Special Tools Required
Relay puller 07AAC-000A1A0
Use this table to identify the type of relay, then do the test listed for it. Carefully remove the relays using the relay puller. Do not use pliers. Pliers will damage the relay
Scheme 45
Note. For the turn signal/hazard relay input test (see TURN SIGNAL/HAZARD RELAY INPUT TEST ).
| Relay | Test |
|---|---|
| A/C compressor clutch relay | Normally open type A |
| A/C condenser fan relay | |
| ETCS control relay (3) | |
| Headlight relay 1 | |
| Headlight relay 2 | |
| High beam cut relay (Except '00-05 USA) | |
| Horn relay | |
| PGM-FI main relay 1 (3) | |
| PGM-FI main relay 2 (3) | |
| Radiator fan relay | |
| Starter cut relay | |
| Taillight relay | |
| Rear window defogger relay (1) | |
| Blower motor relay | Normally open type B |
| Intermittent wiper relay (2) | Five terminal type A |
| A/F sensor relay (3) | Five terminal type B |
| Accessory power socket relay | |
| IG2 relay | |
| Ignition coil relay (3) | |
| Intermittent wiper relay (1) | |
| Rear window defogger change relay (2) | |
| Rear window defogger relay (2) | |
| (1) '00-01 models (2) '02-09 models (3) '06-09 model | |
| (1) | '00-01 models |
| (2) | '02-09 models |
| (3) | '06-09 model |
RELAY INPUT TEST TABLE
