Specification

Item	Specification
Type	Hall Effect Sensor, 2pins (Power: 9V, Signal)
Operation condition	40 ~150°C [-40 ~ 302°F]
Sensor length	52.7~52.9mm (2.0748~2.0827in.)
Air gap	0.95~1.65mm (0.0374~0.0650in.)

SPEED SENSOR SPECIFICATION

Scheme 1

Scheme 1: Removal

Scheme 2

Scheme 3

Scheme 4

Scheme 5

Scheme 6

Remove the battery and the battery tray. (Refer to " «Charging System»(ref-492154) ".)
Remove the under cover (A).
Replace new gasket and the plug after draining the automatic transaxle fluid by removing the drain plug. (Refer to " «Automatic Transaxle System»(ref-492151) ".)
Remove the valve body cover (A) and eyebolt (B). Tightening torque: 9.8 ~ 11.8 N.m (1.0 ~ 1.2 kgf.m, 7.2 ~ 8.7 lb-ft) 34.3 ~ 44.1 N.m (3.5 ~ 4.5 kgf.m, 25.3 ~32.6 lb-ft) CAUTION: The gasket of the eyebolt use new one. NOTE: Remove installation bolts in the engine room first and then remove others under the vehicle.
Remove the plate and the detent spring (A) after removing the bolt. Tightening torque: 24.5 ~ 35.3 N.m (2.5 ~ 3.6 kgf.m, 18.1 ~ 26.0 lb-ft)
Remove the bolt (3ea) after disconnecting the solenoid valve connector (A) and the oil temperature sensor connector (B). Tightening torque: 9.8 ~ 11.8 N.m (1.0 ~ 1.2 kgf.m, 7.2 ~ 8.7 lb-ft) CAUTION: Be careful not to damage the harness lock connector.
Remove the valve body assembly (A). Tightening torque: 9.8 ~ 11.8 N.m (1.0 ~ 1.2 kgf.m, 7.2 ~ 8.7 lb-ft)
Disconnect the input & output speed sensor connector (A).
Remove the input & output speed sensor (B) after removing the bolts (2ea). Tightening torque: 9.8 ~ 11.8 N.m (1.0 ~ 1.2 kgf.m, 7.2 ~ 8.7 lb-ft)

Item	Specification
Type	Hall Effect Sensor, 2pins (Power: 9V, Signal)
Operation condition	40 ~150°C [-40 ~ 302°F]
Sensor length	33.6~33.8mm (1.3228~1.3307in.)
Air gap	0.25~1.9mm (0.0098~0.0748in.)

OUTPUT SPEED SENSOR SPECIFICATIONS

Scheme 7

Scheme 7: Removal

Scheme 8

Scheme 9

Scheme 10

Scheme 11

Scheme 12

Remove the battery and the battery tray. (Refer to " «Charging System»(ref-492154) ".)
Remove the under cover (A).
Replace new gasket and the plug after draining the automatic transaxle fluid by removing the drain plug. (Refer to " «Automatic Transaxle System»(ref-492151) ".)
Remove the valve body cover (A) and eyebolt (B). Tightening torque: 9.8 ~ 11.8 N.m (1.0 ~ 1.2 kgf.m, 7.2 ~ 8.7 lb-ft) 34.3 ~ 44.1 N.m (3.5 ~ 4.5 kgf.m, 25.3 ~32.6 lb-ft) CAUTION: The gasket of the eyebolt use new one. NOTE: Remove installation bolts in the engine room first and then remove others under the vehicle.
Remove the plate and the detent spring (A) after removing the bolt. Tightening torque: 24.5 ~ 35.3 N.m (2.5 ~ 3.6 kgf.m, 18.1 ~ 26.0 lb-ft)
Remove the bolt (3ea) after disconnecting the solenoid valve connector (A) and the oil temperature sensor connector (B). Tightening torque: 9.8 ~ 11.8 N.m (1.0 ~ 1.2 kgf.m, 7.2 ~ 8.7 lb-ft) CAUTION: Be careful not to damage the harness lock connector.
Remove the valve body assembly (A). Tightening torque: 9.8 ~ 11.8 N.m (1.0 ~ 1.2 kgf.m, 7.2 ~ 8.7 lb-ft)
Disconnect the input & output speed sensor connector (A).
Remove the input & output speed sensor (B) after removing the bolts (2ea). Tightening torque: 9.8 ~ 11.8 N.m (1.0 ~ 1.2 kgf.m, 7.2 ~ 8.7 lb-ft)

Item	Specification
Type	Negative Thermal Coefficient Type
Operation temperature	40~165°C [-40~329°F]
Resistance	4.81kohms~39 ohms
Failsafe	Oil temperature set to default value [80°C (176°F)]

TRANSAXLE OIL TEMPERATURE SENSOR SPECIFICATION

Scheme 13

Scheme 13: Removal

Scheme 14

Scheme 15

Scheme 16

Remove the battery and the battery tray. (Refer to " «Charging System»(ref-492154) ".)
Remove the under cover (A).
Replace new gasket and the plug after draining the automatic transaxle fluid by removing the drain plug. (Refer to " «Automatic Transaxle System»(ref-492151) ".)
Remove the valve body cover (A) and eyebolt (B). Tightening torque: 9.8 ~ 11.8 N.m (1.0 ~ 1.2 kgf.m, 7.2 ~ 8.7 lb-ft) 34.3 ~ 44.1 N.m (3.5 ~ 4.5 kgf.m, 25.3 ~32.6 lb-ft) CAUTION: The gasket of the eyebolt use new one. NOTE: Remove installation bolts in the engine room first and then remove others under the vehicle.
Disconnect the oil temperature sensor connector (A).
Remove the oil temperature sensor (A) after removing a bolt. Tightening torque: 9.8 ~ 11.8 N.m (1.0 ~ 1.2 kgf.m, 7.2 ~ 8.7 lb-ft) CAUTION: Be careful not to damage the harness lock connector.
