Front Seat Belt Hyundai Santa Fe III

Scheme 11

Scheme 12

Replacement

Note. When installing the belt, make sure not to damage the pretensioner.

Scheme 13

Scheme 14

1. Remove the center pillar upper trim. (Refer to " «CENTER PILLAR TRIM»(/hyundai/santa-fe/iii-2012-2016/remont/exteriorinterior-trim/#interior-trim) ")
2. After loosening the mounting bolt, then remove the front seat belt upper anchor (A). Tightening torque: 39.2 ~ 53.9 N.m (4.0 ~ 5.5 kgf.m, 28.8 ~ 39.8 lb-ft)
3. Loosen the mounting bolts, and remove the front seat belt pretensioner (B).
4. Disconnect the pretensioner connector lock pin, and remove the front seat belt pretensioner connector (A). Tightening torque: 39.2 ~ 53.9 N.m (4.0 ~ 5.5 kgf.m, 28.8 ~ 39.8 lb-ft)
5. Install in the reverse order of removal. Information Make sure the connector is plugged in properly. Replace any damaged clips.

Scheme 15

Scheme 16

1. Remove the front seat belt upper anchor. (Refer to Front Seat Belt - " «FRONT SEAT BELT PRETENSIONER»(/hyundai/santa-fe/iii-2012-2016/remont/passive-restraints/#front-seat-belt) ")
2. After loosening the mounting bolts, then remove the height adjust (A). Tightening torque: 39.2 ~ 53.9 N.m (4.0 ~ 5.5 kgf.m, 28.9 ~ 39.8 lb-ft)
3. Install in the reverse order of removal. Information Replace any damaged clips.

Scheme 17

Scheme 18

Scheme 19

1. Remove the front seat assembly. (Refer to " «FRONT SEAT ASSEMBLY»(/hyundai/santa-fe/iii-2012-2016/remont/seats/#front-seat) ")
2. Disconnect the front seat belt buckle connector wiring (A).
3. After loosening the mounting nut, then remove the front seat belt buckle (A). Tightening torque: 39.2 ~ 53.9 N.m (4.0 ~ 5.5 kgf.m, 28.9 ~ 39.8 lb-ft)
4. Install in the reverse order of removal. Information Make sure the connector is plugged in properly. Replace any damaged clips.
