TORQUE CONVERTER STALL TEST
This test measures the maximum engine speed when the selector lever is in the D or R position. The torque converter stalls to test the operation of the torque converter, starter motor, one-way clutch operation, the holding performance of the clutches, and brakes in the transmission.
| CAUTION | Do not let anybody stand in front of or behind the vehicle while this test is being carried out. |
- Check the automatic transmission fluid level and temperature, and the engine coolant temperature. Fluid level : At the HOT mark on the oil level gauge Fluid temperature : 80-100°C Engine coolant temperature : 80-100°C
- Chock both rear wheels (left and right).
- Apply the parking brake lever with the brake pedal fully depressed.
- Start the engine.
- Move the selector lever to the D position, fully depress the accelerator pedal and take a reading of the maximum engine speed at this time.
| CAUTION | The throttle should not be left fully open for more than eight seconds. If carrying out the stall test two or more times, move the selector lever to the N position and run the engine at 1,000 RPM to let the automatic transmission fluid cool down before carrying out subsequent tests. Standard value stall speed : 2,100-2,900 RPM Move the selector lever to the R position and carry out the same test again. Standard value stall speed : 2,100-2,900 RPM |
Scheme 8
- Stall speed is too high in both D and R ranges Low line pressure Low & reverse brake slippage
- Stall speed is too high in D range only Underdrive clutch slippage
- Stall speed is too high in R range only Reverse clutch slippage
- Stall speed too low in both D and R ranges Malfunction of torque converter Insufficient engine output (Scheme 8): Identifying Reverse Clutch, Low-Reverse Brake, Underdrive Clutch & Torque Converter
Scheme 9
Scheme 10
Scheme 11
- Warm up the engine until the automatic transmission fluid temperature is 80-100°C.
- Jack up the vehicle so that the wheels are free to turn.
- Connect the special tool (oil pressure gauge) to each pressure discharge port.
- Measure the hydraulic pressure at each port under the conditions given in the standard hydraulic pressure table, and check that the measured values are within the standard value ranges.
- If a value is outside the standard range, correct the problem while referring to the hydraulic pressure test diagnosis table. (Scheme 9): Identifying Low & Reverse Brake Pressure Port, Under Drive Clutch Pressure Port & Second Brake Pressure Port (Scheme 10): Identifying Damper Clutch Apply Pressure Port & Damper Clutch Release Pressure Port (Scheme 11): Identifying Reverse Clutch Pressure Port & Overdrive Clutch Pressure Port
Hydraulic Pressure Test Table. Scheme 12
Hydraulic Pressure Test Diagnosis Table (1 Of 2). Scheme 13
Hydraulic Pressure Test Diagnosis Table (2 Of 2). Scheme 14
