Scheme 1
Windshield Wiper/Washer (Normally operation)
The MICU control of the windshield wiper motor and the windshield washer motor is based on inputs from each switch and B-CAN data.
| Input | Output | |
|---|---|---|
| MICU | IG1 power supply Windshield wiper switch (INT/LO) Windshield wiper switch (LO/HI) Windshield wiper switch (MIST) Windshield washer switch Windshield wiper motor (AUTO STOP) | Windshield wiper motor (INT) Windshield wiper motor (HI) Windshield washer motor |
| B-CAN | IG1 METER signal | Windshield wiper switch (FRINT) message Windshield wiper switch (FRWIPLO) message Windshield wiper switch (FRWIPHI) message Windshield washer switch (FRWASH) message Windshield wiper switch (FRMIST) message Windshield wiper motor (FRWIPAS) message |
MICU SPECIFICATIONS
Rear Window Wiper/Washer (Normally operation)
The MICU control of the rear window wiper motor and the rear washer motor is based on inputs from each switch.
| Input | Output | |
|---|---|---|
| MICU | IG1 power supply Rear window wiper switch Rear window washer switch | Rear window wiper motor Rear window washer motor |
| B-CAN | Rear window wiper switch (RRWIPSW) message Rear window washer switch (RRWASH) message |
MICU SPECIFICATIONS
Power Window Timer (Key-off operation)
The MICU control of the power window key-off operation is based on inputs from each switch.
| Input | Output | |
|---|---|---|
| MICU | IG1 power supply Ignition key switch Driver's door switch Front passenger's door switch | Power window timer |
MICU SPECIFICATIONS
Door Lock Response Operation*
The MICU control of the door lock actuators is based on B-CAN data.
| Input | Output | |
|---|---|---|
| MICU | Door lock actuators (LOCK/UNLOCK) Driver's door lock actuator (UNLOCK) | |
| B-CAN | Door lock signal | |
| *: The security system can be customized in the multi-information display (MID) to suit the customer's needs. For more information about keyless/security system options, refer to the Owner's Manual. | ||
MICU SPECIFICATIONS
Answer Back Response Operation*
The MICU control of the exterior lights and the horn is based on keyless signals sent by B-CAN data.
| Input | Output | |
|---|---|---|
| MICU | Parking lights Side marker lights Taillights License plate lights Horn | |
| B-CAN | Answer back (SMALL) signal | |
| *: The security system can be customized in the multi-information display (MID) to suit the customer's needs. For more information about keyless/security system options, refer to the Owner's Manual. | ||
MICU SPECIFICATIONS
Hatch Outer Handle Switch Operation
The MICU control of the hatch release actuator is based on inputs from each switch.
| Input | Output | |
|---|---|---|
| MICU | Hatch outer handle switch Driver's door lock knob switch (LOCK/UNLOCK) | Hatch release actuator |
| B-CAN |
MICU SPECIFICATIONS
