Pgm-Fi System: Component Locations Honda Fit GE

Special Tools Required

1. Pressure gauge adapter 07NAJ-P07010A
2. A/T low pressure gauge w/panel 07406-0070301
3. A/T pressure hose 07406-0020201
4. A/T pressure hose, 2,210 mm 07MAJ-PY4011A
5. A/T pressure hose, adapter 07MAJ-PY40120
6. Oil pressure hose 07ZAJ-S5AA200

Note. Before you troubleshoot, record all freeze data and any on-board snapshot, and review GENERAL TROUBLESHOOTING INFORMATION . If the misfire is frequent enough to trigger detection of increased emissions during two consecutive driving cycles, the MIL will come on, and DTC P0300 (and some combination of P0301 through P0304) will be stored. If the misfire is frequent enough to damage the catalyst, the MIL will flash whenever the misfire occurs, and DTC P0300 (and some combination of P0301 through P0304) will be stored. When the misfire stops, the MIL will remain on. If any of the DTCs listed below are indicated at the same time as the random misfire DTCs, troubleshoot those DTCs first, then recheck for random misfire DTCs: P0101, P0102, P0103: Mass airflow (MAF) sensor P0107, P0108: Manifold absolute pressure (MAP) sensor P0171, P0172: Fuel system P0335, P0339: Crankshaft position (CKP) sensor P0365, P0369: Camshaft position (CMP) sensor P0506, P0507: Idle control system P2646, P2647, P2648, P2649: VTEC system

Scheme 168

1. Turn the ignition switch to ON (II).
2. Clear the DTC with the HDS.
3. Start the engine, and let it idle without load (A/T in P or N, M/T in neutral).
4. Monitor the OBD STATUS for DTC P0301, P0302, P0303, or P0304 in the DTCs MENU with the HDS. Does the screen indicate FAILED? YES: Go to step 9 . NO: If the HDS indicates PASSED, go to step 5 . If the HDS indicates EXECUTING, keep idling until a result comes on. If the HDS indicates OUT OF CONDITION or NOT COMPLETED, wait for several minutes, then recheck.
5. Check the CYL1 MISFIRE, CYL2 MISFIRE, CYL3 MISFIRE, and/or CYL4 MISFIRE in the DATA LIST for 10 minutes with the HDS. Does the CYL1 MISFIRE, CYL2 MISFIRE, CYL3 MISFIRE, and/or CYL4 MISFIRE show misfire counts? YES: Go to step 9 . NO: Go to step 6 .
6. Test-drive the vehicle for several minutes in the range of these recorded freeze data parameters: ENGINE SPEED VSS REL TP SENSOR CLV (calculated load value) APP SENSOR
7. Monitor the OBD STATUS for DTC P0301, P0302, P0303, or P0304 in the DTCs MENU with the HDS. Does the screen indicate FAILED? YES: Go to step 9 . NO: If the HDS indicates PASSED, go to step 8 . If the HDS indicates EXECUTING, keep driving until a result comes on. If the HDS indicates OUT OF CONDITION or NOT COMPLETED, go to step 6 and recheck.
8. Check the CYL1 MISFIRE, CYL2 MISFIRE, CYL3 MISFIRE, and/or CYL4 MISFIRE in the DATA LIST for 10 minutes with the HDS. Does the CYL1 MISFIRE, CYL2 MISFIRE, CYL3 MISFIRE, and/or CYL4 MISFIRE show misfire counts? YES: Go to step 9 . NO: Intermittent failure, the system is OK at this time.
9. Turn the ignition switch to LOCK (0).
10. Check the fuel quality. Is the quality good? YES: Go to step 11 . NO: Drain the tank and fill with a known-good fuel, then go to step 24 .
11. Inspect the spark plugs (see «SPARK PLUG INSPECTION»(ref-320440-S19658340022009071400000) ). If the spark plugs are fouled or worn, replace them.
12. Test-drive the vehicle for several minutes in the range of these recorded freeze data parameters: ENGINE SPEED VSS REL TP SENSOR CLV (calculated load value) APP SENSOR
13. Check the CYL1 MISFIRE, CYL2 MISFIRE, CYL3 MISFIRE, and/or CYL4 MISFIRE in the DATA LIST for 10 minutes with the HDS. Does the CYL1 MISFIRE, CYL2 MISFIRE, CYL3 MISFIRE, and/or CYL4 MISFIRE show misfire counts? YES Go to step 14 . NO Go to step 24 .
14. Check the fuel pressure (see «FUEL PRESSURE TEST»(ref-320436-S05740436092009071400000) ). Is the fuel pressure OK? YES: Go to step 15 . NO: If the fuel pressure is too high, replace the fuel pressure regulator (see «FUEL PRESSURE REGULATOR REPLACEMENT»(ref-320436-S41654858282009071400000) ), then go to step 24 . If the fuel pressure is too low, check the fuel pump, the fuel feed pipe, and the fuel filter. If they are OK, replace the fuel pressure regulator (see «FUEL PRESSURE REGULATOR REPLACEMENT»(ref-320436-S41654858282009071400000) ), then go to step 24 .
15. Start the engine. Hold the engine speed at 3,000 rpm without load (A/T in P or N, M/T in neutral) until the radiator fan comes on, then let it idle.
16. Check under these conditions: Engine coolant temperature (ECT SENSOR 1) above 176°F (80°C) A/T in P or N, M/T in neutral All electrical loads off
17. Monitor the ENGINE SPEED in the DATA LIST with the HDS, and hold the engine speed at 2,500 rpm. Once the engine speed is met, hold the accelerator pedal steady for more than 10 seconds. Did the engine speed vary more than 100 rpm from 2,500 rpm? YES: Repeat step 17 . NO: Go to step 18 .
18. While holding the engine speed at 2,500 rpm, check the MAF SENSOR in the DATA LIST with the HDS. Is there about 4.6-5.7 gm/s (M/T), 4.7-5.7 gm/s (A/T)? YES: Go to step 19 . NO: Replace the MAF sensor/IAT sensor (see «MAF SENSOR/IAT SENSOR REPLACEMENT»(ref-320426-S41968704082009071400000) ), then go to step 24 .
19. Turn the ignition switch to LOCK (0).
20. Remove the rocker arm oil pressure switch.
21. Attach the special tools to the rocker arm oil control valve as shown, then attach the rocker arm oil pressure switch (A) in the pressure gauge adapter (B).
22. Start the engine. Hold the engine speed at 3,000 rpm without load (A/T in P or N, M/T in neutral) until the radiator fan comes on, then let it idle.
23. Check the oil pressure at engine speeds of 1,000 rpm and 2,000 rpm. Is the oil pressure below 49 kPa (0.5 kgf/cm 2 , 7 psi)? YES: Go to step 24 . NO: Inspect the VTEC system, then go to step 24 .
24. Turn the ignition switch to ON (II).
25. Reset the ECM/PCM with the HDS.
26. Clear the CKP pattern with the HDS.
27. Do «ECM/PCM IDLE LEARN PROCEDURE»(ref-320447-S03803966382009071400000) .
28. Do «CKP PATTERN CLEAR/CKP PATTERN LEARN»(ref-320425-S23638437822009071400000) .
29. Test-drive the vehicle for several minutes in the range of these recorded freeze data parameters: ENGINE SPEED VSS REL TP SENSOR CLV (calculated load value) APP SENSOR
30. Check for Pending or Confirmed DTCs with the HDS. Is DTC P0300, P0301, P0302, P0303, or P0304 indicated? YES: Check for poor connections or loose terminals at the ignition coils, the injectors, and the ECM/PCM, then go to the troubleshooting for DTC P0301, P0302, P0303, or P0304 (see «DTC P0301, P0302, P0303, P0304: NO. 1 CYLINDER MISFIRE DETECTED; NO. 2 CYLINDER MISFIRE DETECTED; NO. 3 CYLINDER MISFIRE DETECTED; NO. 4 CYLINDER MISFIRE DETECTED»(ref-320426-S05596917672009071400000) ). NO: Go to step 31 .
31. Monitor the OBD STATUS for DTC P0301, P0302, P0303, or P0304 in the DTCs MENU with the HDS. Does the screen indicate PASSED? YES: Troubleshooting is complete. If any other Pending or Confirmed DTCs were indicated in step 30 , go to the indicated DTC's troubleshooting. NO: If the HDS indicates FAILED, go to step 1 and recheck. If the HDS indicates EXECUTING, keep driving until a result comes on. If the HDS indicates OUT OF CONDITION or NOT COMPLETED, go to step 29 .

O2 sensor wrench, Snap-on S6176 or equivalent, commercially available

Scheme 169

Scheme 170

1. Remove the cowl cover (see «COWL COVER REPLACEMENT»(ref-320465-S23588023462009071400000) ) and the under-cowl panel (see «UNDER-COWL PANEL REPLACEMENT»(ref-320448-S09609825902009071400000) ).
2. Disconnect the A/F sensor connector (A).
3. Remove the A/F sensor (A).
4. Install the parts in the reverse order of removal.

O2 sensor wrench, Snap-on S6176 or equivalent, commercially available

Scheme 171

Scheme 172

1. Disconnect the secondary HO2S connector (A).
2. Raise the vehicle on a lift.
3. Remove the supporters (A), then remove the secondary HO2S (B).
4. Install the parts in the reverse order of removal.

Scheme 173

1. Remove the cowl cover (see «COWL COVER REPLACEMENT»(ref-320465-S23588023462009071400000) ) and the under-cowl panel (see «UNDER-COWL PANEL REPLACEMENT»(ref-320448-S09609825902009071400000) ).
2. Remove the air cleaner (see «AIR CLEANER REMOVAL/INSTALLATION»(ref-320437-S29837794652009071400000) ).
3. Disconnect the CMP sensor connector (A).
4. Remove the CMP sensor (B).
5. Install the parts in the reverse order of removal with a new O-ring (C).

Scheme 174

Scheme 175

1. Raise the vehicle on a lift. NOTE: Make sure the vehicle is level, because engine oil will drip out when you remove the sensor.
2. Remove the CKP sensor cover (A).
3. Disconnect the CKP sensor connector (A).
4. Remove the CKP sensor (B).
5. Install the parts in the reverse order of removal with a new O-ring (C).
6. Do the CKP pattern clear/CKP pattern learn procedure (see «CKP PATTERN CLEAR/CKP PATTERN LEARN»(ref-320425-S23638437822009071400000) ).
7. Check the engine oil level, and add more oil if needed.

Scheme 176

1. Raise the vehicle on a lift.
2. Disconnect the output shaft (countershaft) speed sensor connector (A).
3. Remove the output shaft (countershaft) speed sensor (B).
4. Install the parts in the reverse order of removal with a new O-ring (C).

Scheme 177

1. Disconnect the knock sensor connector (A).
2. Remove the knock sensor (B).
3. Install the parts in the reverse order of removal.

Scheme 178

1. Disconnect the MAP sensor connector (A).
2. Remove the MAP sensor (B).
3. Install the parts in the reverse order of removal with a new O-ring (C).

Scheme 179

1. Disconnect the MAF sensor/IAT sensor connector (A).
2. Remove the screws (B).
3. Remove the MAF sensor/IAT sensor (C).
4. Install the parts in the reverse order of removal with a new gasket (D).

Scheme 180

Scheme 181

1. Drain the engine coolant (see «COOLANT CHECK»(ref-320432-S30222595332009071400000) ).
2. Remove the air cleaner (see «AIR CLEANER REMOVAL/INSTALLATION»(ref-320437-S29837794652009071400000) ).
3. Remove the hose clamp stay bolt (A).
4. Disconnect the ECT sensor 1 connector (A).
5. Remove ECT sensor 1 (B).
6. Install the parts in the reverse order of removal with a new O-ring (C), then refill the radiator with engine coolant (see «COOLANT CHECK»(ref-320432-S30222595332009071400000) ).

Scheme 182

1. Drain the engine coolant (see «COOLANT CHECK»(ref-320432-S30222595332009071400000) ).
2. Raise the vehicle on a lift.
3. Disconnect the ECT sensor 2 connector (A), then remove ECT sensor 2 (B).
4. Install the parts in the reverse order of removal with a new O-ring (C), then refill the radiator with engine coolant (see «COOLANT CHECK»(ref-320432-S30222595332009071400000) ).

Scheme 183

Scheme 184

1. Remove the under-dash fuse/relay box (see «REMOVAL AND INSTALLATION»(ref-320466-S37197492852009071400000) ).
2. Remove the fuse (A).
3. Remove the joint bar (B).
4. Turn over the under-dash fuse/relay box, then remove the ELD (A).
5. Install the parts in the reverse order of removal.

1. Honda diagnostic system (HDS) tablet tester
2. Honda interface module (HIM) and an iN workstation with the latest HDS software version
3. HDS pocket tester
4. GNA600 and an iN workstation with the latest HDS software version

Any one of the above updating tools can be used.

Note. Use this procedure when you need to update the ECM/PCM at any time. Make sure the HDS/iN workstation has the latest HDS software version. Before you update the ECM/PCM, make sure the battery in the vehicle is fully charged, and connect a jumper battery (not a battery charger) to maintain system voltage. Never turn the ignition switch to ACC (I) or LOCK (0) during the update. If there is a problem with the update, leave the ignition switch ON (II). To prevent ECM/PCM damage, do not operate anything electrical (headlights, audio system, brakes, A/C, power windows, door locks, etc.) during the update. To ensure the latest program is installed, do an ECM/PCM update whenever the ECM/PCM is substituted or replaced. You cannot update an ECM/PCM with a program it already has. It will only accept a new program. High temperature in the engine compartment might cause the ECM/PCM to become too hot to run the update. If the engine has been running before this procedure, open the hood and cool the engine compartment. If you need to diagnose the Honda interface module (HIM) because the HIM's red (# 3) light came on or was flashing during the update, leave the ignition switch in ON (II) when you disconnect the HIM from the data link connector (DLC). This prevents damage to the ECM/PCM.

Scheme 185

1. Turn the ignition switch to ON (II), but do not start the engine.
2. Connect the HDS to the data link connector (DLC) (A) located under the driver's side of the dashboard.
3. Make sure the HDS communicates with the ECM/PCM and other vehicle systems. If it doesn't, go to «DLC CIRCUIT TROUBLESHOOTING»(ref-320426-S32678800202009071400000) . If you are returning from the DLC circuit troubleshooting, skip steps 4 and 5 , and clean the throttle body after updating the ECM/PCM (see «THROTTLE BODY CLEANING»(ref-320437-S26671565662009071400000) ).
4. Select the INSPECTION MENU with the HDS.
5. Select the ETCS TEST, then select the TP POSITION CHECK, and follow the HDS screen prompts. NOTE: If the TP POSITION CHECK indicates FAILED, continue this procedure.
6. Exit the HDS diagnostic system, then select the update mode, and follow the screen prompts to update the ECM/PCM.
7. If the software in the ECM/PCM is the latest, disconnect the HDS/HIM from the DLC, and go back to the procedure that you were doing. If the software in the ECM/PCM is not the latest, follow the instructions on the screen. If prompted to choose the PGM-FI system or the A/T system, make sure you update both. NOTE: If the ECM/PCM update system requires you to cool the ECM/PCM, follow the instructions on screen. If you have a problem during the update procedure (programming takes over 15 minutes, status bar goes over 100%, D (A/T) or immobilizer indicator flashes, HDS tablet freezes, etc.), follow these steps to minimize the chance of damaging the ECM/PCM: Leave the ignition switch in the ON (II) position. Connect a jumper battery (do not connect a battery charger). Shut down the HDS. Disconnect the HDS from the DLC. Reboot the HDS. Reconnect the HDS to the DLC, and try the update procedure again.
8. If the TP POSITION CHECK failed in step 5 , clean the throttle body (see «THROTTLE BODY CLEANING»(ref-320437-S26671565662009071400000) ).
9. Do «ECM/PCM IDLE LEARN PROCEDURE»(ref-320447-S03803966382009071400000) .
10. Do the CKP pattern learn procedure (see «CKP PATTERN CLEAR/CKP PATTERN LEARN»(ref-320425-S23638437822009071400000) ).

1. Honda diagnostic system (HDS) tablet tester
2. Honda interface module (HIM) and an iN workstation with the latest HDS software version
3. HDS pocket tester
4. GNA600 and an iN workstation with the latest HDS software version

Any one of the above updating tools can be used.

Note. Make sure the HDS/iN workstation has the latest HDS software version.

Scheme 186

Scheme 187

Scheme 188

1. Connect the HDS to the data link connector (DLC) (A) located under the driver's side of the dashboard.
2. Turn the ignition switch to ON (II).
3. Make sure the HDS communicates with the ECM/PCM and other vehicle systems. If it doesn't, go to «DLC CIRCUIT TROUBLESHOOTING»(ref-320426-S32678800202009071400000) . If you are returning from the DLC circuit troubleshooting, skip steps 4 through 9 , 19 through 24 , and 27 through 29 , and do these procedures after replacing the ECM/PCM: Replace the engine oil (see «ENGINE OIL LEVEL CHECK»(ref-320427-S42842234232009071400000) ) and the engine oil filter (see «ENGINE OIL FILTER REPLACEMENT»(ref-320427-S38088097852009071400000) ). Replace the ATF (A/T) (see «ATF REPLACEMENT»(ref-379915-S36551758442010121600000) ). Clean the throttle body (see «THROTTLE BODY CLEANING»(ref-320437-S26671565662009071400000) ).
4. Select the PGM-FI system with the HDS.
5. Select the INSPECTION MENU with the HDS.
6. Select the ETCS TEST, then select the TP POSITION CHECK, and follow the screen prompts. NOTE: If the TP POSITION CHECK indicates FAILED, continue with this procedure.
7. Select the REPLACE ECM/PCM MENU, then select READ DATA, and follow the screen prompts. NOTE: Doing this step copies (READS) the engine oil life data from the original ECM/PCM so you can later download (WRITES) it into the new ECM/PCM. If READ DATA indicates FAILED, continue with this procedure.
8. A/T: Select the A/T system with the HDS.
9. A/T: Select the REPLACE TCM/PCM MENU, then READ DATA, and follow the screen prompts. NOTE: A/T: Doing this step copies (READS) the ATF life data from the original PCM so you can later download (WRITES) it into the new PCM. A/T: If READ DATA indicates FAILED, continue with this procedure.
10. Jump the SCS line with the HDS.
11. Turn the ignition switch to LOCK (0).
12. Remove the ECM/PCM cover (A).
13. Remove the battery holder (B), and reposition the battery away from the ECM/PCM. NOTE: Do not disconnect the battery terminals.
14. Remove the bolts (D), and loosen the bolt (E).
15. Disconnect ECM/PCM connectors A, B, and C, then remove the ECM/PCM (F). NOTE: ECM/PCM connectors A, B, and C have symbols (A=[], B=delta, C=o) embossed on them for identification.
16. Install a known-good ECM/PCM in the reverse order of removal.
17. Turn the ignition switch to ON (II).
18. Manually input the VIN to the ECM/PCM with the HDS. NOTE: DTC P0630 (VIN Not Programmed or Mismatch) may be stored because the VIN has not been programmed into the ECM/PCM; ignore it, and continue this procedure.
19. If the READ DATA (engine oil life) failed in step 7 , go to step 22 (A/T) or step 25 (M/T). Otherwise, go to step 20 .
20. Select the PGM-FI system with the HDS.
21. Select the REPLACE ECM/PCM MENU, then WRITE DATA, and follow the screen prompts. NOTE: If the WRITE DATA indicates FAILED, continue with this procedure.
22. A/T: If the READ DATA (ATF life) failed in step 8 , go to step 25 . Otherwise go to step 23 .
23. A/T: Select the A/T SYSTEM with the HDS.
24. A/T: Select the REPLACE ECM/PCM MENU, then WRITE DATA, and follow the screen prompts. NOTE: A/T: If the WRITE DATA indicates FAILED, continue with this procedure.
25. Select IMMOBI system with the HDS.
26. Enter the immobilizer code that you got from the iN, or use the ECM/PCM replacement procedure in the HDS; it allows you to start the engine.
27. If the TP POSITION CHECK failed in step 6 clean the throttle body (see «THROTTLE BODY CLEANING»(ref-320437-S26671565662009071400000) ), then go to step 28 .
28. If the READ DATA failed in step 7 or the WRITE DATA failed in step 21 , replace the engine oil (see «ENGINE OIL LEVEL CHECK»(ref-320427-S42842234232009071400000) ) and the engine oil filter (see «ENGINE OIL FILTER REPLACEMENT»(ref-320427-S38088097852009071400000) ), then go to step 29 (A/T) or step 30 (M/T).
29. If the READ DATA failed in step 9 or the WRITE DATA failed in step 24 , replace the ATF (see «ATF REPLACEMENT»(ref-379915-S36551758442010121600000) ), then go to step 30 .
30. Select the PGM-FI system, and reset the ECM/PCM with the HDS.
31. Update the ECM/PCM if it does not have the latest software (see «ECM/PCM UPDATE»(ref-320426-S22945234462009071400000) ).
32. Do «ECM/PCM IDLE LEARN PROCEDURE»(ref-320447-S03803966382009071400000) .
33. Do the CKP pattern learn procedure (see «CKP PATTERN CLEAR/CKP PATTERN LEARN»(ref-320425-S23638437822009071400000) ).
