Engine Lubrication System: Other Honda Element YH2 рестайлинг 2

Engine Oil Level Check

1. Park the vehicle on level ground, and start the engine. Hold the engine speed at 3,000 rpm with no load (in N or P (A/T Model) or Neutral (M/T model)) until the radiator fan comes on , then turn off the engine, and wait a few minutes.
2. Remove the dipstick, and wipe off the dipstick, then reinstall the dipstick.
3. Remove the dipstick, and check the engine oil level. It should be between the upper mark (A) and the lower mark (B).
4. If the engine oil level is near or below the lower mark, add the recommended engine oil to bring it between the upper and lower marks.

Scheme 35

1. Warm up the engine.
2. Remove the drain bolt (A), and drain the engine oil.
3. Reinstall the drain bolt with a new washer (B).
4. Refill with the recommended oil (see «LUBRICANTS AND FLUIDS»(ref-290811-S36474412962008072200000) ). Capacity At Oil Change: 4.0 L (4.2 US qt) At Oil Change including Filter: 4.2 L (4.4 US qt) After Engine Overhaul: 5.3 L (5.6 US qt)
5. Connect the Honda Diagnostic System (HDS) to the data link connector (DLC) (see step 2 on page 11-3).
6. Turn the ignition switch ON (II).
7. Make sure the HDS communicates with the vehicle and the engine control module (ECM)/powertrain control module (PCM). If it doesn't communicate, troubleshoot the DLC circuit (see «DLC CIRCUIT TROUBLESHOOTING»(ref-355245-S06359967292010012100000) ).
8. Select BODY ELECTRICAL with the HDS.
9. Select ADJUSTMENT in the GAUGES MENU with the HDS.
10. Select RESET in the MAINTENANCE MINDER with the HDS.
11. Select RESETTING THE ENGINE OIL LIFE with the HDS. NOTE: If you changed the ATF at the same time with the engine oil, select RESETTING THE ENGINE OIL LIFE AND ATF with the HDS instead.
12. Run the engine for more than 3 minutes, then check for oil leakage.
13. Reset the multi-information display (see «RESETTING THE MAINTENANCE INFORMATION DISPLAY»(ref-290811-S12906300162008072200000) ).
