Consoles: Other Honda Element YH2 рестайлинг 2

SC Model

Note. Put on gloves to protect your hands. Use the appropriate tool from the KTC trim tool set to avoid damage when prying components. Take care not to scratch the center console, dashboard, and related parts.

Scheme 78

Scheme 79

Scheme 80

Scheme 81

Scheme 82

Scheme 83

Scheme 84

1. Push and pull the hook (A) of the beverage holder (B) up, then remove it.
2. Pull up on the parking brake lever fully.
3. Remove the front trim mat (A). Pull the rear portion of the center console front trim (B) up to detach the clips (C) and hook (D), then pull it backward to release the clips (E) and remove it.
4. Remove the center console rear trim (A). Open the armrest, and remove the bolt (B) from the bottom of the trim. Pull the right side portion of the trim up to release the hooks (C) and clips (D). Pull the left side portion of the trim up to detach the clips (E) and hooks by pulling the trim up by hand securely. Remove the trim away from the parking brake lever.
5. Disconnect the console accessory power socket connector (A) from the bottom of the center console. Remove the bolts (B, C).
6. Remove the console box mat (A) and bolts.
7. Lift up the rear of the console, and pull it backward to release the pins (A) and clips from the dashboard, then remove the center console (B).
8. Remove the tray mat (A). Pull the rear portion of the center floor tray (B) up and backward to release the clips (C, D) and remove it from the subwoofer.
9. Install the console in the reverse order of removal, and note these items: Check if the clips are damaged or stress-whitened, and if necessary, replace them with new ones. Push the clips and hooks into place securely. Make sure the console accessory power socket connector is plugged in properly.

Except SC Models ('07-08 Models)

Note. Take care not to scratch the front seat and related parts.

Scheme 85

1. Pull the front edge of the center console (A) to release the clips, and remove the console by releasing the hooks (B).
2. Install the console in the reverse order of removal, and note these items: Check if the clips are damaged or stress-whitened, and if necessary, replace them with new ones. Push the clip portions into place securely.

Except SC Models ('09-11 Models)

Note. Take care not to scratch the front seat and related parts. Use the appropriate tool from the KTC trim tool set to avoid damage when removing components.

Scheme 86

Scheme 87

Scheme 88

Scheme 89

1. Pivot the handle (A) to the unlock position, and slide the removable cooler/console (B) rearward, then pull it up.
2. Push in where indicated to release the hook (A), and pull up on the beverage holder (B) to release the tabs (C), then remove the holder.
3. Pry out on the notch of the cover (A) to release the hooks (B) with the appropriate trim tool, then remove the cover.
4. Remove the bolts. Pull up the front edge of the center console (A) to release the clips, and remove the console.
5. Install the console in the reverse order of removal, and note these items: If the clips are damaged or stress-whitened, replace them with new ones. Push the clips and the hooks into place securely.

Note. Take care not to scratch the armrest, center console and related parts.

Scheme 90

Scheme 91

1. Open the armrest (A), then remove the screws (B). Pull out the armrest base (C) to detach the clips (D), then remove it.
2. Remove the screws, then remove the center console armrest (A) from the armrest upper hinge (B).
3. Install the center console armrest in the reverse order of removal and check if the clips are damaged or stress-whitened, and if necessary, replace them with new ones.

Note. Take care not to scratch the armrest, center console and related parts.

Scheme 92

Scheme 93

Scheme 94

1. Remove the center console armrest (see «CENTER CONSOLE ARMREST REMOVAL/INSTALLATION»(ref-290853-S21479663892008072200000) ).
2. Release the latch cable (A) from hooks (B) of the center console armrest (C). Detach the cable from the front cable bracket (D) and rear cable bracket (E).
3. Remove the screws, then remove the armrest front lock (A) and armrest rear lock (B) and cable (C) together.
4. Release the cable (A) from the front lock (B) and rear lock (C), then remove the locks.
5. Install the locks in the reverse order of removal, and make sure they are connected securely.

Note. Put on gloves to protect your hands. Use the appropriate tool from the KTC trim tool set to avoid damage when prying components. Take care not to scratch the center console and related parts.

Scheme 95

Scheme 96

Scheme 97

Scheme 98

Scheme 99

Scheme 100

Scheme 101

1. Remove the these items: Center console (see «CENTER CONSOLE REMOVAL/INSTALLATION»(ref-290853-S34235352102008072200000) ) Center console armrest (see «CENTER CONSOLE ARMREST REMOVAL/INSTALLATION»(ref-290853-S21479663892008072200000) )
2. Gently pull out the driver's console trim (A) to detach the clips (B, C), then remove the trim by releasing the hooks (D).
3. Remove the screws, then remove the driver's center console side trim (A) from the center console (B).
4. Remove the screws (A, B), and pull out the passenger's console trim (C) to detach the clips (D), then remove it.
5. Remove the screws, then remove the center passenger's console side trim (A) from the center console (B).
6. Remove the center console (A). Disconnect the console accessory power socket connector (B) and auxiliary jack connector (C), and detach the harness clips (D), then remove the console wire harness (E). Remove the screw (F), and remove the harness bracket (G). Pull out the maintenance lid (H) to detach the clip (I), and remove it. Remove the screws (J), then pull out the center console (K) to detach the clips (L), and remove it.
7. Remove the screws, and remove the lower hinge bracket (A) and lower hinge (B) from the console box (C).
8. Remove the screws (A, B), and separate the frame brackets (C, D), then remove the center console box (E).
9. Install the center console in the reverse order of removal, and note these items: Check if the clips are damaged or stress-whitened, and if necessary, replace them with new ones. Push the clips and hooks into place securely. Make sure each connector is plugged in properly.
