Rear Seat Belt Hyundai Santa Fe III

Passive Restraints 19 illustrations ~702 words

Scheme 20

Scheme 20: Component Location
Scheme 20: Component Location

Second Row Seat Belt Assembly

Note. When installing the belt, make sure not to damage the retractor.

Scheme 21

Scheme 21: Second Row Seat Belt Assembly
Scheme 21: Second Row Seat Belt Assembly

Scheme 22

Scheme 22
Scheme 22
  1. Remove the rear pillar trim. (Refer to " «REAR PILLAR TRIM»(/hyundai/santa-fe/iii-2012-2016/remont/exteriorinterior-trim/#interior-trim) ")
  2. After loosening the mounting bolt, then remove the second row seat belt upper anchor (A). Tightening torque: 39.2 ~ 53.9 N.m (4.0 ~ 5.5 kgf.m, 28.8 ~ 39.8 lb-ft)
  3. After loosening the mounting bolt, then remove the second row seat belt retractor (A). Tightening torque: 39.2 ~ 53.9 N.m (4.0 ~ 5.5 kgf.m, 28.8 ~ 39.8 lb-ft)
  4. Install in the reverse order of removal. Information Make sure the connector is plugged in properly. Replace any damaged clips.

Third Row Seat Belt Assembly

Note. When installing the belt, make sure not to damage the retractor.

Scheme 23

Scheme 23: Third Row Seat Belt Assembly
Scheme 23: Third Row Seat Belt Assembly

Scheme 24

Scheme 24
Scheme 24

Scheme 25

Scheme 25
Scheme 25
  1. Remove the luggage side trim. (Refer to " «LUGGAGE SIDE TRIM»(/hyundai/santa-fe/iii-2012-2016/remont/exteriorinterior-trim/#interior-trim) ")
  2. After loosening the mounting bolt, then remove the third row seat belt upper anchor (A). Tightening torque: 39.2 ~ 53.9 N.m (4.0 ~ 5.5 kgf.m, 28.8 ~ 39.8 lb-ft)
  3. After loosening the mounting bolt, then remove the third row seat belt webbing guide (A).
  4. After loosening the mounting bolt, then remove the third row seat belt retractor (A). Tightening torque: 39.2 ~ 53.9 N.m (4.0 ~ 5.5 kgf.m, 28.9 ~ 39.8 lb-ft)
  5. Install in the reverse order of removal. Information Make sure the connector is plugged in properly. Replace any damaged clips.

Scheme 26

Scheme 26: Component Location
Scheme 26: Component Location

Replacement

CAUTIONWhen installing the belt, make sure not to damage the retractor.

Scheme 27

Scheme 27
Scheme 27

Scheme 28

Scheme 28
Scheme 28
  1. Remove the second row seat back cover [LH]. (Refer to " «REAR SEAT BACK COVER»(/hyundai/santa-fe/iii-2012-2016/remont/seats/#rear-seat) ")
  2. Loosen the rear center seat belt lower anchor mounting bolt (A). Tightening torque: 39.2 ~ 53.9 N.m (4.0 ~ 5.5 kgf.m, 28.8 ~ 39.8 lb-ft)
  3. After loosening the mounting nut (B), then remove the rear center seat belt retractor (A). Tightening torque: 39.2 ~ 53.9 N.m (4.0 ~ 5.5 kgf.m, 28.8 ~ 39.8 lb-ft)
  4. Install in the reverse order of removal. Information Replace any damaged clips.

Scheme 29

Scheme 29: Second Row Seat Belt Buckle
Scheme 29: Second Row Seat Belt Buckle

Scheme 30

Scheme 30: Third Row Seat Belt Buckle
Scheme 30: Third Row Seat Belt Buckle

Second Row Seat Belt Buckle

Information

  1. Before removing the second row seat assembly [LH/RH], first remove the second row center seat belt buckle (A) and seat assembly [RH](B).

Scheme 31

Scheme 31
Scheme 31
  1. Place the second row seat assembly [LH] to the rear and second row seat assembly [RH] to the front. (Refer to " «REAR SEAT ASSEMBLY»(/hyundai/santa-fe/iii-2012-2016/remont/seats/#rear-seat) ")
  2. Separate the second row seat belt buckle and second row seat assembly [LH] by removing the mounting bolt (C).

Scheme 32

Scheme 32: (LH)
Scheme 32: (LH)

Scheme 33

Scheme 33
Scheme 33
  1. Remove the second row seat assembly [LH]. (Refer to " «REAR SEAT ASSEMBLY»(/hyundai/santa-fe/iii-2012-2016/remont/seats/#rear-seat) ")
  2. After loosening the mounting bolt (A), then remove the second row seat belt buckle [LH] (B). Tightening torque: 39.2 ~ 53.9 N.m (4.0 ~ 5.5 kgf.m, 28.8 ~ 39.8 lb-ft)
  3. Install in the reverse order of removal.

Scheme 34

Scheme 34: (Center)
Scheme 34: (Center)
  1. Remove the second row seat assembly [RH]. (Refer to " «REAR SEAT ASSEMBLY»(/hyundai/santa-fe/iii-2012-2016/remont/seats/#rear-seat) ")
  2. After loosening the mounting nuts, then remove the second row center seat belt buckle rail (A). Tightening torque: 39.2 ~ 53.9 N.m (4.0 ~ 5.5 kgf.m, 28.8 ~ 39.8 lb-ft)
  3. Install in the reverse order of removal.

Scheme 35

Scheme 35: (RH)
Scheme 35: (RH)

Scheme 36

Scheme 36
Scheme 36
  1. Remove the second row seat assembly [RH]. (Refer to " «REAR SEAT ASSEMBLY»(/hyundai/santa-fe/iii-2012-2016/remont/seats/#rear-seat) ")
  2. After loosening the mounting screw, then remove the rear seat shield inner cover (A).
  3. After loosening the mounting bolt (A), then remove the second row seat belt buckle [RH] (B). Tightening torque: 39.2 ~ 53.9 N.m (4.0 ~ 5.5 kgf.m, 28.8 ~ 39.8 lb-ft)
  4. Install in the reverse order of removal.

Scheme 37

Scheme 37: (LH)
Scheme 37: (LH)
  1. Remove the third row seat assembly [LH]. (Refer to " «REAR SEAT ASSEMBLY»(/hyundai/santa-fe/iii-2012-2016/remont/seats/#rear-seat) ")
  2. After loosening the mounting bolt, then remove the third row seat belt buckle [LH] (A). Tightening torque: 39.2 ~ 53.9 N.m (4.0 ~ 5.5 kgf.m, 28.9 ~ 39.8 lb-ft)
  3. Install in the reverse order of removal.

Scheme 38

Scheme 38: (RH)
Scheme 38: (RH)
  1. Remove the third row seat assembly [RH]. (Refer to " «REAR SEAT ASSEMBLY»(/hyundai/santa-fe/iii-2012-2016/remont/seats/#rear-seat) ")
  2. After loosening the mounting bolt, then remove the third row seat belt buckle [RH] (A). Tightening torque: 39.2 ~ 53.9 N.m (4.0 ~ 5.5 kgf.m, 28.9 ~ 39.8 lb-ft)
  3. Install in the reverse order of removal.
