DTC P1298: ELD Circuit High Voltage Honda Fit GE

Note. Before you troubleshoot, record all freeze data and any on-board snapshot, and review GENERAL TROUBLESHOOTING INFORMATION .

Scheme 227

Scheme 228

Scheme 229

1. Turn the ignition switch to ON (II).
2. Check the ELD in the DATA LIST with the HDS. Is 0.2 A or less indicated? YES: Go to step 3 . NO: Intermittent failure, the system is OK at this time. Check for poor connections or loose terminals at the ELD and the ECM/PCM.
3. Turn the ignition switch to LOCK (0).
4. Disconnect the ELD 3P connector.
5. Turn the ignition switch to ON (II).
6. Measure the voltage between ELD 3P connector terminal No. 1 and body ground. Is there battery voltage? YES: Go to step 7 . NO: Check the No. 22 METER (7.5 A) fuse in the under-dash fuse/relay box. If the fuse is OK, repair open in the wire between the No. 22 METER (7.5 A) fuse and the ELD, then go to step 12 .
7. Jump the SCS line with the HDS.
8. Disconnect ECM/PCM connector A (49P).
9. Check for continuity between ELD 3P connector terminal No. 3 and ECM/PCM connector terminal A24. Is there continuity? YES: Go to step 10 . NO: Repair open in the wire between the ECM/PCM (A24) and the ELD, then go to step 12 .
10. Check for continuity between ELD 3P connector terminal No. 2 and body ground. Is there continuity? YES: Go to step 11 . NO: Repair open in the wire between the ELD and G501 (see «CONNECTOR TO FUSE/RELAY BOX INDEX»(ref-320459-S26645189512009071400000) ), then go to step 12 .
11. Replace the ELD (see «ECM/PCM UPDATE»(ref-320426-S22945234462009071400000) ).
12. Reconnect all connectors.
13. Turn the ignition switch to ON (II).
14. Reset the ECM/PCM with the HDS.
15. Do «ECM/PCM IDLE LEARN PROCEDURE»(ref-320447-S03803966382009071400000) .
16. Check for Pending or Confirmed DTCs with the HDS. Is DTC P1298 indicated? YES: Go to step 17 . NO: Troubleshooting is complete. If any other Pending or Confirmed DTCs are indicated, go to the indicated DTC's troubleshooting.
17. Update the ECM/PCM if it does not have the latest software (see «ECM/PCM UPDATE»(ref-320426-S22945234462009071400000) ), or substitute a known-good ECM/PCM (see «SUBSTITUTING THE ECM/PCM»(ref-320425-S18610926012009071400000) ).
18. Check for Pending or Confirmed DTCs with the HDS. Is DTC P1298 indicated? YES: Check for poor connections or loose terminals at the ELD and the ECM/PCM. If the ECM/PCM was updated, substitute a known-good ECM/PCM (see «SUBSTITUTING THE ECM/PCM»(ref-320425-S18610926012009071400000) ), then recheck. If the ECM/PCM was substituted, go to step 1 . NO: If the ECM/PCM was updated, troubleshooting is complete. If the ECM/PCM was substituted, replace the original ECM/PCM (see «ECM/PCM REPLACEMENT»(ref-320426-S21651098282009071400000) ). If any other Pending or Confirmed DTCs are indicated, go to the indicated DTC's troubleshooting.
