Body Electrical (General Troubleshooting): Other Honda S2000 AP1

Body Electrical 2 illustrations ~136 words

Wire Color Codes

The following abbreviations are used to identify wire colors in the circuit schematics

WHTWhite
YELYellow
BLKBlack
BLUBlue
GRNGreen
REDRed
ORNOrange
PNKPink
BRNBrown
GRYGray
PURPurple
LT BLULight Blue
LT GRNLight Green

WIRE COLOR CODES

The wire insulation has one color or one color with another color stripe. The second color is the stripe.

Scheme 14

Scheme 14
Scheme 14

Scheme 15

Scheme 15: How To Check For DTCs with the Honda Diagnostic System (HDS) ('06-09 model)
Scheme 15: How To Check For DTCs with the Honda Diagnostic System (HDS) ('06-09 model)
  1. Connect the Honda Diagnostic System (HDS) to the Data Link Connector (DLC) (A) located behind the driver's side of the front console. NOTE: For specific operations, refer to the user's manual that came with the Honda Diagnostic System (HDS).
  2. Make sure the HDS communicates with the vehicle and the gauge assembly. If it doesn't, troubleshoot the DLC circuit (see «DLC CIRCUIT TROUBLESHOOTING»(ref-351945-S34342936082009122900000) ).
  3. Select the TEST MODE MENU and check for Diagnostic Trouble Code (DTCs), and note them. Refer to the Troubleshooting Index and begin the appropriate troubleshooting procedure.
