Normally-open type A

Check for continuity between the terminals.

Scheme 7

1. There should be continuity between the No. 1 and No. 2 terminals when battery positive terminal is connected to the No. 4 terminal, and battery negative terminal is connected to the No. 3 terminal.
2. There should be no continuity between the No. 1 and No. 2 terminals when power is disconnected.

Normally-open type B

Check for continuity between the terminals.

Scheme 8

1. There should be continuity between the No. 3 and No. 4 terminals when battery positive terminal is connected to the No. 2 terminal, and battery negative terminal is connected to the No. 1 terminal.
2. There should be no continuity between the No. 3 and No. 4 terminals when power is disconnected.

Normally-open type C

Check for continuity between the terminals.

Scheme 9

1. There should be continuity between the No. 4 and No. 2 terminals when battery positive terminal is connected to the No. 3 terminal, and battery negative terminal is connected to the No. 1 terminal.
2. There should be no continuity between the No. 4 and No. 2 terminals when power is disconnected.

Five-terminal type

Check for continuity between the terminals.

Scheme 10

1. There should be continuity between the No. 1 and No. 2 terminals when battery positive terminal is connected to the No. 5 terminal, and battery negative terminal is connected to the No. 3 terminal.
2. There should be continuity between the No. 1 and No. 4 terminals when power is disconnected.
