Starting System: Removal & Installation Honda CR-V II

Removal

1. Ensure you have the anti-theft codes for the radio and the navigation system, write down the frequencies for the radio's preset buttons.
2. Disconnect the battery negative cable. Disconnect the positive cable.
3. Remove intake manifold. See «INTAKE MANIFOLD»(ref-171634-S07637084232005021000000).
4. Disconnect the knock sensor connector.
5. Disconnect the bolt securing the harness clamp. (Scheme 17)
6. Disconnect the starter cable (A) from the "B" terminal on the solenoid. Disconnect the Black/White wire (B) from the "S" terminal. (Scheme 18)
7. Remove the two bolts holding the starter. Remove the starter.

Scheme 17

Scheme 18

Scheme 19

Installation

1. Install in the reverse order of removal. Ensure the crimped side of the ring terminal is facing out. (Scheme 19)
2. Install intake manifold. See «INTAKE MANIFOLD»(ref-171634-S07637084232005021000000).
3. Connect the battery positive cable and negative cable to the battery.
4. Start the engine to ensure the starter works properly.
5. Enter the anti-theft codes for the radio and the navigation system, enter the customer's radio channel presets.
6. Set the clock.
7. Perform the ECM/PCM idle learn procedure, and power window control unit reset procedure. See appropriate COMPUTER RELEARN article in GENERAL INFORMATION.
