Seat Electrical Hyundai Santa Fe III

Scheme 98

Scheme 99

Scheme 100

1. Disconnect the connectors for each motor. (Refer to Body - " «FRONT SEAT ASSEMBLY»(/hyundai/santa-fe/iii-2012-2016/remont/seats/#seat-electrical) ") Slide motor Front height motor Rear height motor Lumbar support motor (Horizontal) Lumbar support motor (Vertical) Recline motor
2. With the battery connected directly to the motor terminals, check if the motors run smoothly.
3. Reverse the connections and check that the motor turns in reverse.
4. If there is an abnormality, replace the motors.

Scheme 101

Scheme 102

Scheme 103

Scheme 104

Note. Make sure that the motor connectors are plugged in properly.

Scheme 105

Scheme 106

Scheme 107

Scheme 108

Scheme 109

Scheme 110

Scheme 111

Scheme 112

Scheme 113

1. With the power seat switch in each position, make sure that continuity exists between the terminals below. If continuity is not as specified, replace the power seat switch.

Scheme 114

1. Disconnect the negative (-) battery terminal.
2. Remove the front seat shield outer cover. (Refer to " «FRONT SEAT SHIELD OUTER COVER»(/hyundai/santa-fe/iii-2012-2016/remont/seats/#front-seat) ")
3. Remove the power seat control switch (A) and lumbar support switch (B).

Installation

1. Install the power seat control switch after connecting the connector.

Scheme 115

Scheme 116

Scheme 117

Scheme 118

Scheme 119

Scheme 120

1. Check for continuity and measure the resistance between terminals. No. Description 1 Heater + 2 Heater - 3 NTC + 4 - 5 NTC - 6 - Standard value (Fabric/Leather) Cushion : 1.27 ohms ± 10% Back : 1.07 ohms ± 10% Set : 2.34 ohms ± 10%
2. Operate the seat heater after connecting the connector, and then check the NTC by measuring the temperature of seat surface. 1st 2nd 3rd Cushion (±2°C/±3.6°F) 36°C (96.8°F) 39°C (102.2°F) 42°C (107.6°F) Back (±2°C/±3.6°F) 40°C (104°F) 45°C (113°F) 50°C (122°F)

Second Seat

1. Check for continuity and measure the resistance between terminals.

Scheme 121

Scheme 122

Standard value (Fabric/Leather)

Cushion : 1.15 ohms ± 10%

Back : 1.09 ohms ± 10%

Set : 2.24 ohms ± 10%

1. 2. Operate the seat heater after connecting the connector, and then check the NTC by measuring the temperature of seat surface. Standard value Cushion : 36±2°C (LOW)/39±2°C (HIGH) Back : 40.0±2°C (LOW)/45.0±2°C (HIGH)

Scheme 123

Scheme 124

Scheme 125

Scheme 126

Scheme 127

Scheme 128

Scheme 129

Scheme 130

Scheme 131

Scheme 132

Scheme 133

Scheme 134

1. Disconnect the negative (-) battery terminal.
2. Remove the floor console assembly. (Refer to " «FLOOR CONSOLE ASSEMBLY»(/hyundai/santa-fe/iii-2012-2016/remont/exteriorinterior-trim/#floor-console) ")
3. Remove the heater switch after loosening the screws. [A/T]
4. Remove the front tray cover (A). [M/T]
5. Remove the heater switch after loosening the screws.

1. Disconnect the negative (-) battery terminal.
2. Remove the rear door trim. (Refer to " «REAR DOOR TRIM»(/hyundai/santa-fe/iii-2012-2016/remont/exterior-body-panels/#rear-door) ")
3. Remove the power window switch after loosen the screws (3EA).

Driver/Passenger

1. Install the heater switch.
2. Install the floor console upper cover.
3. Connect the negative (-) battery terminal.

1. Install the power window switch.
2. Install the rear door trim.
3. Connect the negative (-) battery terminal.

Scheme 135

Scheme 136

1. Disconnect the negative (-) battery terminal.
2. Remove the floor console upper cover. (Refer to Body «[CONSOLE REAR COMPLETE ASSEMBLY]»(/hyundai/santa-fe/iii-2012-2016/remont/exteriorinterior-trim/#floor-console) - "Floor Console Upper Cover")
3. Operate driver seat heater switch and check that continuity exists between the terminals. If there is no continuity, replace the seat heater switch.

Scheme 137

1. Disconnect the negative (-) battery terminal.
2. Remove the rear door trim. (Refer to " «REAR DOOR TRIM»(/hyundai/santa-fe/iii-2012-2016/remont/exterior-body-panels/#rear-door) ")
3. Operate driver seat heater switch and check that continuity exists between the terminals. If there is no continuity, replace the seat heater switch.

Scheme 138

Scheme 139

Scheme 140

Description

The ventilated seat system uses a Push method to cool the seat. A blower mounted in the seat generates the cool air, which then travels through ducts to the seat back and cushion.

Scheme 141

Scheme 142

1. Remove the front seat assembly. (Refer to Body - " «FRONT SEAT ASSEMBLY»(/hyundai/santa-fe/iii-2012-2016/remont/seats/#seat-electrical) ")
2. Remove the cushion blower (A) after loosening the screws (4EA) and disconnecting the connector.

Scheme 143

1. Remove the front seat assembly. (Refer to Body - " «FRONT SEAT ASSEMBLY»(/hyundai/santa-fe/iii-2012-2016/remont/seats/#seat-electrical) ")
2. Remove the front seat back cover. (Refer to " «FRONT SEAT BACK COVER»(/hyundai/santa-fe/iii-2012-2016/remont/seats/#front-seat) ")
3. Remove the back blower (A) after loosening the screws (2EA) and disconnecting the connector.

Scheme 144

1. Remove the front seat assembly. (Refer to Body - " «FRONT SEAT ASSEMBLY»(/hyundai/santa-fe/iii-2012-2016/remont/seats/#seat-electrical) ")
2. Remove the air ventilation unit (A) after loosening the screws (2EA) and disconnecting the connector.

Cushion Blower

1. Install the cushion blower.
2. Install the front seat assembly.

Back Blower

1. Install the back blower.
2. Install the front seat back cover.
3. Install the front seat assembly.

Air Ventilation Unit

1. Install the air ventilation unit.
2. Install the front seat assembly.
