Automatic Transaxle Control System - G3.5 DOHC: Specifications Hyundai Santa Fe II facelift

Automatic Trans 16 illustrations ~642 words

Specifications

ItemSpecification
TypeHall Effect Sensor, 2pins (Power: 9V, Signal)
Operation condition40 ~150°C [-40 ~ 302°F]
Sensor length52.7~52.9mm (2.0748~2.0827in.)
Air gap0.95~1.65mm (0.0374~0.0650in.)

INPUT SPEED SENSOR SPECIFICATIONS

Scheme 98

Scheme 98: Removal

Scheme 99

Scheme 99

Scheme 100

Scheme 100

Scheme 101

Scheme 101

Scheme 102

Scheme 102

Scheme 103

Scheme 103
  1. Remove the battery and the battery tray. (Refer to «REPAIR PROCEDURES»(ref-492234-S22749353292012080100000).)
  2. Remove the under cover (A).
  3. Replace new gasket and the plug after draining the automatic transaxle fluid by removing the drain plug. (Refer to «AUTOMATIC TRANSAXLE SYSTEM»(ref-492238).)
  4. Remove the valve body cover (A) and eyebolt (B). Tightening torque: 9.8 ~ 11.8 N.m (1.0 ~ 1.2 kgf.m, 7.2 ~ 8.7 lb-ft) 34.3 ~ 44.1 N.m (3.5 ~ 4.5 kgf.m, 25.3 ~32.6 lb-ft) CAUTION: The gasket of the eyebolt use new one. NOTE: Remove installation bolts in the engine room first and then remove others under the vehicle.
  5. Remove the plate and the detend spring (A) after removing the bolt. Tightening torque: 24.5 ~ 35.3 N.m (2.5 ~ 3.6 kgf.m, 18.1 ~ 26.0 lb-ft)
  6. Remove the bolt (3ea) after disconnecting the solenoid valve connector (A) and the oil temperature sensor connector (B). Tightening torque: 9.8 ~ 11.8 N.m (1.0 ~ 1.2 kgf.m, 7.2 ~ 8.7 lb-ft) CAUTION: Be careful not to damage the harness lock connector.
  7. Remove the valve body assembly (A). Tightening torque: 9.8 ~ 11.8 N.m (1.0 ~ 1.2 kgf.m, 7.2 ~ 8.7 lb-ft)
  8. Disconnect the input & output speed sensor connector (A).
  9. Remove the input & output speed sensor (B) after removing the bolts (2ea). Tightening torque: 9.8 ~ 11.8 N.m (1.0 ~ 1.2 kgf.m, 7.2 ~ 8.7 lb-ft)
ItemSpecification
TypeHall Effect Sensor, 2pins (Power: 9V, Signal)
Operation condition40 ~150°C [-40 ~ 302°F]
Sensor length33.6~33.8mm (1.3228~1.3307in.)
Air gap0.25~1.9mm (0.0098~0.0748in.)

OUTPUT SPEED SENSOR SPECIFICATIONS

Scheme 104

Scheme 104: Removal

Scheme 105

Scheme 105

Scheme 106

Scheme 106

Scheme 107

Scheme 107

Scheme 108

Scheme 108

Scheme 109

Scheme 109
  1. Remove the battery and the battery tray. (Refer to «REPAIR PROCEDURES»(ref-492234-S22749353292012080100000).)
  2. Remove the under cover (A).
  3. Replace new gasket and the plug after draining the automatic transaxle fluid by removing the drain plug. (Refer to «AUTOMATIC TRANSAXLE SYSTEM»(ref-492238).)
  4. Remove the valve body cover (A) and eyebolt (B). Tightening torque: 9.8 ~ 11.8 N.m (1.0 ~ 1.2 kgf.m, 7.2 ~ 8.7 lb-ft) 34.3 ~ 44.1 N.m (3.5 ~ 4.5 kgf.m, 25.3 ~32.6 lb-ft) CAUTION: The gasket of the eyebolt use new one. NOTE: Remove installation bolts in the engine room first and then remove others under the vehicle.
  5. Remove the plate and the detend spring (A) after removing the bolt. Tightening torque: 24.5 ~ 35.3 N.m (2.5 ~ 3.6 kgf.m, 18.1 ~ 26.0 lb-ft)
  6. Remove the bolt (3ea) after disconnecting the solenoid valve connector (A) and the oil temperature sensor connector (B). Tightening torque: 9.8 ~ 11.8 N.m (1.0 ~ 1.2 kgf.m, 7.2 ~ 8.7 lb-ft) CAUTION: Be careful not to damage the harness lock connector.
  7. Remove the valve body assembly (A). Tightening torque: 9.8 ~ 11.8 N.m (1.0 ~ 1.2 kgf.m, 7.2 ~ 8.7 lb-ft)
  8. Disconnect the input & output speed sensor connector (A).
  9. Remove the input & output speed sensor (B) after removing the bolts (2ea). Tightening torque: 9.8 ~ 11.8 N.m (1.0 ~ 1.2 kgf.m, 7.2 ~ 8.7 lb-ft)

Specification

ItemSpecification
TypeNegative Thermal Coefficient Type
Operation temperature40~165°C [-40~329°F]
Resistance4.81kohms~39 ohms
FailsafeOil temperature set to default value [80°C (176°F)]

TRANSAXLE OIL TEMPERATURE SENSOR SPECIFICATIONS

Scheme 110

Scheme 110: Removal

Scheme 111

Scheme 111

Scheme 112

Scheme 112

Scheme 113

Scheme 113
  1. Remove the battery and the battery tray. (Refer to «REPAIR PROCEDURES»(ref-492234-S22749353292012080100000).)
  2. Remove the under cover (A).
  3. Replace new gasket and the plug after draining the automatic transaxle fluid by removing the drain plug. (Refer to «AUTOMATIC TRANSAXLE SYSTEM»(ref-492238).)
  4. Remove the valve body cover (A) and eyebolt (B). Tightening torque: 9.8 ~ 11.8 N.m (1.0 ~ 1.2 kgf.m, 7.2 ~ 8.7 lb-ft) 34.3 ~ 44.1 N.m (3.5 ~ 4.5 kgf.m, 25.3 ~32.6 lb-ft) CAUTION: The gasket of the eyebolt use new one. NOTE: Remove installation bolts in the engine room first and then remove others under the vehicle.
  5. Disconnect the oil temperature sensor connector (A).
  6. Remove the oil temperature sensor (A) after removing a bolt. Tightening torque: 9.8 ~ 11.8 N.m (1.0 ~ 1.2 kgf.m, 7.2 ~ 8.7 lb-ft) CAUTION: Be careful not to damage the harness lock connector.
