Sunvisor Removal/Installation
Note. When using a flat-tip screwdriver, wrap it with protective tape to prevent damage.
Scheme 29
Scheme 30
Scheme 31
Scheme 32
- Release the tabs (A) on both sides with the appropriate tool from the KTC trim tool set, then remove the sunvisor cap (B) from the bracket (C). Turn the cap, and remove it.
- Remove the sunvisor (A). Remove the sunvisor from the holder (B). Using a TORX T25 bit, remove the screws. Remove the sunvisor from the body.
- Using a flat-tip screwdriver, push the hook (A), and turn the holder (B) 90°, then pull it out.
- Install the sunvisor in the reverse order of removal, and note these items: If the side curtain airbag has deployed, replace the sunvisor with a new one. To prevent the side curtain airbags from deploying improperly and possibly causing injury, inspect removed pieces and replace them if they have any of these types of damage: Any cracks in the sunvisor stay base (A) Any bends or cracks in the sunvisor stay shaft (B) Any cracks in the sunvisor base (C) If the threads on a visor screws are worn out, use an oversized self-tapping ET screw, P/N 90137-S30-003, made specifically for this application.
Floor Covering Replacement
Special Tools Required
KTC trim tool set SOJATP2014 *
* Available through the American Honda Tool and Equipment Program; call 888-424-6857
SRS components are located in this area. Review the SRS COMPONENT LOCATION INDEX and PRECAUTIONS AND PROCEDURES , before performing repairs or service.
Note. Put on gloves to protect your hands. Use the appropriate tool from the KTC trim tool set to avoid damage when prying components. Take care not to damage, wrinkle or twist the floor covering. Be careful not to damage the dashboard or other interior trim pieces.
Scheme 33
- Remove these items: Front seats, both sides (see «FRONT SEAT REMOVAL/INSTALLATION»(ref-290866-S25622170252008072200000) ) Door sill trim, both sides (see «TRIM REMOVAL/INSTALLATION - DOOR AREAS»(ref-290846-S09306060772008072200000) ) Kick panels, both sides (see «TRIM REMOVAL/INSTALLATION - DOOR AREAS»(ref-290846-S09306060772008072200000) ) Passenger's dashboard undercover (see «PASSENGER'S DASHBOARD UNDERCOVER REMOVAL/INSTALLATION»(ref-290806-S30518185312008072200000) ) Center lower cover (see «CENTER LOWER COVER REMOVAL/INSTALLATION»(ref-290806-S10272235662008072200000) ) Center console (see «CENTER CONSOLE REMOVAL/INSTALLATION»(ref-290853-S34235352102008072200000) ) Subwoofer (see «SUBWOOFER»(ref-290858-S35186389972008072200000) )
- Remove the front floor covering (A). -1 Detatch the clips -2 Remove the screw, then remove the floor mat holder (B). -3 Release the Velcro fastener (C), then pull back the floor covering from under the heater unit. -4 Release the Velcro fasteners (D) on the front edge of the floor covering, then pull back the floor covering from under the dashboard.
- Remove the front floor covering.
- Install the floor covering in the reverse order of removal, and note these items: Take care not to damage, wrinkle or twist the floor covering. Make sure the seat harnesses are routed correctly. Check if the clips are damaged or stress-whitened, and if necessary, replace them with new ones. Push the clips into place securely.
Scheme 34
- Remove these items: Front seats, both sides (see «FRONT SEAT REMOVAL/INSTALLATION»(ref-290866-S25622170252008072200000) ) Door sill trim, both sides (see «TRIM REMOVAL/INSTALLATION - DOOR AREAS»(ref-290846-S09306060772008072200000) ) Rear side trim panel, both sides (see «TRIM REMOVAL/INSTALLATION - REAR SIDE AREA»(ref-290846-S31031747122008072200000) ) Center console (see «CENTER CONSOLE REMOVAL/INSTALLATION»(ref-290853-S34235352102008072200000) )
- Remove the clips, then remove the rear floor covering (A).
- Install the floor covering in the reverse order of removal, and note these items: Take care not to damage, wrinkle or twist the floor covering. Check if the clips are damaged or stress-whitened, and if necessary, replace them with new ones. Push the clips into place securely.
