Automatic Transaxle Control System - G3.5 DOHC: Overview Hyundai Santa Fe II facelift

Automatic Trans 9 illustrations ~318 words

Scheme 114

Scheme 114: Components Location

Scheme 115

Scheme 115: Components

Scheme 116

Scheme 116: Removal

Scheme 117

Scheme 117

Scheme 118

Scheme 118

Scheme 119

Scheme 119
  1. Remove the center console assembly. (Refer to «INTERIOR»(ref-492145) .)
  2. Disconnect sports mode connector (A).
  3. Take off the clip (A) and the clamp (B) and then remove the shift cable (C).
  4. Remove the shift lever assembly (B) by removing the four bolts (A). Tightening torque: 8.8 ~ 13.7 N.m (0.9 ~ 1.4 kgf.m, 6.5 ~ 10.1 lb-ft)
  5. Remove the nut connected with manual lever on the automatic transaxle assembly and a clip.
  6. Remove the shift cable assembly in the vehicle after removing the nuts (B) and the retainer (A). Tightening torque: 7.8 ~ 11.8 N.m (0.8 ~ 1.2 kgf.m, 5.8~8.7 lb-ft)

Description

  1. Integrated one unit for input & output speed sensor
  2. Differential current type (low: 7mA, high: 14mA)
  3. Failsafe: 4th gear hold (D), 2nd ~ 4th manual shift (S)
  1. Integrated one unit for input & output speed sensor
  2. Differential current type (low: 7mA, high: 14mA)
  3. Failsafe: 4th gear hold (D), 2nd ~ 4th manual shift (S)
ItemSpecification
TypeCombination of output signals from 4 terminals
Power supply12V
Range detection7-position (P, R, N, D, X, Y, Z)
Failsafe1st, 2nd gear is prohibited.

INHIBITOR SWITCH SPECIFICATIONS

Scheme 120

Scheme 120: Removal

Scheme 121

Scheme 121

Scheme 122

Scheme 122
  1. Set room side lever and T/M side lever to "N" position.
  2. Remove the battery and the battery tray. (Refer to «REPAIR PROCEDURES»(ref-492234-S22749353292012080100000) .)
  3. Remove the air cleaner assembly. (Refer to «INTAKE MANIFOLD»(ref-492230-S08768529242012080100000) .)
  4. Remove the shift cable mounting nut (B). Tightening torque: 7.8 ~ 11.8 N.m (0.8 ~ 1.2 kgf.m, 5.8 ~ 8.7 lb-ft)
  5. Disconnect the inhibitor switch connector (A).
  6. Remove the manual control lever (A) and the washer (B) after removing a nut (C). CAUTION: When installing, fix the manual control lever and the inhibitor switch with ø5mm (0.1969in.) fixing jig. And then tighten the inhibitor assembly mounting bolts.
  7. Remove the inhibitor assembly (A) after removing the bolts (2ea). Tightening torque: 9.8 ~ 11.8 N.m (1.0 ~ 1.2 kgf.m, 7.2 ~ 8.7 lb-ft) CAUTION: When installing, tighten the inhibitor assembly mounting bolt lightly.
