Front Door Sill Area

Note. Put on gloves to protect your hands. Use the appropriate tool from the KTC trim tool set to avoid damage when prying components. Take care not to bend or scratch the trim and panels.

Scheme 56

Scheme 56: Front Door Sill Area

Scheme 57

Scheme 58

Scheme 59

Scheme 60

Scheme 61

Remove the front seat track floor cover. Slide the front seat forward fully. Pull the front seat track floor cover (A) up by hand to detach the clips (B, C) and release the hooks (D) from the carpet, then remove the cover.
Pull the front door sill trim (A) up by hand to detach the clips (B, C, D), then remove the trim.
Remove the left kick panel (A) or the right kick panel (B). Pull out the front door inner seal (C) from the kick panel hooks (D) and the front door opening flange. Pull the kick panel back by hand to detach the clips (E, F), then remove the panel. On the driver's side, pull the hood opener knob (G) and hold it while removing the panel. Driver's side Passenger's side ('07-08 models) Passenger's side ('09 model)
Pull out the front door inner seal (A) from the trim hooks (B) and around the front door opening flange, then remove the seal.
Install the trim in the reverse order of removal, and note these items: Check if the clips are damaged or stress-whitened, and if necessary, replace them with new ones. Push the clips into place securely.

A-Pillar Trim

SRS components are located in this area. Review the SRS COMPONENT LOCATION INDEX and PRECAUTIONS AND PROCEDURES , before performing repairs or service.

Note. Follow the A-pillar trim installation procedure carefully; improper installation could cause the side curtain airbag to deploy improperly and possibly cause injury. Put on gloves to protect your hands. Use the appropriate tool from the KTC trim tool set to avoid damage when prying components. Take care not to scratch the trim and panels. The upper clip in the A-pillar trim (A) consists of a grommet (B) and a pin (C). The grommet expands when the pin secures it to the body panel (D). The projections (E) on the pin are broken during removal, so the clip must be replaced with a new one when the trim is reinstalled.

Scheme 62

Scheme 62: A-Pillar Trim

Scheme 63

Scheme 64

Scheme 65

Scheme 66

Scheme 67

Scheme 68

Pull the front door inner seal away from the front pillar as needed (see step 3 on «FRONT DOOR SILL AREA»(ref-290846-S03427765922008072200000) ).
Hit the upper clip in the front pillar trim (A) with a rubber mallet. The clip is under the point (B) on the edge of the trim indicates. Hitting the clip breaks the projections (C) on the pin (D) and pushes it into the grommet (E) and against the body (F). The grommet becomes narrow. NOTE: The clip must be replaced with a new one when the front pillar trim is reinstalled.
Pull the top of the A-pillar trim (A) back by hand to remove the upper clip (B) from the body (C).
Pull the A-pillar trim (A) by hand to detach the clip. Pull the trim up from the dashboard (B), then disconnect the tweeter connector (C) (if equipped) and remove the trim.
If the side curtain airbag has deployed, replace the A-pillar trim and all clips on the trim with new ones.
If the side curtain airbag has not deployed, remove the upper clip (A) from the removed A-pillar trim (B) and discard it. Then check the trim: To prevent the side curtain airbags from deploying improperly and possibly causing injury, inspect the A-pillar trim and replace it if it has any of these types of damage: Any cracks, deformations, or stress-whitened areas in the A-pillar trim Any cracks or stress-whitening in the clip seating surfaces (C, D) Check if the clip (E) is damaged or stress-whitened, and if necessary, replace it with a new one. Replace the upper clip with a new one.
Before installing the A-pillar trim (A), whether it is being replaced or reinstalled, temporarily remove the new upper clip (B).
Temporarily install the A-pillar trim (without the upper clip) to check the overlap between the trim and the headliner. Remove the trim, and if necessary, adjust it (see «CHECKING AND ADJUSTING THE HEADLINER/PILLAR TRIM OVERLAP»(ref-355246-S23540158022010012100000) ).
Carefully install a new upper clip (A) to the A-pillar trim (B). Be sure that the grommet (C) is nearest to the top of the pin (D) as shown.
Reinstall the A-pillar trim (A). Connect the tweeter connector (for some models). Insert the bottom of the trim into the dashboard (B). Place the trim over the A-pillar (C), and fit its upper clip (D), and lower clip into the holes (E) in the A-pillar, then lightly push the trim into place. NOTE: Make sure the side curtain airbag isn't tucked down under the clips and ribs. Push lightly on the upper clip. If you push too hard, the clip will be damaged, and it will not hold the trim properly.
Reinstall the door inner seal.

Rear Side Trim Panel

Note. Put on gloves to protect your hands. Use the appropriate tool from the KTC trim tool set to avoid damage when prying components. Take care not to bend or scratch the trim and panels.

Scheme 69

Scheme 69: Rear Side Trim Panel

Scheme 70

Remove these items: Door sill trim (see «TRIM REMOVAL/INSTALLATION - DOOR AREAS»(ref-290846-S09306060772008072200000) ) Rear seat (see «REAR SEAT DISASSEMBLY/REASSEMBLY»(ref-290866-S30928031672008072200000) ) Hatch weatherstrip, as needed (see «HATCH WEATHERSTRIP REPLACEMENT»(ref-290867-S29418738832008072200000) ) Cargo area floor (see «TRIM REMOVAL/INSTALLATION - CARGO AREA»(ref-290846-S04774016742008072200000) )
Remove the lower anchor bolt (A) and tie down hooks (B).
Remove the rear side trim panel (A). Remove the screws (B, C) and release the clips (D). Remove the seat belt lid (E) from the rear side trim panel. Pull the upper edge of the panel back to release the upper hooks (F) from the quarter pillar trim (G). Detach the clips (H, I) and pull the panel back to remove it. Passenger's side: Disconnect the accessory power socket connector (J).
Install the panel in the reverse order of removal, and note these items: Check if the clips are damaged or stress-whitened, and if necessary, replace them with new ones. When installing the panel, make sure there are no pinches in the seat belt. Push the clips into place securely. Before installing the anchor bolt, make sure there are no twists or kinks in the seat belt. Make sure the each connector is plugged in properly.

C-Pillar Trim/Upper Quarter Window Trim

SRS components are located in this area. Review the SRS COMPONENT LOCATION INDEX and PRECAUTIONS AND PROCEDURES , before performing repairs or service.

Note. Put on gloves to protect your hands. Take care not to bend or scratch the trim and panels. Use the appropriate tool from the KTC trim tool set to avoid damage when prying components.

Scheme 71

Scheme 71: C-Pillar Trim/Upper Quarter Window Trim

Scheme 72

Scheme 73

Scheme 74

Fold the rear seat forward.
Remove the rear seat belt lower anchor bolt (see step 2 on «REAR SEAT BELT REPLACEMENT»(ref-290865-S40671507752008072200000) ).
Remove these items: Door sill trim (see «TRIM REMOVAL/INSTALLATION - DOOR AREAS»(ref-290846-S09306060772008072200000) ) Rear seat Door inner seal, as needed (see step 3 on «FRONT DOOR SILL AREA»(ref-290846-S03427765922008072200000) ) Hatch weatherstrip, as needed (see «HATCH WEATHERSTRIP REPLACEMENT»(ref-290867-S29418738832008072200000) ) Cargo area floor (see «TRIM REMOVAL/INSTALLATION - CARGO AREA»(ref-290846-S04774016742008072200000) ) Rear side trim panel (see «TRIM REMOVAL/INSTALLATION - REAR SIDE AREA»(ref-290846-S31031747122008072200000) )
Remove the C-pillar trim (A). Detach the clips (B, C) by pulling the trim back. Lower the trim to release the upper hooks (D) from the C-Pillar (E)
Detach the clips by pulling the trim back, then remove the upper quarter window trim (A).
Install the trim in the reverse order of removal, and note these items: Check if the clips (A) are damaged or stress-whitened, and if necessary, replace them with new ones. If the side curtain airbag has deployed, replace the C-pillar trim and all clips on the trim with new ones (see «SIDE CURTAIN AIRBAG REPLACEMENT»(ref-355246-S02684509642010012100000) ). To prevent the side curtain airbags from deploying improperly and possibly causing injury, inspect the trim and replace it if it has any of these types of damage: Any cracks or deformations in the upper quarter window trim (B), the C-pillar trim (C) and the upper hooks (D), and any stress-whitened areas in the upper part of the trim Any cracks or stress-whitened areas in the clips seating surfaces (E) Replace any damaged parts with new ones. Make sure the hooks on the C-pillar trim are installed in the side curtain airbag bracket properly. Make sure the trim hook is installed into the side curtain airbag the quarter pillar bracket securely. Push the clips and hooks into place securely. Before installing the anchor bolts, make sure there are no twists or kinks in the seat belt. Upper quarter window trim C-pillar trim
