Seat Belts: Component Locations Honda Element YH2 рестайлинг 2

Restraints Control Systems 11 illustrations ~774 words

Special Tools Required

KTC trim tool set SOJATP2014*

  1. Available through the American Honda Tool and Equipment Program; call 888-424-6857

SRS components are located in this area. Review the SRS COMPONENT LOCATION INDEX and PRECAUTIONS AND PROCEDURES , before performing repairs or service.

Note. Use the appropriate tool from the KTC trim tool set to avoid damage when prying components. Take care not to tear the seams or damage the seat covers. Put on gloves to protect your hands. Check the front seat belts for damage (see INSPECTION ), and replace them if necessary. Be careful not to damage them during removal and installation.

Scheme 6

Scheme 6: Front Seat Belt
Scheme 6: Front Seat Belt

Scheme 7

Scheme 7
Scheme 7

Scheme 8

Scheme 8
Scheme 8

Scheme 9

Scheme 9
Scheme 9

Scheme 10

Scheme 10
Scheme 10

Scheme 11

Scheme 11
Scheme 11

Scheme 12

Scheme 12
Scheme 12

Scheme 13

Scheme 13
Scheme 13
  1. Make sure you have the anti-theft code for the audio system, then write down the audio presets.
  2. Disconnect the negative cable from the battery, and wait at least 3 minutes before beginning work.
  3. Remove the front seat (see «FRONT SEAT REMOVAL/INSTALLATION»(ref-290866-S25622170252008072200000) ).
  4. Remove these items: Front seat-back cover (see «FRONT SEAT-BACK COVER REPLACEMENT»(ref-290866-S22730701142008072200000) ) Front seat recline cover (see step 2 on «FRONT SEAT CUSHION COVER REPLACEMENT»(ref-290866-S38410594852008072200000) )
  5. Remove the lower anchor (A).
  6. Remove these items: Front seat cushion cover (see «FRONT SEAT CUSHION COVER REPLACEMENT»(ref-290866-S38410594852008072200000) ) Front seat belt buckle
  7. Remove the front seat belt upper anchor (A).
  8. Remove the screws (B), and the seat belt sleeve bracket (C) from the seat frame (D).
  9. Detach the clip (E), then release the seat belt sleeve (F).
  10. Detach the clips (A, B), then release the clips (C), and remove the recline rear cover (D) from the seat frame (E).
  11. Remove the bolts (A), and the seat cushion protector (B) from the seat frame (C).
  12. Disconnect and detach the seat belt tensioner connectors (A). Remove the wire tie (B) and detach the clip (C).
  13. Remove the retractor mounting bolt (A), then remove the front seat belt and retractor (B).
  14. Install the seat belt in the reverse order of removal, and note these items: Apply liquid thread lock to the anchor bolts before reinstallation. Tighten the bolts by hand first, then tighten them to specification with a torque wrench. Check that the retractor locking mechanism functions (see «INSPECTION»(ref-290865-S09809402622008072200000) ). Assemble the washers, on the upper and lower anchor bolts as shown. If the seat belt tensioner has been deployed, replace the seat belt protector with a new one. Before installing the anchor bolts, make sure there are no twists or kinks in the seat belt. Make sure the seat belt tensioner connector is plugged in properly. Check if the clips are damaged or stress-whitened, and if necessary, replace them with new ones. Reconnect the negative cable to the battery. Enter the anti-theft code for the audio system, then enter the audio presets. Reset the clock. Do the power window control unit reset procedure (see «RESETTING THE POWER WINDOW CONTROL UNIT»(ref-290808-S20236797192008072200000) ). Upper anchor bolt installation Lower anchor bolt installation

Scheme 14

Scheme 14: Seat Belt Buckle
Scheme 14: Seat Belt Buckle

Scheme 15

Scheme 15
Scheme 15

Scheme 16

Scheme 16
Scheme 16
  1. Make sure you have the anti-theft code for the audio system, then write down the audio presets.
  2. Disconnect the negative cable from the battery, and wait at least 3 minutes before beginning work.
  3. Remove the front seat (see «FRONT SEAT REMOVAL/INSTALLATION»(ref-290866-S25622170252008072200000) ).
  4. Lift up the front seat, then detach the seat belt buckle switch connector (A) and seat belt buckle tensioner connector (B), and on the driver's seat, remove the wire tie (C). On the passenger's seat, detach the harness clip (D).
  5. Remove the center cover from the seat; driver's seat (see «FRONT SEAT CUSHION COVER REPLACEMENT»(ref-290866-S38410594852008072200000) ), passenger's seat (see «FRONT SEAT CUSHION COVER REPLACEMENT»(ref-290866-S38410594852008072200000) ).
  6. Pull the seat belt buckle switch/tensioner harness (A) out through the space between the seat cushion and the seat linkage (driver's seat), or the hole on the seat track (passenger's seat).
  7. Remove the center anchor bolt (B), and remove the seat belt buckle (C).
  8. Install the seat belt buckle in the reverse order of removal, and note these items: Apply liquid thread lock to the center anchor bolt before reinstalling it, and collar. Assemble the washers and collar on the center anchor bolt as shown. If the seat belt tensioner has been deployed, replace the front seat belt protector with a new one. Apply liquid thread lock to the seat mounting bolts before reinstallation. Tighten the bolts by hand first, then tighten them to specification with a torque wrench. Reconnect the negative cable to the battery. Enter the anti-theft code for the audio system, then enter the audio presets. Reset the clock. Do the power window control unit reset procedure (see «RESETTING THE POWER WINDOW CONTROL UNIT»(ref-290808-S20236797192008072200000) ). Center anchor bolt installation
