Seat Belts: Removal & Installation Honda Element YH2 рестайлинг 2

Rear Seat Belt Replacement

Note. Check the rear seat belts for damage, and replace them if necessary. Be careful not to damage them during removal and installation.

Scheme 3

Scheme 4

Scheme 5

1. Remove these items: Cargo floor lid (see «TRIM REMOVAL/INSTALLATION - CARGO AREA»(ref-290846-S04774016742008072200000) ) Rear trim panel (see «TRIM REMOVAL/INSTALLATION - CARGO AREA»(ref-290846-S04774016742008072200000) ) Rear seat Rear seat striker (see «REAR SEAT STRIKER REPLACEMENT»(ref-290866-S23266936832008072200000) )
2. Remove the lower anchor bolt.
3. Remove the rear side trim panel (see «TRIM REMOVAL/INSTALLATION - REAR SIDE AREA»(ref-290846-S31031747122008072200000) ).
4. Remove the C-pillar trim (see «TRIM REMOVAL/INSTALLATION - REAR SIDE PILLAR AREA»(ref-290846-S40345882242008072200000) ).
5. Remove the upper quarter window trim (see «TRIM REMOVAL/INSTALLATION - REAR SIDE PILLAR AREA»(ref-290846-S40345882242008072200000) ).
6. Remove the upper anchor bolt (A).
7. Remove the retractor bolt (A), then remove the rear seat belt (B) and retractor (C).
8. If necessary, remove the seat belt protector (D).
9. Install the seat belt in the reverse order of removal, and note these items: Apply liquid thread lock to the anchor bolts before reinstallation. Tighten the bolts by hand first, then tighten them to specification with a torque wrench. Check that the retractor locking mechanism functions as described (see «INSPECTION»(ref-290865-S09809402622008072200000) ). Before installing the anchor bolts, make sure there are no twists or kinks in the seat belt.
