Crankcase Emission Control System: Removal & Installation Hyundai Santa Fe II facelift

Testing & Diagnostics 3 illustrations

Removal

  1. Disconnect the vapor hose (A).
  2. Remove the PCV valve (B).

Scheme 14

Scheme 14: [2.4 DOHC]
Scheme 14: [2.4 DOHC]

Scheme 15

Scheme 15: [3.5 V6]
Scheme 15: [3.5 V6]

Scheme 16

Scheme 16: Inspection
Scheme 16: Inspection
  1. Insert a thin stick (A) into the PCV valve (B) from the threaded side to check that the plunger movement. NOTE: If the plunger does not move (PCV valve is clogged), clean or replace the valve.

Installation

  1. Installation is reverse of removal. PCV Valve installation: 7.8 ~ 11.8 N.m (0.8 ~ 1.2 kgf.m, 5.8 ~ 8.7 lb-ft)
