Body Control Module (BCM): Removal & Installation Hyundai Equus II

Installation

1. Install the IPM after connecting the connector.
2. Install the crash pad lower panel.

Scheme 3

Scheme 4

Scheme 5

1. It will be able to diagnose defects of IPM with GDS quickly. GDS can operates actuator forcefully, input/output value monitoring and self diagnosis.
2. Select model and "IPM".
3. Select the module to check.
4. Select "Input/output monitoring", if you will check current data of body network system. It provides input/output status of each module.
5. If you will check each module data operation forcefully, select "Actuation test".
6. To check the DTC of the each module, select "DIAGNOSTIC TROUBLE CODES"
