Body Control Module (BCM): Specifications Hyundai Equus II

Communication Devices 2 illustrations

Specifications

ItemsSpecifications
Rated voltageDC 12V
Operating voltageDC 9 ~ 16V
Operating temperature30°C ~ 75°C (-4°F ~ 158°F)
Insulation resistanceIPM: 3mA
DDM: 2mA
ADM: 2mA
SCM: 2mA
IMS: 2mA
PDM: 1mA
FAM: 1mA

BODY CONTROL MODULE SPECIFICATIONS CHART

Scheme 1

Scheme 1: Components
Scheme 1: Components

Scheme 2

Scheme 2: Schematic Diagrams
Scheme 2: Schematic Diagrams
ItemDescription
MOSTMedia Oriented Systems Transport
CANController Area Network
FAMFront Area Module
IPMInter Panel Module
PDMPower Distribution Module
DDMDriver Door Module
ADMAssistant Door Module
CLUCLUster
MFSWMulti Function SWitch
DATCDual Auto Telematics System communicate with MTS
MTSMobile Telematics System
PSMPower Seat Module
SCMSteering Control Module
FBWSFront Back Warning System
SWRCSteering Wheel RemoCon
PTLPower Trunk Lid Module = PTM
ECWElectronic Control Window
EMSEngine Management System
SRXStand Along Receiver
DIAGDIAGnostic
ESCLElectrical Steering Column Lock
DISDisplay Information System
DRLDaytime Running Light Control

BODY CONTROL MODULE DESCRIPTION CHART
