " «VERIFICATION VEHICLE REPAIR»(ref-286597-S37143452212008060300000) " procedure. NO Go to " «TERMINAL & CONNECTOR INSPECTION»(ref-286597-S14292096892008060300000) " procedure.
Refer to DTC P0717 .
Solenoid Valve for Pressure Control
- Sensor type : Normal open 3-way
- Operating temperature : -30°C~130°C ( -22-266°F)
- Frequency : LR, 2ND, UD, OD, RED: 61.27Hz (at the ATF temp. -20°C above) DCC : 30.64HZ VFS : 600 ± 20Hz
- Internal resistance : 2.7~3.4ohms (68°F or 20°C) - LR, 2ND, UD, OD, RED, DCC 4.3~4.4ohms (68°F or 20°C) - VFS
- Surge voltage : 56 V (except VFS)
Refer to DTC P0743 .
Refer to DTC P0743 .
Refer to DTC P0743 .
Refer to DTC P0743 .
Refer to DTC P0743 .
