Automatic Transaxle Shift Control System: Removal & Installation Hyundai Elantra III

SHIFT LOCK DEVICE INSTALLATION

Note. When servicing the shift lock device, follow the service instructions and procedures described below to ensure proper operation.

Scheme 124

Scheme 125

Scheme 126

Scheme 127

Scheme 128

1. Procedure to install the lock cam. Move the P-lock cam to direction "A" and hold it by hand. (Scheme 124) Check that the key lock cam is located at "B" by detent pin. (Scheme 124)and (Scheme 125). (Scheme 124): Move The P-Lock Cam To Direction "A" & Checking That The Key Lock Cam Is Located At "B" By Detent Pin
2. Procedure for adjusting the shift lock and key lock cable. Check that each lock cam is located in position (Scheme 125) (Scheme 125): Identifying Lock Cam Position Install the shift lock cable and key lock cable in position. In this case, the key lock cable must be fixed to the key cylinder and the shift lock cable must be fixed to the brake pedal in position. Temporarily install each cable to the A/T lever assembly (Scheme 126) Securely insert the cable into the fixing pin of each cam. (Scheme 126): Identifying Gap Of 2-4 mm Between The Key Lock Cam & The P-Lock Cam Keep a gap of 2-4 mm between the key lock cam and the P-lock cam to eliminate cable slack by pulling the shift lock cable slightly in the direction of "E". (Scheme 126) CAUTION: If the gap is not maintained between 2 and 4mm, the brake pedal will have to be depressed more than required when operating the push button of the shift lever. After checking that a portion of the cable end touches cable fixing pin of the P-lock cam, fix the shift lock cable to the A/T lever with the rear and fix the shift lock cable end with the washer and snap pin. (Scheme 127) Slightly push the key lock cam in the direction of "Q". Slightly pull the key lock cable in the direction of "G" to stretch the cable tight and then fix it with a nut. (Scheme 126)and (Scheme 127). Be sure to check whether the key lock cable is inserted into the fixing pin of the key lock cam, and then fix it with the washer and snap pin. At this time, check if the P-lock cam is fixed to the shift lock cable (Scheme 127) (Scheme 127): Identifying P-Lock Cam Is Fixed To The Shift Lock Cable
3. Procedure for checking for correct shift lock installation. When the brake pedal is not depressed the, push button of the shift lever in the "P" position cannot operate (shift lever cannot shift to other positions from "P"). Push button can be operated at other positions, except "P". When the brake pedal stroke is 15-25mm (with shift lever in the "P" position), push button should operate without catching and the shift lever can shift smoothly out of "P". When the brake pedal is not depressed, the shift lever should be shift smoothly to the "P" position from other positions. Brake pedal must operate smoothly without catching in all positions. When the ignition key is at the "LOCK" position, although brake pedal is depressed, the push button should operate. Ignition key must not turn to the "LOCK" position, except when in "P" position. If the shift lever is shifted to the "P" position, the ignition key must be able to turn to the "LOCK" position smoothly.
4. Caution in service. Keep the gap of 2-4 mm between the key lock cam and p-lock cam by pulling the shift lock cable in the direction of "E" slightly, and then fix the cable with a nut. After this, be sure to check that the gap is within 2-4 mm. NOTE: If the gap is not maintained between 2 and 4mm, the brake pedal will have to be depressed more than required in order to shift the lever from "P" to other positions. Be sure that the key lock cable slack is eliminated. NOTE: If slack in the key lock cable is not eliminated, the ignition key cannot be removed from the key cylinder and the shift lever will be able to shift from "P" to other positions, although the key is in the "LOCK" position. Before and after the relating work, the key lock cam and P-lock cam should not be in the same condition as the (Scheme 128) and (Scheme 129). (Scheme 128): Checking For Correct Shift Lock Installation NOTE: When the key lock cam and P-lock cam are in the same condition as the (Scheme 128) and (Scheme 129), shifting the shift lever from D, 3, 2, L positions to P, R, N by force may cause a malfunction of related parts. Under the condition in (Scheme 128), shift the shift lever from D, 3, 2, L to P, R, N after rotating the P-lock cam in the direction of "A". Under the condition in (Scheme 129), shift the shift lever from D, 3, 2, L to P, R, N after rotating the P-lock cam in the direction of "A" the depressing the brake pedal.

KEY INTERLOCK DEVICE INSTALLATION

It is expected that the ignition key may not be removed from the key cylinder due to misassembly of the key inter lock cable. To prevent this problem, apply the following installation instructions when servicing.

Scheme 129

Scheme 130

1. Assembly of key interlock cable and ignition lock. The ignition lock assembled to the steering column. Set the ignition lock to the lock position. Assemble the key interlock cable and the ignition lock with the set screw. (Scheme 129): Shifting The Shift Lever From D, 3, 2, L To P, R, N
2. Assembly of key interlock cable and shift lever. Set the shift lever to the "P" position. After setting the key interlock cable as shown in the (Scheme 130), temporarily assemble the key inter lock cable with a M8 nut just enough to move the key interlock cable plate by its spring force. (Scheme 130): Setting The Key Interlock Cable Holding the cable and the key inter lock cable plate, push them into the direction of "F" so as not to create any bending or slack on the "B" point of the key inter lock cable. NOTE: Do not pull the cable in the direction of "X" to remove the slack. This may cause key not to remove from the key cylinder. Tighten the key inter lock cable with a M8 nut.
