Automatic Transaxle Control System - G2.4 DOHC: Overview Hyundai Santa Fe II facelift

Automatic Trans 9 illustrations ~322 words

Scheme 17

Scheme 17: Components Location

Scheme 18

Scheme 18: Components

Scheme 19

Scheme 19: Removal

Scheme 20

Scheme 20

Scheme 21

Scheme 21

Scheme 22

Scheme 22
  1. Remove the center console assembly. (Refer to " «Interior»(ref-492145) ".)
  2. Disconnect sports mode connector (A).
  3. Take off the clip (A) and the clamp (B) and then remove the shift cable (C).
  4. Remove the shift lever assembly (B) by removing the four bolts (A). Tightening torque: 8.8 ~ 13.7 N.m (0.9 ~ 1.4 kgf.m, 6.5 ~ 10.1 lb-ft)
  5. Remove the nut connected with manual lever on the automatic transaxle assembly and a clip.
  6. Remove the shift cable assembly in the vehicle after removing the nuts (B) and the retainer (A). Tightening torque: 7.8 ~ 11.8 N.m (0.8 ~ 1.2 kgf.m, 5.8~8.7 lb-ft)

Description

  1. Integrated one unit for input & output speed sensor
  2. Differential current type (low: MA high: MA
  3. Failsafe: 4th gear hold (D), 2nd ~ 4th manual shift (S)
  1. Integrated one unit for input & output speed sensor
  2. Differential current type (low: MA high: MA
  3. Failsafe: 4th gear hold (D), 2nd ~ 4th manual shift (S)
ItemSpecification
TypeCombination of output signals from 4 terminals
Power supply12V
Range detection7-position (P, R, N, D, X, Y, Z)
Failsafe1st, 2nd gear is prohibited.

INHIBITOR SWITCH DESCRIPTION CHART

Scheme 23

Scheme 23: Removal

Scheme 24

Scheme 24

Scheme 25

Scheme 25
  1. Set room side lever and T/M side lever to "N" position.
  2. Remove the battery and the battery tray. (Refer to " «Charging System»(ref-492154) ".)
  3. Remove the air cleaner assembly. (Refer to " «Intake Manifold»(ref-492148-S31070692362012080100000) ".)
  4. Remove the shift cable mounting nut (B). Tightening torque: 7.8 ~ 11.8 N.m (0.8 ~ 1.2 kgf.m, 5.8 ~ 8.7 lb-ft)
  5. Disconnect the inhibitor switch connector (A).
  6. Remove the manual control lever (A) and the washer (B) after removing a nut (C). CAUTION: When installing, fix the manual control lever and the inhibitor switch with Ø5mm (0.1969in.) fixing jig. And then tighten the inhibitor assembly mounting bolts.
  7. Remove the inhibitor assembly (A) after removing the bolts (2ea). Tightening torque: 9.8 ~ 11.8 N.m (1.0 ~ 1.2 kgf.m, 7.2 ~ 8.7 lb-ft) CAUTION: When installing, tighten the inhibitor assembly mounting bolt lightly.
