Seat Belt Pretensioner Hyundai Santa Fe III

Passive Restraints 10 illustrations ~669 words

Description

The Seat Belt Pretensioners (BPT) are installed inside Center Pillar (LH & RH). When a vehicle crashes with a certain degree of frontal impact, the pretensioner seat belt helps to reduce the severity of injury to the front seat occupants by retracting the seat belt webbing. This prevents the front occupants from thrusting forward and hitting the steering wheel or the instrument panel when the vehicle crashes.

CAUTIONNever attempt to measure the circuit resistance of the Seat Belt Pretensioner (BPT) even if you are using the specified tester. If the circuit resistance is measured with a tester, the pretensioner will be ignited accidentally. This will result in serious personal injury.

Scheme 1

Scheme 1: Components
Scheme 1: Components

Scheme 2

Scheme 2: Removal
Scheme 2: Removal

Scheme 3

Scheme 3
Scheme 3

Scheme 4

Scheme 4
Scheme 4
  1. Disconnect the battery negative cable, and wait for at least three minutes before beginning work.
  2. Left side - Remove the seat belt lower anchor cover (A). After loosening the mounting bolt, then remove the seat belt lower anchor (B). Right side - To remove the locking mechanism (A), using a (-) driver (B) turn it counter clockwise. From the emergency fastening device (EFD) system (C)
  3. Remove the door scuff trim. (Refer to " «DOOR SCUFF TRIM»(/hyundai/santa-fe/iii-2012-2016/remont/exteriorinterior-trim/#interior-trim) ")
  4. Remove the center pillar trim (Refer to " «CENTER PILLAR TRIM»(/hyundai/santa-fe/iii-2012-2016/remont/exteriorinterior-trim/#interior-trim) ")
  5. Remove the upper anchor bolt.
  6. Loosen the seat belt pretensioner mounting bolts (A, B) and remove the seat belt pretensioner.
  7. Disconnect the seat belt pretensioner connector (C).

Scheme 5

Scheme 5: Installation
Scheme 5: Installation

Scheme 6

Scheme 6
Scheme 6
  1. Remove the ignition key from the vehicle.
  2. Disconnect the battery negative cable and wait for at least three minutes.
  3. Connect the seat belt pretensioner (BPT) connector (C).
  4. Install the seat belt pretensioner with a bolts (A, B). Tightening torque Bolt B: 39.2 ~ 53.9 N.m (4.0 ~ 5.5 kgf.m, 28.9 ~ 39.8 lb-ft)
  5. Install the upper anchor bolts. Tightening torque: 39.2 ~ 53.9 N.m (4.0 ~ 5.5 kgf.m, 28.9 ~ 39.8 lb-ft)
  6. Install the center pillar trim (Refer to " «CENTER PILLAR TRIM»(/hyundai/santa-fe/iii-2012-2016/remont/exteriorinterior-trim/#interior-trim) ")
  7. Install the door scuff trim. (Refer to " «DOOR SCUFF TRIM»(/hyundai/santa-fe/iii-2012-2016/remont/exteriorinterior-trim/#interior-trim) ")
  8. Left side - Install the lower anchor bolts. Tightening torque: 39.2 ~ 53.9 N.m (4.0 ~ 5.5 kgf.m, 28.9 ~ 39.8 lb-ft) Right side - Insert the seat belt to the Emergency fastening device (A). NOTE: Make sure the lock pin is connected in properly.
  9. Reconnect the battery negative cable.
  10. After installing the seat belt pretensioner, confirm proper system operation: Turn the ignition switch ON; the SRS indicator light should be turned on for about six seconds and then go off.

The Emergency Fastening Device (EFD) operates as well as the belt pretensioner at the same time, if it gets into its deploy condition after a collision. It is located near the anchor on the front seat and it is an equipment to make up for the existing short stroke. The front seat belt EFD is an auxiliary equipment to prevent the driver and passenger from breaking away doubly as the seat belt is pulled towards the anchor side after a collision.

CAUTIONNever measure resistance of EFD directly, current of measuring device may cause unexpected airbag deploy.

Scheme 7

Scheme 7: Components
Scheme 7: Components

Scheme 8

Scheme 8: Removal
Scheme 8: Removal

Scheme 9

Scheme 9
Scheme 9
  1. Disconnect the battery negative cable, and wait for at least three minutes before beginning work.
  2. To remove the locking mechanism (A), using a (-) driver (B) turn it counter clockwise. From the emergency fastening device (EFD) system (C).
  3. Remove the door scuff trim. (Refer to " «DOOR SCUFF TRIM»(/hyundai/santa-fe/iii-2012-2016/remont/exteriorinterior-trim/#interior-trim) ")
  4. Remove the center pillar trim. (Refer to " «CENTER PILLAR TRIM»(/hyundai/santa-fe/iii-2012-2016/remont/exteriorinterior-trim/#interior-trim) ")
  5. Disconnect the EFD connector (A).
  6. Loosen the EFD mounting bolt (B) and remove the anchor pretensioner.

Scheme 10

Scheme 10: Installation
Scheme 10: Installation
  1. Remove ignition key from the vehicle.
  2. Disconnect the negative (-) cable from battery and wait for at least three minutes.
  3. Install the EFD with a bolt. Tightening torque: 39.2 ~ 53.9 N.m (4.0 ~ 5.5 kgf.m, 28.9 ~ 39.8 lb-ft)
  4. Connect the EFD connector.
  5. Install the center pillar trim. (Refer to " «CENTER PILLAR TRIM»(/hyundai/santa-fe/iii-2012-2016/remont/exteriorinterior-trim/#interior-trim) ")
  6. Install the door scuff trim. (Refer to " «DOOR SCUFF TRIM»(/hyundai/santa-fe/iii-2012-2016/remont/exteriorinterior-trim/#interior-trim) ")
  7. Insert the seat belt to the EFD (A). NOTE: Make sure the lock pin is connected in properly.
  8. Reconnect the battery negative cable.
  9. After installing the EFD, confirm proper system operation: Turn the ignition switch ON; the SRS indicator light should be turned on for about six seconds and then go off.
