Multifunction Switch Hyundai Santa Fe III

Steering Column Switches 20 illustrations ~290 words

Specifications

ItemsSpecifications
Rated voltageDC 12V
Operating temperature range22 ~ +176°F (-30°C ~ +80°C)
Rated loadDimmer & passing switchHigh: 0.2A (Relay load) Low: 0.2A (Relay load) Passing: 0.2A (Relay load)
Lighting switchLighting: 0.2A (Relay load) (High, Low, Auto)
Front & rear fog lamp switch0.2A (Relay load)
Turn signal switch6.6A (Lamp load)
Wiper & mist switchLow: 4.5A (Motor load) High: 4.5A (Motor load) Intermittent: 0.25 mA Lock: Max. 28A (Motor load) Washer: 4.0A (Motor load)
Rear wiper & washerWiper: 1.0A (Relay load) Washer: 4.0A (Motor load)

Scheme 1

Scheme 1: Component
Scheme 1: Component

Scheme 2

Scheme 2: Removal
Scheme 2: Removal

Scheme 3

Scheme 3
Scheme 3

Scheme 4

Scheme 4
Scheme 4

Scheme 5

Scheme 5
Scheme 5

Scheme 6

Scheme 6
Scheme 6
  1. Disconnect the negative (-) battery terminal.
  2. Remove the steering wheel. (Refer to «STEERING WHEEL - SANTA FE»(/hyundai/santa-fe/iii-2012-2016/remont/steering-column/#steering-wheel) .
  3. Remove the steering column upper and lower shrouds (A) after removing 3 screws.
  4. Disconnect the light switch connector (A) and the wiper switch connector (B).
  5. Remove the wiper switch (A) by pushing the lock pin (B). NOTE: When removing the wiper & washer switch only, release the lock of wiper switch without removing the steering wheel.
  6. Remove the clock spring. (Refer to " «DRIVER AIRBAG (DAB) MODULE AND CLOCK SPRING»(/hyundai/santa-fe/iii-2012-2016/remont/airbag/#airbag-modules-clock-spring) ")
  7. Loosen the screws (2EA) from the multifunction switch assembly (A).

Installation

  1. Install the multifunction switch.
  2. Install the clock spring and steering wheel.
  3. Install the steering column upper and lower shrouds.
  4. Install the steering wheel.

Scheme 7

Scheme 7: Lighting Switch Inspection
Scheme 7: Lighting Switch Inspection
  1. With the multi function switch in each position, make sure that continuity exists between the terminals below. If continuity is not as specified, replace the multi-function switch

Scheme 8

Scheme 8: Lighting switch (Auto light)
Scheme 8: Lighting switch (Auto light)

Scheme 9

Scheme 9: Lighting Switch
Scheme 9: Lighting Switch

Scheme 10

Scheme 10: Dimmer And Passing Switch
Scheme 10: Dimmer And Passing Switch

Scheme 11

Scheme 11: Turn Signal Switch
Scheme 11: Turn Signal Switch

Scheme 12

Scheme 12: Front Fog Lamp
Scheme 12: Front Fog Lamp

Scheme 13

Scheme 13: Wiper And Washer Switch Inspection
Scheme 13: Wiper And Washer Switch Inspection
  1. With the multi function switch in each position, make sure that continuity exists between the terminals below. If continuity is not as specified, replace the multi-function switch.

Scheme 14

Scheme 14: Wiper Switch
Scheme 14: Wiper Switch

Scheme 15

Scheme 15: Washer Switch
Scheme 15: Washer Switch

Scheme 16

Scheme 16: Rear Wiper Switch
Scheme 16: Rear Wiper Switch

Scheme 17

Scheme 17: Rear Washer Switch
Scheme 17: Rear Washer Switch

Scheme 18

Scheme 18: Inspection (With GDS)
Scheme 18: Inspection (With GDS)

Scheme 19

Scheme 19
Scheme 19

Scheme 20

Scheme 20
Scheme 20
  1. Check IPM input/output specification of multifunction switch using the GDS. If the specification is abnormal, replace the lamp or wiper switch.
  2. If diagnosis is required on the multifunction switch, select model and "IPM".
  3. Select "Current data" and check the input/output condition of "Multifunction switch".
  4. To perform test on "Multifunction switch" outputs, select "Actuation test".
