Engine Control System - G3.5 DOHC: Specifications Hyundai Santa Fe II facelift

Testing & Diagnostics 33 illustrations ~233 words

Specification

Throttle Angle (°)Output Voltage (V)
TPS1TPS2
00.05.0
100.54.5
200.94.1
301.43.6
401.83.2
502.32.7
602.72.3
703.21.8
803.61.4
904.10.9
1004.50.5
1105.00.0

THROTTLE POSITION SENSOR SPECIFICATIONS

Scheme 172

Scheme 172
Scheme 172
ItemSensor Resistance (kohms)
TPS13.6 ~ 6.0 [20°C (68°F)]
TPS22.7 ~ 4.1 [20°C (68°F)]

THROTTLE POSITION SENSOR SPECIFICATIONS

ItemSpecification
Coil Resistance (ohms)1.275 ~ 1.725 [20°C (68°F)]

ETC MOTOR SPECIFICATIONS

Scheme 173

Scheme 173: Circuit Diagram
Scheme 173: Circuit Diagram
Pressure (kPa)Output Voltage (V)
10.00.50
55.02.21
100.03.93
115.04.50

BAROMETRIC PRESSURE SENSOR OUTPUT VOLTAGE SPECIFICATIONS

Scheme 174

Scheme 174
Scheme 174

Scheme 175

Scheme 175: Circuit Diagram
Scheme 175: Circuit Diagram
TemperatureResistance (kohms)
°C°F
404040.93 ~ 48.35
20413.89 ~ 16.03
0325.38 ~ 6.09
10503.48 ~ 3.90
20682.31 ~ 2.57
401041.08 ~ 1.21
601400.54 ~ 0.66
801760.29 ~ 0.34

INTAKE AIR TEMPERATURE SENSOR SPECIFICATIONS

Scheme 176

Scheme 176: Circuit Diagram
Scheme 176: Circuit Diagram
Pressure (kPa)Output Voltage (V)
20.00.79
46.661.84
101.324.0

MANIFOLD ABSOLUTE PRESSURE SENSOR SPECIFICATIONS

Scheme 177

Scheme 177
Scheme 177

Scheme 178

Scheme 178: Circuit Diagram
Scheme 178: Circuit Diagram
TemperatureResistance (kohms)
°C°F
404048.14
20414.13 ~ 16.83
0325.79
20682.31 ~ 2.59
401041.15
601400.59
801760.32

ENGINE COOLANT TEMPERATURE SENSOR SPECIFICATIONS

Scheme 179

Scheme 179: Circuit Diagram
Scheme 179: Circuit Diagram
ItemSpecification
Coil Resistance (ohms)774 ~ 946 [20°C (68°F)]
Air Gap (mm)0.5 ~ 1.5

CRANKSHAFT POSITION SENSOR SPECIFICATIONS

Scheme 180

Scheme 180: Wave Form
Scheme 180: Wave Form

Scheme 181

Scheme 181: Circuit Diagram
Scheme 181: Circuit Diagram
ItemSpecification
Output Voltage (V)High: 5.0V
Low: 0.7V
Air Gap (mm)0.5 ~ 1.5

CAMSHAFT POSITION SENSOR SPECIFICATIONS

Scheme 182

Scheme 182: Wave Form
Scheme 182: Wave Form

Scheme 183

Scheme 183: Circuit Diagram
Scheme 183: Circuit Diagram
ItemSpecification
Capacitance (pF)950 ~ 1, 350

KNOCK SENSOR SPECIFICATIONS

Scheme 184

Scheme 184: Circuit Diagram
Scheme 184: Circuit Diagram

Scheme 185

Scheme 185: Removal
Scheme 185: Removal

Scheme 186

Scheme 186
Scheme 186

Scheme 187

Scheme 187
Scheme 187

Scheme 188

Scheme 188
Scheme 188
  1. Turn the ignition switch OFF and disconnect the battery negative (-) cable.
  2. Disconnect the knock sensor connector (A). [Bank 1] [Bank 2]
  3. Remove the intake manifold. (Refer to «INTAKE AND EXHAUST SYSTEM»(/hyundai/santa-fe/ii-facelift-2010-2012/remont/exhaust/#intake-and-exhaust-system-g35-dohc) .)
  4. Remove the installation bolt (A), and then remove the sensor from the cylinder block. [Bank 1] [Bank 2]
A/F Ratio (lambda)Output Voltage (V)
RICHMin. 0.8
LEANMax. 0.1

HEATED OXYGEN SENSOR SPECIFICATIONS

ItemSpecification
Heater Resistance (ohms)3.3 ~ 4.1[20°C (68°F)]

HEATED OXYGEN SENSOR SPECIFICATIONS

Scheme 189

Scheme 189: Wave Form
Scheme 189: Wave Form

Scheme 190

Scheme 190
Scheme 190

Scheme 191

Scheme 191: Circuit Diagram
Scheme 191: Circuit Diagram
TemperatureResistance (kohms)
°C°F
404052.15
20416.52
0326.0
20682.45
401041.11
601400.54
801760.29

CVVT OIL TEMPERATURE SENSOR SPECIFICATIONS

Scheme 192

Scheme 192: Circuit Diagram
Scheme 192: Circuit Diagram
Accelerator PositionOutput Voltage (V)
APS1APS2
C.T0.7 ~ 0.80.29 ~ 0.46
W.O.T3.85 ~ 4.351.93 ~ 2.18

ACCELERATOR POSITION SENSOR SPECIFICATIONS

Scheme 193

Scheme 193
Scheme 193

Scheme 194

Scheme 194: Circuit Diagram
Scheme 194: Circuit Diagram
Pressure (kPa)Output Voltage (V)
3.754.4 ~ 4.6
01.4 ~ 1.6
+1.250.4 ~ 0.6

FUEL TANK PRESSURE SENSOR SPECIFICATIONS

Scheme 195

Scheme 195
Scheme 195

Scheme 196

Scheme 196: Circuit Diagram
Scheme 196: Circuit Diagram
ItemSpecification
Coil Resistance (ohms)[20°C (68°F)]

VARIABLE CHARGE MOTION POSITION SENSOR SPECIFICATIONS

Valve Angle (°)Output Voltage (V)
Mechanical stop04.45 ~ 4.55
Intake Close73.24 ~ 4.36
Intake Open630.04 ~ 1.76
Mechanical stop700.45 ~ 0.55

VARIABLE CHARGE MOTION POSITION SENSOR SPECIFICATIONS

Scheme 197

Scheme 197: Wave Form
Scheme 197: Wave Form

Scheme 198

Scheme 198
Scheme 198

Scheme 199

Scheme 199: Circuit Diagram
Scheme 199: Circuit Diagram
ItemSpecification
Coil Resistance (ohms)13.8 ~ 15.2 [20°C (68°F)]

INJECTOR SPECIFICATIONS

Scheme 200

Scheme 200: Circuit Diagram
Scheme 200: Circuit Diagram
ItemSpecification
Coil Resistance (ohms)22.0 ~ 26.0 [20°C (68°F)]

PURGE CONTROL SOLENOID VALVE SPECIFICATIONS

Scheme 201

Scheme 201: Circuit Diagram
Scheme 201: Circuit Diagram
ItemSpecification
Coil Resistance (ohms)9.4 ~ 10.4 [20°C (68°F)]

CVVT OIL CONTROL VALVE SPECIFICATIONS

Scheme 202

Scheme 202: Circuit Diagram
Scheme 202: Circuit Diagram
ItemSpecification
Coil Resistance (ohms)30.0 ~ 35.0 [20°C (68°F)]

VARIABLE INTAKE SOLENOID VALVE SPECIFICATIONS

Scheme 203

Scheme 203: Circuit Diagram
Scheme 203: Circuit Diagram
ItemSpecification
Coil Resistance (ohms)19.8 ~ 21.8 [20°C (68°F)

CANISTER CLOSE VALVE SPECIFICATIONS

Scheme 204

Scheme 204: Circuit Diagram
Scheme 204: Circuit Diagram
