Electrical System
| Item | Specifications | ||
|---|---|---|---|
| Slide, Front/Rear Height | Recline/Cushion/Headrest | ||
| Main Power Seat Position Sensor | Operating Voltage | DC 3.8V ~ 24V | |
| Consumption Current | Type 3mA, Max 7mA | ON: 5.7mA(Recline, Cushion) ON: 4.1mA(Headrest) | |
| Type | Hall sensor | Hall sensor | |
| ON: OFF ratio | 50±15% | 50±10%(Cushion/Headrest) 0.5(Recline) | |
| Continuity current | 100mA | 25mA(Cushion/Headrest) 8mA(Recline) | |
| Main Power Seat Manual SW | Type | Self return | |
| Chattering time | Max 10msec | ||
| Limit SW | Type | Open at the adjustment limit position (Normal Close) | |
| Contact Current | Max 8A | ||
ELECTRICAL SYSTEM SPECIFICATIONS
Mechanical System
| Item | Specifications | ||
|---|---|---|---|
| Main power seat position sensor | Phase Angle | 90° | |
| Full Stroke | Slide | 240 mm | |
| Recline | 66° | ||
| Forward Height | 28 mm | ||
| Backward height | 40 mm | ||
| Cushion extension | 63 mm | ||
MECHANICAL SYSTEM SPECIFICATIONS
Function option
| Item | Slide | Recline | Height | Headrest | IMS | Cushion extension | Easy Access ON/OFF |
|---|---|---|---|---|---|---|---|
| Driver | O | O | O | O | O | O | (1) |
| Assist | O | O | X | O | X | X | X |
| Rear left | O | X | X | X | X | X | O |
| Rear right | O | X | X | O | X | X | O |
| (1) ON/OFF operation is possible using DIS or GDS. | |||||||
| (1) | ON/OFF operation is possible using DIS or GDS. |
FUNCTION OPTION
Scheme 53
Scheme 54
Scheme 55
Scheme 56
Scheme 57
Scheme 58
Scheme 59
Power Seat Module (PSM) For Driver
| Pin | PIN Description | |||
|---|---|---|---|---|
| A Connector | B Connector | C Connector | D Connector | |
| 1 | Cushion Ext Front Motor(IPS) | Power Supply for Load 1 | Slide FRont Limit SW | |
| 2 | FRont Height Up Motor (IPS) | Recline FRont Limit SW | ||
| 3 | Rear Height Down Motor (IPS) | Power Supply for Load 2 | Power source of Sensor | |
| 4 | Recline Front Motor (IPS) | Power ground 1 | CushionEXT Sensor Signal | CAN high line |
| 5 | Slide FRont Motor (IPS) | Power ground 2 | CAN low line | |
| 6 | Cushion Ext Rear Motor(IPS) | Slide Rear Sensor Signal | ||
| 7 | FRont Height Down Motor (IPS) | Back up source in case of Vbat failure IGN1 input | ||
| 8 | Head Rest Up Motor(IPS) | Slide FRont Sensor Signal | Vbat main | |
| 9 | Head Rest Down Motor(IPS) | Rear Height Up Sensor Signal | ||
| 10 | Rear Height Down Motor (IPS) | Power source of Sensor | ||
| 11 | Recline Rear Motor (IPS) | Slide Rear Limit SW | ||
| 12 | Slide Rear Motor (IPS) | Recline Rear Limit SW | ||
| 13 | ||||
| 14 | Head Rest Sensor Signal | |||
| 15 | ||||
| 16 | FRont Height Down Sensor Signal | |||
| 17 | Rear Height Down Sensor Signal | Signal ground | ||
| 18 | Recline Sensor Signal | |||
| 19 | Front Height Up Sensor Signal | |||
| 20 | Sensor GND | |||
PINS DESCRIPTION CHART
Relax Power Seat Module (For Passenger & Rear)
| Pin | PIN Description | |||
|---|---|---|---|---|
| A Connector | B Connector | C Connector | D Connector | |
| 1 | Slide Motor FR Output | Motor Driving Power B+ | Slide RR Limit SW Input | Recline Walk In FR SW Input |
| 2 | Recline Motor FR Output | Recline RR Limit SW Input | Recline Walk In RR SW Input | |
| 3 | Head Rest Motor Up Output | Motor Driving Power B+ | Rear Slide FR Limit SW Input | Leg Support FR Limit SW Input |
| 4 | Rear Slide FR Control Output | Motor Driving Power GND+ | Seat Motor Sensor pwr | Can Hi Input |
| 5 | Rear Leg FR Control Output | Motor driving Power GND+ | Recline Sensor Input | Can Low Input |
| 6 | Slide Motor RR Output | Slide RR Sensor Input | Leg Support RR Limit SW Input | |
| 7 | Recline Motor RR Output | Head Rest Sensor Input | Ign1 Input | |
| 8 | Rear Slide RR Control Output | Slide Sensor FR Input | ECU power Input | |
| 9 | Rear Leg RR Control Output | Local SW (Door Open) Input | Slide FR SW Input | |
| 10 | Headrest Motor Down Output | Seat Motor Sensor pwr | Slide RR SW Input | |
| 11 | Slide FR Limit SW Input | Recline FR SW Input | ||
| 12 | Recline FR Limit SW Input | Recline RR SW Input | ||
| 13 | Rear Slide Limit SW RR Input | Head Rest Up SW Input | ||
| 14 | Combined Walk In FR SW Input | Head Rest Down SW Input | ||
| 15 | Combined Walk In RR SW Input | |||
| 16 | Combined Relax FR SW Input | ECU PWR Gnd | ||
| 17 | Combined Relax RR SW Input | |||
| 18 | Slide Walk In FR SW Input | |||
| 19 | Slide Walk In RR SW Input | |||
| 20 | Seat Motor Sensor Gnd | |||
PINS DESCRIPTION CHART
Headrest Error
The Error is detected if pulse is below 6 pulses in 1 sec when HEADREST is operated
- SLIDE run to position after HEADREST ERROR
- HEADREST does not run although SLIDE run more 15mm
- HEADREST does not run although HEADREST is recovery and HEADREST linkage with SLIDE operates when resetting is going.
Scheme 60
Soft Limit
Soft Limit Setting(FR HEIGHT, RR HEIGHT, CUSHION EXT, HEAD REST)
- SOFT LIMIT INITIALIZATION SETTING BOTH SOFT LIMIT Is not set at the first time (B+) The initial set of SOFT LIMIT is initial stop position by MANUAL operation.
- SOFT LIMIT renewal condition SOFT LIMIT will be renewal in case of over SOFT LIMIT position by MANUAL or PLAYBACK (However, buzzer output is not) SOFT LIMIT will be renewal to operation direction when the error is occurred during operating Of MANUAL or PLAYBACK. (However, Motor output must be keep for MANUAL but renewal for PLAYBACK) Both SOFT LIMIT will be renewal in error condition and return by only manual.
- SOFT LIMIT ERROR and BUZZER output Buzzer output will be 0 times when the motor error is occurred within SOFT LIMIT range. Front Height: below 6 pulses in 1sec. Rear Height: below 6 pulses in 1.5sec. Cushion Extension: below 6 pulses in 1 sec. Head Rest: below 6 pulse in 1 sec.
Glossary
- RPSM: Relax Power Seat Module
- Combined RELAX SW: Combined RELAX SWITCH
- Combined WALK IN SW: Combined WALK IN SWITCH
- WALK IN SW: WALK IN SWITCH
- SW: SWITCH
- FR: FRONT
- RR: REAR
- ASSIST MANUAL SW
- SLIDE FR/RR SW
- RECLINE FR/RR SW
- HEAD REST UP/DOWN SW
- DRIVER MANUAL SW
- ASSIST SEAT SLIDE FR/RR SW
- ASSIST SEAT RECLINE FR. RR SW
Scheme 61
- Behavior of Combined WALK IN SWITCH ASSIST SEAT SLIDE/RECLINE/HEADREST can be controlled by Combined WALK IN SWITCH Control by Combined WALK IN FRONT SWITCH In case of Combined WALK IN FRONT SWITCH is kept ON RPSM drives ASSIST SLIDE motor forward and ASSIST HEADREST motor down. RPSM drives ASSIST RECLINE forward when ASSIST SLIDE FRONT LIMIT ON. BUZZER output 1 time when ASSIST SLIDE FRONT LIMIT & ASSIST RECLINE FRONT LIMIT. If Combined WALK IN FRONT SWITCH is OFF-->ON in above state (3), BUZZER output 1 time. But no output ASSIST SLIDE & RECLINE motors. If Combined WALK IN FRONT SWITCH and MANUAL SWITCH are simultaneously ON, RPSM Drives for MANUAL SWITCH. RPSM stops ASSIST seats motor output immediately, when Combined WALK IN FRONT SWITCH is ON --> OFF. (Combined WALK IN SWITCH: SELF RETURN TYPE SWITCH) Behavior of Combined WALK IN FRONT SWITCH is not available when ASSIST DOOR OPEN. Control by Combined WALK IN REAR SWITCH In case of Combined WALK IN REAR SWITCH is kept ON RPSM drives ASSIST RECLINE motor backward to STD Position(400 Pulse(20°) from REAR LIMIT). RPSM drives ASSIST SLIDE motor backward to REAR LIMIT when ASSIST RECLINE is at STD position. And then BUZZER output 1time. No output for ASSIST HEADREST as Combined WALK IN REAR SWITCH. If Combined WALK IN REAR SWITCH is OFF-->ON when ASSIST RECLINE is at STD position and ASSIST SLIDE REAR LIMIT, BUZZER output 1 time. But no output ASSIST SLIDE & RECLINE motor. If Combined WALK IN REAR SWITCH and MANUAL SWITCH are simultaneously ON, RPSM drives assist seat motors for MANUAL SWITCH. RPSM stops ASSIST seats motor output immediately, when Combined WALK IN REAR SWITCH is ON --> OFF. (Combined WALK IN SWITCH: SELF RETURN TYPE SWITCH) Behavior of Combined WALK IN REAR SWITCH is not available when ASSIST DOOR OPEN.
- Behavior of Combined RELAX SWITCH ASSIST SEAT SLIDE/RECLINE/HEADREST & VIP SEAT SLIDE/LEG SUPPORT can be controlled by Combined RELAX SWITCH Control by Combined RELAX FRONT SWITCH In case of Combined WALK IN FRONT SWITCH is kept ON RPSM drives ASSIST SLIDE motor forward, ASSIST RECLINE forward and ASSIST HEAD REST motor down. If ASSIST RECLINE position reaches to 900 Pulse from REAR LIMIT (RECLINE angle: 90°), RPSM drives VIP SEAT SLIDE forward. RPSM drives VIP SEAT LEG SUPPORT motor up when VIP SEAT SLIDE FRONT LIMIT ON. BUZZER output 1 time when ASSIST SLIDE/RECLINE, VIP SEAT SLIDE FRONT LIMIT and VIP SEAT LEG SUPPORT UP LIMIT. If Combined RELAX FRONT SWITCH is OFF-->ON in above state (3), BUZZER output 1 time. But no output ASSIST and VIP SEAT motors. If Combined RELAX FRONT SWITCH and MANUAL SWITCH are simultaneously ON, RPSM Drives for MANUAL SWITCH. RPSM stops motor output immediately, when Combined RELAX FRONT SWITCH is ON-->OFF. (Combined RELAX FRONT SWITCH: SELF RETURN TYPE SWITCH) Behavior of Combined RELAX FRONT SWITCH is not available when ASSIST DOOR OPEN. Control by Combined RELAX REAR SWITCH In case of Combined WALK IN FRONT SWITCH is kept ON RPSM drives VIP SEAT LEG SUPPORT down and SLIDE backward. If they reach to LIMIT, RPSM drives ASSIST RECLINE backward to STD Position(400 Pulse(20°) from REAR LIMIT). RPSM drives ASSIST SLIDE motor backward to REAR LIMIT when ASSIST RECLINE is at STD position. BUZZER output 1 time when ASSIST SLIDE REAR LIMIT If Combined RELAX REAR SWITCH is OFF-->ON when ASSIST RECLINE is at STD position, ASSIST SLIDE REAR LIMIT, VIP SEAT SLIDE REAR LIMIT and LEG SUPPORT DOWN LIMIT, BUZZER output 1 time. But no output ASSIST and VIP SEAT motors. If Combined RELAX REAR SWITCH and MANUAL SWITCH are simultaneously ON, RPSM Drives for MANUAL SWITCH. RPSM stops motor output immediately, when Combined RELAX REAR SWITCH is ON-->OFF. (Combined RELAX REAR SWITCH: SELF RETURN TYPE SWITCH) Behavior of Combined RELAX REAR SWITCH is not available when ASSIST DOOR OPEN.
- Maximum Driving Time of ASSIST SEAT motors Slide: 20s +/- 2s Recline: 35s +/- 3s Head Rest: 10s +/- 1s
- Set LIMIT HARD LIMIT SW HARD LIMIT SW prevents MOTOR restriction, Electrical contacts type is NORMAL CLOSE. ASSIST SLIDE/RECLINE, VIP SEAT SLIDE/LEG SUPPORT When HARD LIMIT SW of ASSIST SLIDE/RECLINE, VIP SEAT SLIDE/LEG SUPPORT is close --> open, LIMIT is renewed when they estimate end position of machinery. SOFT LIMIT SW SOFT LIMIT is applied because it prevents MOTOR restriction. (HEADREST(Spare Seat)) SOFT LIMIT deals with HEADREST, First it moves all section so it renewed LIMIT position. Renewal conditions of LIMIT are first all section to move, LIMIT set up when HALL SENSOR don't input (1sec of 6PULSE) After LIMIT was renewed, if OUTPUT don't generate 6PULSE upward that it is ERROR condition.
- ERROR detection and transaction ERROR detection ERROR is detected when as follow conditions are occurred for each MOTOR operation by MANUAL SW ERROR when no pulse input Each MOTOR output stops when ERROR occurred during the MANUAL SW operation (Exclusive of SLIDE, RECLINE) In case of SENSOR VCC of SEAT detects under 2.5V for 40ms => In this case SENSOR VCC of SEAT detects over 3.5V, then reversion No buzzer output although error is occurred ERROR transaction When error detected as above, HARNESS disconnection or SENSOR fault, behavior of Error transaction is as follows. ERROR is decided when HALL SENSOR don't input during MANUAL SW operation. ERROR is recovered if MANUAL SW operates in MOTOR to occur ERROR Recovered timing is decided when troubled MOTOR is repaired, it's like as follows SEAT: In case, Normal SIGNAL [6PULSE input within 3sec(RECLINE)/1sec(HEADREST)] input from POSITION SENSOR that Controls of MANUAL SW cause MOTOR ERROR
Scheme 62
- Remove the negative(-) battery terminal.
- Remove the seats in the car. (Refer to the «FRONT SEAT»(ref-417757-S01226783022011083000000) )
- Remove the IMS & PSM module(A) after loosening 4 screws and 4 connectors in the bottom of seat.
Manual Control With Direction Switches
- Tilt & Telescope operation is carried out in SCM according to user handling of direction switches when the following conditions are satisfied. Only one of direction switches is pressed ON (Tilt Up/Down, Telescope Forward/Backward).
- SCM is different from a value of maximum continuous time for each motor Tilt: 6s +/- 1s Telescope: 6s +/- 1s
- Manual has priority although self-diagnosis actuator operation order is received (actuator operation ignorance)
Soft Limit Setting By Manual Switches
- The basis value must be set 8000H and both direction SOFT LIMIT must be open at the first time at B+ condition
- The LIMIT must be renewal in all range by MANUAL operation at the first setting of LIMIT
- If the error is occurred during operation, after saving the ERROR DATA in EEPROM, easy access position is deleted and only SOFT LIMIT to going direction is deleted.
- The LIMIT must be reset in all range and in easy access (get out) after recovery form error.
- The SOFT LIMIT is presented ±12PULSE from mechanical limit position
Memory With Position Switches
When no manual operation is performing
- SCM memorizes position once if one of Mem P1 CMD or Mem P2 CMD command is changed to ON.
- Memory enable CAN signal Mem ENB=Enable
- Memory operation If CAN signal Mem P1 CMD=P1 or Mem P2 CMD=P2 is received, SCM memorize a present Tilt & Telescope position
- The notice about memory Memory must not be clear even though battery is removed.
Arbitration Control
Tilt & Telescope function is carried out according to the following priority table. If Tilt & Telescope requirement happen same time.
Scheme 63
* "-": Non-existence condition
Scheme 64
Scheme 65
Scheme 66
- You can turn ON/OFF of IMS tilt & telescope control option with the user option program.
- Select model and "body control module" menu.
- Select the "user option".
- Select the "Tilt steering & seat linkage".
- Select the On/Off option of IMS tilt & telescope control. Seat installation state ON/OFF Seat riding & getting off gearing ON/OFF Column installation state ON/OFF Column riding & getting off gearing ON/OFF
