Instrument Panel Vent

Note. Take care not to scratch the dashboard and its related parts. Use the appropriate tool from the KTC trim tool set to avoid damage when removing components.

Scheme 140

1. Remove the instrument panel (see «INSTRUMENT PANEL REMOVAL/INSTALLATION»(ref-333587-S31415692192009072100000) ).
2. Remove the screws, then remove the instrument panel vent (A) and the vent trim (B).
3. Install the instrument panel vent in the reverse order of removal.

Center Panel Vent

Note. Take care not to scratch the dashboard and its related parts. Use the appropriate tool from the KTC trim tool set to avoid damage when removing components.

Scheme 141

1. Remove the center panel (see «DASHBOARD CENTER PANEL REMOVAL/INSTALLATION»(ref-333587-S16005184032009072100000) ).
2. Remove the screws, then remove the passenger's side center panel vent (A) and the vent trim (B).
3. Install the center panel vent in the reverse order of removal.

Note. Take care not to scratch the dashboard and its related parts. Use the appropriate tool from the KTC trim tool set to avoid damage when removing components.

Scheme 142

1. Remove the passenger's dashboard trim (see «PASSENGER'S DASHBOARD TRIM REMOVAL/INSTALLATION»(ref-333587-S33316179992009072100000) ).
2. Remove the screws, then remove the instrument panel vent (A) and vent trim (B).
3. Install the instrument panel vent in the reverse order of removal.
