Relays: Other Honda S2000 AP1

Normally-open type A

Check for continuity between the terminals.

Scheme 46

1. There should be continuity between the No. 1 and No. 2 terminals when power and ground are connected to the No. 3 and No. 4 terminals.
2. There should be no continuity between the No. 1 and No. 2 terminals when power is disconnected.

type 1

Scheme 47

type 2

Scheme 48

Normally-open type B

Check for continuity between the terminals.

Scheme 49

1. There should be continuity between the No. 1 and No. 3 terminals when power and ground are connected to the No. 2 and No. 4 terminals.
2. There should be no continuity between the No. 1 and No. 3 terminals when power is disconnected.

Five-terminal type A

Check for continuity between the terminals.

Scheme 50

1. There should be continuity between the No. 1 and No. 2 terminals when power and ground are connected to the No. 3 and No. 5 terminals.
2. There should be continuity between the No. 2 and No. 4 terminals when power is disconnected.

Intermittent wiper relay ('02-09 models)

Scheme 51

Five-terminal type B

Check for continuity between the terminals.

Scheme 52

Scheme 53

1. There should be continuity between the No. 1 and No. 2 terminals when power and ground are connected to the No. 5 and No. 3 terminals.
2. There should be continuity between the No. 1 and No. 4 terminals when power is disconnected.
3. Intermittent wiper relay ('00-01 models)
4. Rear window defogger relay ('02-09 models)
5. Rear window defogger change relay ('02-09 models)
