Special Tools Required
KTC Trim Tool Set SOJATP2014*
*Available through the Honda Tool and Equipment Program; call 888-424-6857
KTC Trim Tool Set SOJATP2014*
*Available through the Honda Tool and Equipment Program; call 888-424-6857
KTC Trim Tool Set SOJATP2014*
*Available through the Honda Tool and Equipment Program; call 888-424-6857
KTC Trim Tool Set SOJATP2014*
*Available through the Honda Tool and Equipment Program; call 888-424-6857
KTC Trim Tool Set SOJATP2014*
*Available through the Honda Tool and Equipment Program; call 888-424-6857
Note. Put on gloves to protect your hands. Take care not to bend or scratch the trim and panels. Use the appropriate tool from the KTC trim tool set to avoid damage when removing components.
Scheme 21
Scheme 22
Scheme 23
Scheme 24
Scheme 25
- Remove the hatch glass weatherstrip (see «HATCH GLASS WEATHERSTRIP REPLACEMENT»(ref-333583-S12724290662009072100000) ).
- Remove the tailgate upper trim panel (A). Detach the hooks (B) and tabs (C) from the left tailgate side trim (D) and right tailgate side trim (E). Pull the tailgate upper trim panel back by hand to detach the clips, then remove it.
- Remove the left tailgate side trim (A) and the right tailgate side trim (B). Pull out the top of the side trim to detach the clips. With power tailgate: release the rod (C) from the slit (D). Detach the tabs (E) and hooks (F) from the tailgate lower trim panel (G).
- Remove the tailgate pull pocket (A). Carefully pull the edge of the tailgate lower trim panel (B) just beside the tailgate pull pocket by hand, and push out the inside hooks (C). Pull down the upper edge of the pocket and release the lower tabs (D). With power tailgate: Disconnect the power tailgate close switch connector (E).
- Pry out the cap (A) and remove the bolt, then remove the pull strap (B).
- Remove the tailgate lower trim panel (A). Detach the clips (B) beside the tailgate latch. Pull down the panel to detach all of the clips (C).
- Install the trim and panel in the reverse order of removal, and note these items: Make sure the power tailgate close switch connector is plugged in properly. If the clips are damaged or stress-whitened, replace them with new ones. Push the clips, hooks, and tabs into place securely.
KTC Trim Tool Set SOJATP2014*
*Available through the Honda Tool and Equipment Program; call 888-424-6857
Note. Use the appropriate tool from the KTC trim tool set to avoid damage when removing components. When prying with a flat-tip screwdriver, wrap it with protective tape to prevent damage.
Scheme 26
Scheme 27
Scheme 28
Scheme 29
Scheme 30
Scheme 31
Scheme 32
- Lower the grab handle (A), then insert a small flat-tip screwdriver wrapped in protective tape into the notch.
- Use a KTC trim tool (A) to pull on the small flat-tip screwdriver, and remove the cap (B).
- While pinching the clips (A), release the hooks (B), then remove the grab handle (C).
- Using a pair pliers, remove all of the clips (A) by pinching the hooks with a pair of pliers.
- If the side curtain airbag has deployed, replace the grab handle with a new one.
- If the side curtain airbag has not deployed, inspect the grab handle for damage. A damaged grab handle may cause the side curtain airbag to deploy improperly, possibly causing injury. Replace the grab handle if it has any of the following damage: Any cracks or damage in the grab handle (A) Any cracks or stress-whitening in the caps (B)
- Install the clips (A) to the grab handle (B), then install the caps (C) fully into the clips.
- Position the grab handle (A) on the body (B), and push on the grab handle until the clips (C) snap into place securely.
KTC Trim Tool Set SOJATP2014*
*Available through the Honda Tool and Equipment Program; call 888-424-6857
SRS components are located in this area. Review the SRS COMPONENT LOCATION INDEX and PRECAUTIONS AND PROCEDURES before doing repairs or service.
Note. Take care not to bend or scratch the headliner. Use the appropriate tool from the KTC trim tool set to avoid damage when removing components. Be careful not to damage the dashboard and other interior trim.
Scheme 33
Scheme 34
Scheme 35
Scheme 36
Scheme 37
Scheme 38
Scheme 39
Scheme 40
Scheme 41
Scheme 42
Scheme 43
Scheme 44
Scheme 45
Scheme 46
- Remove these items: A-pillar trim, both sides (see «TRIM REMOVAL/INSTALLATION - PILLAR AREAS»(ref-333585-S08240123312009072100000) ) B-pillar lower trim, both sides (see «B-PILLAR UPPER/LOWER TRIM»(ref-333585-S13708563092009072100000) ) B-pillar upper trim, both sides (see «B-PILLAR UPPER/LOWER TRIM»(ref-333585-S13708563092009072100000) ) C-pillar trim, both sides (see «C-PILLAR TRIM»(ref-333585-S12168036682009072100000) ) D-pillar trim, both sides (see «D-PILLAR TRIM»(ref-333585-S33408886062009072100000) ) Upper quarter window trim (see «UPPER QUARTER WINDOW TRIM»(ref-333585-S38230762532009072100000) ) Sunvisors, both sides (see «SUNVISOR REMOVAL/INSTALLATION»(ref-333585-S05801120942009072100000) ) Grab handles, four places (see «GRAB HANDLE REMOVAL/INSTALLATION»(ref-333585-S04321254532009072100000) ) Rear individual map lights (see «REAR INDIVIDUAL MAP LIGHT TEST/REPLACEMENT»(ref-333616-S34530234252009072100000) ) With rear entertainment system: Remove the wireless remote control and display cover and disconnect the RES connector (see «WIRELESS REMOTE CONTROL ILLUMINATION DOES NOT COME ON»(ref-333640-S06247291522009072100000) ).
- Remove the roof console (A). Remove the lenses (B). Remove the screws (C), then pull out the front individual map light (D). Disconnect the front individual map light connector (E). If equipped, disconnect the moonroof switch connector (F). Remove the screws (G). Pull out the front side of the console, and release the rear hooks (H).
- Pry out the cover (A) and remove the screws, then remove the coat hanger (B).
- Remove the ground bolt (A).
- With rearview mirror: Disconnect the connector (A).
- If necessary, remove the roof console screw grommet (A) by squeezing the hooks (B).
- If necessary, remove the map light clip by releasing the hooks (C), and then prying out the clip (D).
- Disconnect roof wire harness connector (A) and detach the harness clips (B) from the driver's side A-pillar (C).
- Disconnect the rear washer hose joint (A) and the roof wire harness connector (B), then detach the harness clips (C) from the passenger's side A-pillar (D).
- Disconnect the rear window washer tube at the rear hatch, (see step 3 on «TAILGATE HINGE COVER REPLACEMENT»(ref-333593-S02892657622009072100000) )
- Lower the headliner (A). Remove the front door opening seals (B), rear door opening seals (C), and tailgate weatherstrip (D) from each roof portion. With moonroof: Release the Velcro fasteners (E) and front clips (F) by lowering the headliner. With the help of an assistant, detach the rear clips (G) by pulling the rear portion of the headliner down. Detach the magnets (H) by carefully pulling down on the headliner. Without moonroof With moonroof With moonroof and rear entertainment system
- With the help of an assistant, pull the headliner (A) along with the roof wire harness out through the tailgate opening. Do not bend the headliner excessively as this may crease or damage it.
- If necessary, remove the cushion tapes (A) fastening the roof wire harness (B), the rear washer hose (C), and the RES wire harness (D) (with rear entertainment system) to the headliner (E) and detach the harness clips (F), then remove them from the headliner. Without moonroof With moonroof With moonroof and with rear entertainment system
- Install the headliner in the reverse order of removal, and note these items: If the side curtain airbag has deployed, replace the headliner and affected trim pieces (see «COMPONENT REPLACEMENT/INSPECTION AFTER DEPLOYMENT»(ref-333646-S14025615592009072100000) ). To prevent the side curtain airbags from deploying improperly and possibly causing injury, inspect the headliner and all removed trim. Replace any pieces with the following damage: Any crease or tears in the headliner (A) Any cracks or breakage in the grab handle (B) Any damage around the grab handle holes (C) or sunvisor holes in the headliner Any cracks in the sunvisor bracket cover (D) Any bends or cracks in the sunvisor stay shaft (E) Any cracks in the sunvisor base (F) Any cracks or breakage in the vanity mirror base (G) Any fasteners (H), clip bases (I), or magnet bases (J) which have come off the headliner When installing the grab handle, push on the handle against the bracket (K) until the clips (L) snap into place securely. If the clips are damaged or stress-whitened, replace them with new ones. Replace the removed cushion tape with new pieces. Check that both sides of the headliner are securely attached to the roof. Make sure the headliner overlaps the trim pieces correctly (see «CHECKING AND ADJUSTING THE HEADLINER/PILLAR TRIM OVERLAP»(ref-333646-S02112221432009072100000) ). Be careful not to crease or damage the headliner when reinstalling it through the tailgate opening. Also be careful not to scratch the body.
Headliner
Scheme 47
Grab handle
Scheme 48
Sunvisor
Scheme 49
KTC Trim Tool Set SOJATP2014*
*Available through the Honda Tool and Equipment Program; call 888-424-6857
SRS components are located in this area. Review the SRS component locations (see COMPONENT LOCATION INDEX ) and the precautions and procedures (see PRECAUTIONS AND PROCEDURES ) before doing repairs or service.
Note. Put on gloves to protect your hands. Take care not to damage, wrinkle or twist the carpet. Use the appropriate tool from the KTC trim tool set to avoid damage when removing components. Be careful not to damage the dashboard and other interior trim pieces.
Scheme 50
Scheme 51
Scheme 52
Scheme 53
Scheme 54
Scheme 55
Scheme 56
- Do the battery terminal disconnection procedure (see «BATTERY TERMINAL DISCONNECTION AND RECONNECTION»(ref-333608-S13381695222009072100000) ), then wait at least 3 minutes before beginning work.
- Remove these items: Front seats, both sides (see «FRONT SEAT REMOVAL/INSTALLATION»(ref-333588-S11463606232009072100000) ) Second row seats, both sides (see «SECOND ROW SEAT REMOVAL/INSTALLATION»(ref-333588-S35540306182009072100000) ) Third row seats, both sides (see «THIRD ROW SEAT REMOVAL/INSTALLATION»(ref-333588-S00537842522009072100000) ) Front door sill trim, both sides (see step 1 on «TRIM REMOVAL/INSTALLATION - DOOR AREAS»(ref-333585-S19189801972009072100000) ) Rear door sill trim, both sides (see «REAR DOOR SILL AREA»(ref-333585-S06776744912009072100000) ) Kick panels, both sides (see step 3 on «TRIM REMOVAL/INSTALLATION - DOOR AREAS»(ref-333585-S19189801972009072100000) ) Passenger's dashboard undercover (see «PASSENGER'S DASHBOARD UNDERCOVER REMOVAL/INSTALLATION»(ref-333587-S10832152972009072100000) ) Steering joint cover (see «STEERING COLUMN REMOVAL AND INSTALLATION»(ref-333571-S10288250872009072100000) )
- Detach the hooks (A), then remove the footrest plate (B).
- Remove the nut with a 6 mm hexagonal wrench, release the clip, then remove the footrest (A).
- Remove the clips fastening both rear side trim panels (A). Pull out the edge of the carpet (B) from under the panels.
- Remove the clips fastening the edge of the carpet (A) from both front door sill areas and both rear door sill areas. Pull out the edge of the carpet from under the B-pillar lower trim (B).
- Pull out the edges of the carpet (A) from under the center console (B), driver's/passenger's console trim (C), and console rear trim (D).
- Release the fastener (A) on the front edge of the carpet (B), then pull back the carpet from under the dashboard.
- Remove the carpet.
- Install the carpet in the reverse order of removal, and note these items: Take care not to damage, wrinkle, or twist the carpet. Make sure the floor wire harnesses (A) are routed correctly. Slip the slits (B) in the carpet over the rear heater ducts (C) and the third row seat heater duct (D). Slip the carpet under the center console, both B-pillar lower trims, and both rear side trim panels properly. Do the battery terminal reconnection procedure (see «BATTERY TERMINAL DISCONNECTION AND RECONNECTION»(ref-333608-S13381695222009072100000) ).
