Special Tools Required
Relay puller 07AAC-000A1A0
SRS components are located in this area. Review the SRS COMPONENT LOCATION INDEX and PRECAUTIONS AND PROCEDURES , before performing repairs or service.
Scheme 1
- Do the battery terminal disconnection procedure (see «DISCONNECTION»(ref-290830-S11729868702009102900000)
- Remove the dashboard lower cover (see «DRIVER'S DASHBOARD LOWER COVER REMOVAL/INSTALLATION»(ref-290806-S07762317602008072200000) ).
- Disconnect the connectors from the fuse side of the under-dash fuse/relay box (A).
- Remove the mounting bolts, and pull the fuse/relay box away from the body.
- Disconnect the connectors from the back side of the under-dash fuse/relay box, then remove the under-dash fuse/relay box. NOTE: The SRS connector is a spring-loaded lock type (see «SPRING-LOADED LOCK CONNECTOR»(ref-355246-S05263143822010012100000) ).
- Carefully remove the relays using relay puller NOTE: Do not use pliers. Pliers will damage the relays, which could cause the engine to stall or not start.
