Dashboard: Component Locations Honda S2000 AP1

Special Tools Required

KTC trim tool set SOJATP2014*

*Available through the American Honda Tool and Equipment Program; call 888-424-6857

Note. Use the appropriate tool from the KTC trim tool set to avoid damage when prying components. Take care not to scratch the dashboard and related parts.

Scheme 14

1. Remove the instrument panel as shown below.
2. Install the panel in the reverse order of removal, and note these items: Replace any damaged clips. Make sure the connectors are plugged in properly. Push the clips into place securely.

KTC trim tool set SOJATP2014*

*Available through the American Honda Tool and Equipment Program; call 888-424-6857

Note. Use the appropriate tool from the KTC trim tool set to avoid damage when prying components. Take care not to scratch the dashboard and related parts.

Scheme 15

1. Remove the radio panel as shown below.
2. Install the panel in the reverse order of removal, and note these items: Replace any damaged clips. Push the clips into place securely.

KTC trim tool set SOJATP2014*

*Available through the American Honda Tool and Equipment Program; call 888-424-6857

Note. Use the appropriate tool from the KTC trim tool set to avoid damage when prying components. Take care not to scratch the dashboard and related parts.

Scheme 16

1. Remove the front console cover as shown below.
2. Install the cover in the reverse order of removal, and note these items: Replace any damaged clips. Push the clips into place securely.

KTC trim tool set SOJATP2014*

*Available through the American Honda Tool and Equipment Program; call 888-424-6857

KTC trim tool set SOJATP2014*

*Available through the American Honda Tool and Equipment Program; call 888-424-6857

Note. Use the appropriate tool from the KTC trim tool set to avoid damage when prying components. Take care not to scratch the dashboard and related parts.

Scheme 17

Scheme 18

1. Remove the passenger's dashboard lower cover as shown below.
2. Install the cover in the reverse order of removal, and note these items: Check for damaged or stress-whitened clips, and replace them with new ones. Push the clips into place securely. '00-05 models '06-09 model

KTC trim tool set SOJATP2014*

*Available through the American Honda Tool and Equipment Program; call 888-424-6857

Note. Use the appropriate tool from the KTC trim tool set to avoid damage when prying components.

Scheme 19

1. Carefully insert a trim tool next to the clips (A), and detach the clips by prying on the passenger's side vent (B). Take care not to scratch the dashboard and related parts.
2. Remove the vent by releasing the hooks (C).
3. Reinstall the hook portions of the vent first, then push the clips into place securely.

KTC trim tool set SOJATP2014*

*Available through the American Honda Tool and Equipment Program; call 888-424-6857

SRS components are located in this area. Review the SRS component locations for the appropriate model

1. '00-05 models (see «COMPONENT LOCATION INDEX»(ref-221407-S07466498202006022400000) )
2. '06-08 models (see «COMPONENT LOCATION INDEX»(ref-221407-S07466498202006022400000) )

Also review PRECAUTIONS AND PROCEDURES before performing repairs or service.

Note. Use the appropriate tool from the KTC trim tool set to avoid damage when prying components. Have an assistant help you when you remove and install the dashboard. Take care not to scratch the dashboard, body and other related parts. Put on gloves to protect your hands.

Scheme 20

Scheme 21

1. Make sure you have the anti-theft code for the radio, and then write down the audio presets.
2. Disconnect the negative cable from the battery, and wait at least 3 minutes before beginning work.
3. Remove these items: Radio panel (see «RADIO PANEL REMOVAL/INSTALLATION»(ref-221367-S32922038512006022400000) ) Audio unit (see «AUDIO UNIT REMOVAL/INSTALLATION»(ref-351956-S28419735862009122900000) ) Steering column (see «STEERING COLUMN REMOVAL AND INSTALLATION»(ref-221352-S07217601762006022400000) ) '06-09 model: Driver's dashboard lower cover (see «'06-09 MODEL»(ref-221367-S07153962222006022400000) ) Passenger's dashboard lower cover (see «PASSENGER'S DASHBOARD LOWER COVER REMOVAL/INSTALLATION»(ref-221367-S01244536242006022400000) ) Front console cover, both sides (see «'06-09 MODEL»(ref-221367-S07153962222006022400000) ) Passenger's airbag assembly (see «PASSENGER'S AIRBAG REPLACEMENT»(ref-351949-S12298792602009122900000) ) Kick panel, both sides (see «TRIM REMOVAL/INSTALLATION - DOOR AREAS»(ref-221365-S37075338132006022400000) ) A-pillar trim, both sides (see «TRIM REMOVAL/INSTALLATION - FRONT ROOF AREA»(ref-221365-S35667005942006022400000) )
4. Disconnect the engine wire harness connector (A), engine compartment wire harness connectors (B), door wire harness connectors (C), rear wire harness connector (D), steering hanger beam wire harness connectors (E), SRS main harness connector (F), front impact sensor harness connector (G), radio antenna harness connector (H), ECM connector (I), keyless entry control unit connector (J), and convertible top control unit connector (K).
5. Remove the ground bolts (L).
6. Detach all of the harness and connector clips.
7. Open the doors, remove the caps (A), then remove the bolts (B, C, D) and screws (E), and lift up on the dashboard (F) to release it from the guide pins (G). Take care not to scratch the center console and shift knob.
8. Carefully remove the dashboard through the front door opening.
9. Install the dashboard in the reverse order of removal, and note these items: Make sure the dashboard fits onto the guide pins correctly. Before tightening the bolts, make sure the dashboard wire harness and steering hanger beam wire harness are not pinched. Make sure the connectors are plugged in properly. Reconnect the negative cable to the battery. Enter the anti-theft code for the radio, then enter the audio presets. Reset the clock. '02-05 models: Do «ECM IDLE LEARN PROCEDURE»(ref-221342-S09897997502006022400000) .
