Special Tools Required
Relay Puller 07AAC-000A1A0
Use this table to identify the type of relay, then do the test listed for it. Carefully remove the relays using the replay puller. Do not use pliers. Pliers will damage the relay.
Scheme 6
Note. See TURN SIGNAL/HAZARD RELAY INPUT TEST ).
| Relay | Test |
|---|---|
| A/C compressor clutch relay | Normally-open type A |
| Air fuel ratio (A/F) sensor relay | |
| A/C condenser fan relay | |
| A/T reverse relay | |
| Daytime running lights relay (3) | |
| Headlight relay (1) | |
| Headlight relay 1 (2) | |
| Headlight relay 2 (2) | |
| Horn relay | |
| Ignition coil relay | |
| PGM-FI main relay 1 (Fl main) | |
| Power window relay | |
| Radiator fan relay | |
| Rear accessory power socket relay | |
| Starter cut relay | |
| Taillight relay | |
| Throttle actuator control module relay | |
| Blower motor relay | Normally-open type B |
| Rear window defogger relay | Normally-open type C |
| PGM-FI main relay 2 (fuel pump) | Five terminal type |
| Low beam cut relay (Canada models) (4) | |
| (1) '07-08 except SC models, and '09 model (2) '07-08 SC model (3) '07-08 Canada models (4) '07-08 Canada except SC models | |
| (1) | '07-08 except SC models, and '09 model |
| (2) | '07-08 SC model |
| (3) | '07-08 Canada models |
| (4) | '07-08 Canada except SC models |
RELAY TABLE
See also:
• TURN SIGNAL/HAZARD RELAY INPUT TEST
