Rear Wiper/washer Hyundai Santa Fe III

Scheme 29

Scheme 30

Scheme 31

1. Remove the connector from the rear wiper motor.
2. Connect battery positive (+) and negative (-) cables to terminals 2 and 1 respectively.
3. Check that the motor operates normally. Replace the motor if it operates abnormally. No. Description 1 Ground 2 Rear wiper motor (+) 3 Parking

Scheme 32

1. Operate the motor at low speed using the stalk control.
2. Stop the motor operation anywhere except at the off position by disconnecting terminal 3.
3. Connect the positive (+) lead from the battery to terminal 3 and the negative (-) lead to terminal 1.
4. Check that the motor stops running at the off position.

Scheme 33

Scheme 34

Scheme 35

Scheme 36

Scheme 37

1. Detach the rear wiper cap (A).
2. Remove the rear wiper arm & blade (A) after removing rear wiper HEX nut (B).
3. Remove the rear wiper cap & pad (A).
4. Remove the cover (B) after loosening a rear wiper nut (A).
5. Remove the tailgate trim after opening the tailgate. Refer to «TAIL GATE TRIM»(/hyundai/santa-fe/iii-2012-2016/remont/exterior-body-panels/#tail-gate) .
6. Disconnect the rear wiper motor connector (A) then remove the rear wiper motor (B) after loosening bolts (2EA).

Scheme 38

1. Install the rear wiper motor assembly. Tightening torque Nut: 6.9 ~ 9.8 N.m (0.7 ~ 1.0 kgf.m, 5.0 ~ 7.2 lbf-ft)
2. Install the tailgate trim.
3. Install the rear wiper arm and rear wiper cap. Tightening torque Nut (B): 6.9 ~ 10.8 N.m (0.7 ~ 1.1 kgf.m, 5.0 ~ 8.0 lbf-ft)
4. Install the rear wiper arm cap after tightening the nut. Tightening torque Bolt: 13.7 ~ 16.7 N.m (1.4 ~ 1.7 kgf.m, 10.1 ~ 12.3 lbf-ft)
5. Set the rear wiper blade and to the lowest defogger heat line and tailgate glass.

Scheme 39

1. Check for continuity between the terminals while operating the wiper and washer switch. If it is not normal condition, replace wiper and wiper switch.

Scheme 40

Scheme 41

Scheme 42

Scheme 43

1. With the washer motor connected to the reservoir tank, fill the reservoir tank with water. NOTE: Before filling the reservoir tank with water, check the filter for foreign material or contamination. if necessary, clean the filter.
2. Remove the front bumper cover. Refer to «FRONT BUMPER COVER»(/hyundai/santa-fe/iii-2012-2016/remont/exterior-body-panels/#front-bumper-grille) .
3. Connect positive (+) and negative (-) battery cables to terminals 3 and 2 respectively to see that the washer motor runs and water is pumped.
4. Check that the motor operates normally. Replace the motor if it operates abnormally. No. Description 1 Ground 2 Windshield washer (+) 3 Rear washer (+)
