Engine Control System - G2.4 DOHC: Specifications Hyundai Santa Fe II facelift

Testing & Diagnostics 20 illustrations ~179 words

Specifications

[Throttle Position Sensor (TPS)]

Throttle Angle(°)Output Voltage (V)
TPS1TPS2
00.05.0
100.484.52
200.954.05
301.433.57
401.903.10
502.382.62
602.862.14
703.331.67
803.811.19
904.290.71
1004.760.24
1055.00
C.T (6 ~ 15°)0.29 ~ 0.714.29 ~ 4.71
W.O.T (93 ~ 102°)4.43 ~ 4.860.14 ~ 0.57

THROTTLE POSITION SENSOR SPECIFICATIONS

Scheme 62

Scheme 62
Scheme 62
ItemSensor Resistance (kohms)
TPS10.875 ~ 1.625 [20°C (68°F)]
TPS20.875 ~ 1.625 [20°C (68°F)]

RESISTANCE SPECIFICATIONS

[ETC Motor]

ItemSpecification
Coil Resistance (ohms)1.2 ~ 1.8 [20°C (68°F)]

RESISTANCE SPECIFICATIONS

Scheme 63

Scheme 63: Circuit Diagram
Scheme 63: Circuit Diagram
Pressure (kPa)Output Voltage (V)
20.00.79
46.71.84
101.34.0

MANIFOLD ABSOLUTE PRESSURE SENSOR SPECIFICATIONS

Scheme 64

Scheme 64
Scheme 64

Scheme 65

Scheme 65: Circuit Diagram
Scheme 65: Circuit Diagram
Temperature [°C(°F)]Resistance (kohms)
40(-40)40.93 ~ 48.35
20(-4)13.89 ~ 16.03
0 (32)5.38 ~ 6.09
10 (50)3.48 ~ 3.90
20 (68)2.31 ~ 2.57
40 (104)1.08 ~ 1.21
50 (122)1.56 ~ 1.74
60 (140)0.54 ~ 0.62
80 (176)0.29 ~ 0.34

RESISTANCE SPECIFICATIONS

Scheme 66

Scheme 66: Circuit Diagram
Scheme 66: Circuit Diagram
TemperatureResistance (kohms)
°C°F
404048.14
20414.13 ~ 16.83
0325.79
20682.31 ~ 2.59
401041.15
601400.59
801760.32

RESISTANCE SPECIFICATIONS

Scheme 67

Scheme 67: Circuit Diagram
Scheme 67: Circuit Diagram
ItemSpecification
Capacitance (pF)850 ~ 1, 150

RESISTANCE SPECIFICATIONS

Scheme 68

Scheme 68: Circuit Diagram
Scheme 68: Circuit Diagram

Scheme 69

Scheme 69: Removal
Scheme 69: Removal

Scheme 70

Scheme 70
Scheme 70
  1. Turn the ignition switch OFF and disconnect the battery negative (-) cable.
  2. Drain the engine coolant. (Refer to «COOLING SYSTEM»(ref-492144).)
  3. Remove the radiator upper hose. (Refer to «REPAIR PROCEDURES»(ref-492144-S33874351622012080100000).)
  4. Disconnect the knock sensor connector (A).
  5. Remove the intake manifold. (Refer to «INTAKE AND EXHAUST SYSTEM»(/hyundai/santa-fe/ii-facelift-2010-2012/remont/exhaust/#intake-and-exhaust-system-g24-dohc) .)
  6. Remove the installation bolt (A), and then remove the sensor from the cylinder block.

HO2S [Bank 1/Sensor 1]

ItemSpecification
Heater Resistance (ohms)2.5 ~ 4.0 [20°C (68°F)]

RESISTANCE SPECIFICATIONS

HO2S [Bank 1/Sensor 2]

A/F Ratio (lambda)Output Voltage (V)
RICHApprox. 0.9
LEANApprox. 0.04

VOLTAGE SPECIFICATIONS

ItemSpecification
Heater Resistance (ohms)3.3 ~ 4.1ohms[21°C (69.8°F)]

RESISTANCE SPECIFICATIONS

Scheme 71

Scheme 71: Circuit Diagram
Scheme 71: Circuit Diagram
Accelerator PositionOutput Voltage (V)
APS1APS2
C.T0.7 ~ 0.80.29 ~ 0.46
W.O.T3.85 ~ 4.351.93 ~ 2.18

RESISTANCE SPECIFICATIONS

Scheme 72

Scheme 72
Scheme 72

Scheme 73

Scheme 73: Circuit Diagram
Scheme 73: Circuit Diagram
Pressure (kPa)Output Voltage (V)
3.754.4 ~ 4.6
01.4 ~ 1.6
+1.250.4 ~ 0.6

VOLTAGE SPECIFICATIONS

Scheme 74

Scheme 74
Scheme 74

Scheme 75

Scheme 75: Circuit Diagram
Scheme 75: Circuit Diagram
ItemSpecification
Coil Resistance (ohms)13.8 ~ 15.2 [20°C (68°F)]

RESISTANCE SPECIFICATIONS

Scheme 76

Scheme 76: Circuit Diagram
Scheme 76: Circuit Diagram
ItemSpecification
Coil Resistance (ohms)19.0 ~ 22.0 [20°C (68°F)]

RESISTANCE SPECIFICATIONS

Scheme 77

Scheme 77: Circuit Diagram
Scheme 77: Circuit Diagram
ItemSpecification
Coil Resistance (ohms)6.9 ~ 7.9 [20°C (68°F)]

RESISTANCE SPECIFICATIONS

Scheme 78

Scheme 78: Circuit Diagram
Scheme 78: Circuit Diagram
ItemSpecification
Coil resistance (ohms)30.0 ~ 35.0 [20°C (68°F)]

RESISTANCE SPECIFICATIONS

Scheme 79

Scheme 79: Circuit Diagram
Scheme 79: Circuit Diagram
ItemSpecification
Coil Resistance (ohms)19.8 ~ 21.8 [20°C (68°F)

RESISTANCE SPECIFICATIONS

Scheme 80

Scheme 80: Circuit Diagram
Scheme 80: Circuit Diagram

Motor

ItemSpecification
Coil Resistance (ohms)3.4 ~ 4.4 [20°C (68°F)]

COIL RESISTANCE SPECIFICATIONS

Position sensor

ItemSpecification
Coil Resistance (kohms)3.44 ~ 5.16 [20°C (68°F)]

RESISTANCE SPECIFICATIONS

Scheme 81

Scheme 81: Circuit diagram
Scheme 81: Circuit diagram
