Rear Seat Hyundai Santa Fe III

Scheme 1

Scheme 2

Scheme 3

Scheme 4

Scheme 5

Scheme 6

Scheme 7

Scheme 8

Scheme 9

Scheme 10

Scheme 11

Scheme 12

1. Push the second row seat assembly [RH] (A) towards the front of the vehicle as far as possible.
2. Push the second row seat assembly towards the front of the vehicle as far as possible.
3. Loosen the second row seat assembly rear mounting bolts (A). Tightening torque: 44.1 ~ 58.8N.m (4.5 ~ 6.0kgf.m, 32.5 ~ 43.4lb-ft) [LH] [RH]
4. Push the second row seat assembly towards the rear of the vehicle as far as possible.
5. After loosening the mounting bolts, then remove the second row seat assembly (A). Tightening torque: 16.7 ~ 25.5N.m (1.7 ~ 2.6kgf.m, 12.3~18.8lb-ft)
6. Install in the reverse order of removal.

Scheme 13

Scheme 14

Scheme 15

Scheme 16

Scheme 17

1. Remove the luggage covering met (A).
2. After loosening the mounting screws, then remove the luggage floor box (A).
3. Loosen the third row seat assembly rear mounting bolts (A). Tightening torque: 16.7 ~ 25.5N.m (1.7 ~ 2.6kgf.m, 12.3~18.8lb-ft)
4. Remove the third row seat track mounting cover (A).
5. After loosening the mounting bolts, then remove the third row seat assembly (A). Tightening torque: 16.7 ~ 25.5N.m (1.7 ~ 2.6kgf.m, 12.3~18.8lb-ft)
6. Install in the reverse order of removal.

Scheme 18

Scheme 19

(LH)

Note. When prying with a flat-tip screwdriver, wrap it with protective tape, and apply protective tape around the related parts, to prevent damage. Use a plastic panel removal tool to remove interior trim pieces to protect from marring the surface. Take care not to bend or scratch the trim and panels.

Scheme 20

Scheme 21

Scheme 22

Scheme 23

Scheme 24

Scheme 25

Scheme 26

Scheme 27

Scheme 28

Scheme 29

Scheme 30

Scheme 31

Scheme 32

Scheme 33

Scheme 34

1. Remove the second row seat assembly [LH]. (Refer to Rear Seat - " «REAR SEAT ASSEMBLY»(/hyundai/santa-fe/iii-2012-2016/remont/seats/#rear-seat) ")
2. Tilt the rear back armrest towards the front of the vehicle as far as possible.
3. To remove the rear back armrest (B), loosen the mounting bolts after removing the caps (A).
4. Remove the mounting screws (A).
5. Remove the rear back armrest pad (B) by pulling it out while pressing the both sides of the lock pin (C).
6. After loosening the mounting bolt and nuts, then remove the rear back armrest bracket (A).
7. After loosening the mounting bolt, then remove the rear back armrest panel (A).
8. Push the lock pin (B), remove the rear seat headrest (A).
9. Using a screwdriver or remover, remove the rear center seat belt upper anchor cover (A).
10. After loosening the mounting screw, then remove the rear seat striker mounting cover (A).
11. Using a screwdriver or remover, remove the rear seat folding cover (A).
12. After loosening the mounting screw, then remove the rear seat shield outer cover (A).
13. Remove the protector (A) located in the bottom side of the rear seat cushion.
14. Remove the protector (A) located in the bottom side of the rear seat back.
15. Remove the protector (A) located in the upper side of the rear seat back.
16. Remove the protector (B) located in the side part of the rear seat back.
17. Turn the rear seat back cover inside out. Then pull out the headrest guides (A) while pinching the upper part of the guides, and remove them.
18. Remove the rear seat back cover (A) from the rear seat back frame.
19. After removing the velcro tape (A) on the rear of seat back and remove the rear seat back cover (B).
20. Install in the reverse order of removal. Information Replace any damaged clips.

(RH)

Note. When prying with a flat-tip screwdriver, wrap it with protective tape, and apply protective tape around the related parts, to prevent damage. Use a plastic panel removal tool to remove interior trim pieces to protect from marring the surface. Take care not to bend or scratch the trim and panels.

Scheme 35

Scheme 36

Scheme 37

Scheme 38

Scheme 39

Scheme 40

Scheme 41

Scheme 42

Scheme 43

Scheme 44

Scheme 45

1. Remove the second row seat assembly [RH]. (Refer to Rear Seat - " «REAR SEAT ASSEMBLY»(/hyundai/santa-fe/iii-2012-2016/remont/seats/#rear-seat) ")
2. Push the lock pin (B), remove the rear seat headrest (A).
3. Using a screwdriver or remover, remove the rear seat folding cover (A).
4. After loosening the mounting screw, then remove the rear seat shield outer cover (A).
5. After loosening the mounting screw, then remove the rear seat shield inner cover (A).
6. Remove the protector (A) located in the bottom side of the rear seat cushion.
7. Remove the protector (A) located in the bottom side of the rear seat back.
8. Remove the protector (A) located in the upper side of the rear seat back.
9. Remove the protector (B) located in the side part of the rear seat back.
10. Remove the protector (A) located in the side of the inner part of the rear seat back.
11. Turn the rear seat back cover inside out. Then pull out the headrest guides (A) while pinching the upper part of the guides, and remove them.
12. Remove the rear seat back cover (A) from the rear seat back frame.
13. After removing the velcro tape (A) on the rear of seat back and remove the rear seat back cover (B).
14. Install in the reverse order of removal. Information Replace any damaged clips.

[Third row seat assembly]

Note. When prying with a flat-tip screwdriver, wrap it with protective tape, and apply protective tape around the related parts, to prevent damage. Use a plastic panel removal tool to remove interior trim pieces to protect from marring the surface. Take care not to bend or scratch the trim and panels.

Scheme 46

Scheme 47

Scheme 48

Scheme 49

Scheme 50

Scheme 51

Scheme 52

Scheme 53

1. Remove the third row seat assembly. (Refer to Rear Seat - " «REAR SEAT ASSEMBLY»(/hyundai/santa-fe/iii-2012-2016/remont/seats/#rear-seat) ")
2. Using a screwdriver or remover, remove the reat seat headrest cover (A).
3. Loosen the rear seat frame mounting bolts (A). Tightening torque: 44.1 ~ 53.9 N.m (4.5 ~ 5.5 kgf.m, 32.5 ~ 39.8 lb-ft)
4. Push the rear seat cushion frame (A) to the front of the vehicle as far as possible.
5. Remove the protector (A) located in the side part of the rear seat back.
6. Remove the protector (A) located in the bottom side of the rear seat back.
7. Turn the rear seat back cover inside out. Then pull out the headrest guides (A) while pinching the upper part of the guides, and remove them.
8. Remove the rear seat back cover (A) from the rear seat back frame.
9. After removing the velcro tape (A) on the rear of seat back and remove the rear seat back cover (B).
10. Install in the reverse order of removal. Information Replace any damaged clips.

Scheme 54

Scheme 55

Note. When prying with a flat-tip screwdriver, wrap it with protective tape, and apply protective tape around the related parts, to prevent damage. Use a plastic panel removal tool to remove interior trim pieces to protect from marring the surface. Take care not to bend or scratch the trim and panels.

Scheme 56

Scheme 57

Scheme 58

Scheme 59

Scheme 60

Scheme 61

1. Remove the second row seat assembly [LH]. (Refer to Rear Seat - " «REAR SEAT ASSEMBLY»(/hyundai/santa-fe/iii-2012-2016/remont/seats/#rear-seat) ")
2. Remove the protector (A) located in the bottom side of the rear seat cushion.
3. After loosening the mounting screw, then remove the rear seat slide knob (A).
4. After loosening the mounting screw, then remove the rear seat slide outer cover (A).
5. Remove the protector (A) located in the side part of the rear seat cushion.
6. Remove the rear seat cushion cover (A) from the rear seat cushion frame.
7. After removing the velcro tape (A) on the rear of seat cushion and remove the rear seat cushion cover (B).
8. Install in the reverse order of removal. Information Replace any damaged clips.

Note. When prying with a flat-tip screwdriver, wrap it with protective tape, and apply protective tape around the related parts, to prevent damage. Use a plastic panel removal tool to remove interior trim pieces to protect from marring the surface. Take care not to bend or scratch the trim and panels.

Scheme 62

Scheme 63

Scheme 64

Scheme 65

Scheme 66

Scheme 67

1. Remove the second row seat assembly [RH]. (Refer to Rear Seat - " «REAR SEAT ASSEMBLY»(/hyundai/santa-fe/iii-2012-2016/remont/seats/#rear-seat) ")
2. Remove the protector (A) located in the bottom side of the rear seat cushion.
3. After loosening the mounting screw, then remove the rear seat slide knob (A).
4. After loosening the mounting screw, then remove the rear seat slide outer cover (A).
5. Remove the protector (A) located in the side part of the rear seat cushion.
6. Remove the rear seat cushion cover (A) from the rear seat cushion frame.
7. After removing the velcro tape (A) on the rear of seat cushion and remove the rear seat cushion cover (B).
8. Install in the reverse order of removal. Information Replace any damaged clips.

Note. When prying with a flat-tip screwdriver, wrap it with protective tape, and apply protective tape around the related parts, to prevent damage. Use a plastic panel removal tool to remove interior trim pieces to protect from marring the surface. Take care not to bend or scratch the trim and panels.

Scheme 68

Scheme 69

Scheme 70

Scheme 71

Scheme 72

Scheme 73

Scheme 74

1. Remove the third row seat assembly. (Refer to Rear Seat - " «REAR SEAT ASSEMBLY»(/hyundai/santa-fe/iii-2012-2016/remont/seats/#rear-seat) ")
2. Loosen the rear seat frame mounting bolts (A). Tightening torque: 44.1 ~ 53.9 N.m (4.5 ~ 5.5 kgf.m, 32.5 ~ 39.8 lb-ft)
3. Push the rear seat cushion frame (A) to the front of the vehicle as far as possible.
4. After loosening the mounting screw, then remove the rear seat outer link cover (A).
5. After loosening the mounting screw, then remove the rear seat inner link cover (A).
6. Remove the protector (A) located in the side part of the rear seat cushion.
7. Remove the rear seat cushion cover (A) from the rear seat cushion frame.
8. After removing the velcro tape (A) on the rear of seat cushion and remove the rear seat cushion cover (B).
9. Install in the reverse order of removal. Information

Scheme 75

Scheme 76

[Second row seat assembly]

Note. When prying with a flat-tip screwdriver, wrap it with protective tape, and apply protective tape around the related parts, to prevent damage. Use a plastic panel removal tool to remove interior trim pieces to protect from marring the surface. Take care not to bend or scratch the trim and panels.

Scheme 77

Scheme 78

Scheme 79

1. Remove the second row seat assembly [LH]. (Refer to Rear Seat - " «REAR SEAT ASSEMBLY»(/hyundai/santa-fe/iii-2012-2016/remont/seats/#rear-seat) ")
2. Holding the bottom (B) lift up the rear seat back panel (A) to the direction of the arrow.
3. Disconnect the rear seat folding cable (A).
4. After loosening the mounting screws, then remove the rear seat folding cover (A).
5. Install in the reverse order of removal. Information Replace any damaged clips.

Note. When prying with a flat-tip screwdriver, wrap it with protective tape, and apply protective tape around the related parts, to prevent damage. Use a plastic panel removal tool to remove interior trim pieces to protect from marring the surface. Take care not to bend or scratch the trim and panels.

Scheme 80

Scheme 81

Scheme 82

1. Remove the rear seat back cover. (Refer to Rear Seat - " «REAR SEAT BACK COVER»(/hyundai/santa-fe/iii-2012-2016/remont/seats/#rear-seat) ")
2. After loosening the mounting screws, then remove the rear seat latch cover (A).
3. Disconnect the rear seat latch cable (A).
4. After loosening the mounting bolts (A), then remove the rear seat latch (B). Tightening torque: 19.6 ~ 29.4 N.m (2.0 ~ 3.0 kgf.m, 14.5 ~ 21.7 lb-ft)
5. Install in the reverse order of removal. Information Replace any damaged clips.

Scheme 83

Scheme 84

Scheme 85

Note. When prying with a flat-tip screwdriver, wrap it with protective tape, and apply protective tape around the related parts, to prevent damage. Use a plastic panel removal tool to remove interior trim pieces to protect from marring the surface. Take care not to bend or scratch the trim and panels.

Scheme 86

1. Remove the rear seat back cover. (Refer to Rear Seat - " «REAR SEAT BACK COVER»(/hyundai/santa-fe/iii-2012-2016/remont/seats/#rear-seat) ")
2. Remove the rear seat cushion cover. (Refer to Rear Seat - " «REAR SEAT CUSHION COVER»(/hyundai/santa-fe/iii-2012-2016/remont/seats/#rear-seat) ")
3. After loosening the mounting bolts, then disconnect the rear seat back frame assembly (A) and rear seat cushion frame assembly (B). Tightening torque: 53.9 ~ 63.7 N.m (5.5 ~ 6.5 kgf.m, 39.8 ~ 47.0 lb-ft)
4. Install in the reverse order of removal. Information Replace any damaged clips.

Note. When prying with a flat-tip screwdriver, wrap it with protective tape, and apply protective tape around the related parts, to prevent damage. Use a plastic panel removal tool to remove interior trim pieces to protect from marring the surface. Take care not to bend or scratch the trim and panels.

Scheme 87

1. Remove the rear seat back cover. (Refer to Rear Seat - " «REAR SEAT BACK COVER»(/hyundai/santa-fe/iii-2012-2016/remont/seats/#rear-seat) ")
2. Remove the rear seat cushion cover. (Refer to Rear Seat - " «REAR SEAT CUSHION COVER»(/hyundai/santa-fe/iii-2012-2016/remont/seats/#rear-seat) ")
3. After loosening the mounting bolts, then disconnect the rear seat back frame assembly (A) and rear seat cushion frame assembly (B). Tightening torque: 53.9 ~ 63.7 N.m (5.5 ~ 6.5 kgf.m, 39.8 ~ 47.0 lb-ft)
4. Install in the reverse order of removal. Information Replace any damaged clips.

Note. When prying with a flat-tip screwdriver, wrap it with protective tape, and apply protective tape around the related parts, to prevent damage. Use a plastic panel removal tool to remove interior trim pieces to protect from marring the surface. Take care not to bend or scratch the trim and panels.

Scheme 88

1. Remove the rear seat back cover. (Refer to Rear Seat - " «REAR SEAT BACK COVER»(/hyundai/santa-fe/iii-2012-2016/remont/seats/#rear-seat) ")
2. Remove the rear seat cushion cover. (Refer to Rear Seat - " «REAR SEAT CUSHION COVER»(/hyundai/santa-fe/iii-2012-2016/remont/seats/#rear-seat) ")
3. After loosening the mounting bolts, then disconnect the rear seat back frame assembly (A) and rear seat cushion frame assembly (B). Tightening torque: 44.1 ~ 53.9 N.m (4.5 ~ 5.5 kgf.m, 32.5 ~ 39.8 lb-ft)
4. Install in the reverse order of removal. Information Replace any damaged clips.

Scheme 89

Scheme 90

Scheme 91

1. Remove the luggage side trim. (Refer to " «LUGGAGE SIDE TRIM»(/hyundai/santa-fe/iii-2012-2016/remont/exteriorinterior-trim/#interior-trim) ")
2. Disconnect the cable (B) and remove the seat remote folding lever (A).
3. Remove the seat remote folding cable (B) after disengaging the fixing clips (A).
4. Install in the reverse order of removal.

Scheme 92

Scheme 93

Scheme 94

1. Remove the seat remote folding housing (A).
2. Loosen bolt (A-2ea) on the vehicle and then remove seat remote folding lever (B). Tightening torque: 3.9 ~ 5.9 N.m (0.4 ~ 0.6 kgf.m, 2.9 ~ 4.3 lb-ft)
3. Disconnect the cable (B) and remove the seat remote folding lever (A).
4. Install in the reverse order of removal.

Scheme 95

Scheme 96

Scheme 97

1. Push the second row seat towards the front of the vehicle as far as possible.
2. Open the folding cable connector cap (A).
3. Remove the folding cable connector (A) from the second row seat cable.
4. Remove the folding cable connector (A) after loosening mounting nuts. Tightening torque: 3.9 ~ 5.9 N.m (0.4 ~ 0.6 kgf.m, 2.9 ~ 4.3 lb-ft)
5. Install in the reverse order of removal.
