Engine Block (Except Hybrid): Diagnosis Honda Civic VIII рестайлинг

Inspection

Note. Inspect the piston, piston pin, and connecting rod when they are at room temperature.

Scheme 299

Scheme 300

Scheme 301

Scheme 302

1. Measure the diameter of the piston pin. Piston Pin Diameter Standard (New): 19.960-19.964 mm (0.7858-0.7860 in.) Service Limit: 19.960 mm (0.7858 in.)
2. Zero the dial indicator to the piston pin diameter.
3. Check the difference between the piston pin diameter and piston pin hole diameter in the piston. Piston Pin-to-Piston Clearance Standard (New): -0.004 to +0.003 mm (-0.00016 to +0.00012 in.) Service Limit: 0.006 mm (0.0002 in.)
4. Measure the piston pin-to-connecting rod clearance. Piston Pin-to-Connecting Rod Clearance Standard (New): 0.005-0.015 mm (0.0002-0.0006 in.) Service Limit: 0.02 mm (0.0008 in.)

Scheme 303

Scheme 304

Scheme 305

1. Install one piston pin snap ring (A).
2. Coat the piston pin bore, the bore in the connecting rod, and the piston pin with new engine oil.
3. Heat the piston to about 158°F (70°C).
4. Assemble the piston (A) and connecting rod (B) with the mark (C) and the embossed mark (D) on the same side. Install the piston pin (E).
5. Install the remaining snap ring (F).
6. Turn the snap rings until the end gaps are positioned at the bottom of the piston.

Scheme 306

Scheme 307

Scheme 308

Scheme 309

Scheme 310

1. Remove the piston from the engine block (see «CRANKSHAFT AND PISTON REMOVAL»(ref-255533-S31147131582007060300000) ).
2. Using a ring expander (A), remove the old piston rings (B).
3. Clean all ring grooves thoroughly with a squared-off broken ring or ring groove cleaner with a blade to fit the piston grooves. The top and 2nd ring grooves are 1.2 mm (0.05 in.) wide. The oil ring groove is 2.0 mm (0.08 in.) wide. File down a blade if necessary. Do not use a wire brush to clean the ring grooves, or cut the ring grooves deeper with the cleaning tools. NOTE: If the piston is to be separated from the connecting rod, do not install new rings yet.
4. Using a piston that has its rings removed, push a new ring (A) into the cylinder bore 15-20 mm (0.6-0.8 in.) from the bottom.
5. Measure the piston ring end-gap (B) with a feeler gauge: If the gap is too small, check to see if you have the proper rings for your engine. If the gap is too large, recheck the cylinder bore diameter against the wear limits (see «BLOCK AND PISTON INSPECTION»(ref-255533-S01471911352007060300000) ). If the bore is beyond the service limit, the engine block must be rebored. Piston Ring End-Gap Top Ring: Standard (New): 0.20-0.35 mm (0.008-0.014 in.) Service Limit: 0.60 mm (0.024 in.) Second Ring: Standard (New): 0.40-0.55 mm (0.016-0.022 in.) Service Limit: 0.70 mm (0.028 in.) Oil Ring: Standard (New): 0.20-0.70 mm (0.008-0.028 in.)
6. Install the top ring and the second ring as shown. The top ring (A) has a 1T, 1A, or 1R mark, and the second ring (B) has a 2T, 2A, or 2R mark. The manufacturing marks (C) must be facing upward.
7. Rotate the rings in their grooves to make sure they do not bind.
8. Position the ring end gaps as shown
9. After installing a new set of rings, measure the ring-to-groove clearances: Top Ring Clearance Standard (New): 0.045-0.070 mm (0.0018-0.0028 in.) Service Limit: 0.13 mm (0.005 in.) Second Ring Clearance Standard (New): 0.035-0.060 mm (0.0014-0.0024 in.) Service Limit: 0.13 mm (0.005 in.)

Scheme 311

Scheme 312

Scheme 313

1. Set the crankshaft to bottom dead center (BDC) for each cylinder as its piston is installed.
2. Remove the connecting rod caps, then install the ring compressor. Check that the bearing is securely in place.
3. Apply new engine oil to the piston, inside of the ring compressor, and the cylinder bore, then attach the ring compressor to the piston/connecting rod assembly.
4. Position the mark (A) to face the cam chain side of the engine.
5. Position the piston in the cylinder, and tap it in using the wooden handle of a hammer (A). Push down on the ring compressor (B) to prevent the rings from expanding before entering the cylinder bore.
6. Stop after the ring compressor pops free, and check the connecting rod-to-crank journal alignment before pushing the piston into place.
7. Check the connecting rod bearing clearance with plastigage (see «CONNECTING ROD BEARING REPLACEMENT»(ref-255533-S33691523122007060300000) ).
8. Inspect the connecting rod bolts (see «CONNECTING ROD BOLT INSPECTION»(ref-255533-S19003272332007060300000) ).
9. Apply new engine oil to the bolt threads, then install the rod caps with bearings. Torque the bolts to 20 N.m (2.0 kgf.m, 14 lbf.ft).
10. Tighten the connecting rod bolts an additional 90 °. NOTE: Remove the connecting rod bolt if you tightened it beyond the specified angle, and go back to step 8 of the procedure. Do not loosen it back to the specified angle.

Scheme 314

Scheme 315

1. Remove the connecting rod caps, then install the ring compressor, and check that the bearing is securely in place.
2. Apply new engine oil to the piston, inside of the ring compressor, and the cylinder bore, then attach the ring compressor to the piston/connecting rod assembly.
3. Position the mark (A) to face the cam chain side of the engine.
4. Position the piston in the cylinder, and tap it in using the wooden handle of a hammer (A). Push down on the ring compressor (B) to prevent the rings from expanding before entering the cylinder bore.
5. Position all pistons at top dead center (TDC).

Scheme 316

1. Measure the diameter of each connecting rod bolt at point A and point B.
2. Calculate the difference in diameter between point A and point B. Point A-Point B = Difference in Diameter Difference in Diameter
3. If the difference in diameter is out of specification, replace the connecting rod bolt.

Note. Inspect the piston, piston pin, and connecting rod when they are at room temperature.

Scheme 317

Scheme 318

Scheme 319

Scheme 320

1. Measure the diameter of the piston pin. Piston Pin Diameter Standard (New): 21.961-21.965 mm (0.8646-0.8648 in.) Service Limit: 21.953 mm (0.8643 in.)
2. Zero the dial indicator to the piston pin diameter.
3. Check the difference between the piston pin diameter and piston pin hole diameter in the piston. Piston Pin-to-Piston Clearance Standard (New): -0.005 to +0.002 mm (-0.00020 to +0.00008 in.) Service Limit: 0.005 mm (0.0002 in.)
4. Measure the piston pin-to-connecting rod clearance. Piston Pin-to-Connecting Rod Clearance Standard (New): 0.005-0.015 mm (0.0002-0.0006 in.) Service Limit: 0.02 mm (0.0008 in.)

Scheme 321

Scheme 322

Scheme 323

1. Install a piston pin snap ring (A).
2. Coat the piston pin bore in the piston, the bore in the connecting rod, and the piston pin with new engine oil.
3. Heat the piston to about 158°F (70°C).
4. Assemble the piston (A) and connecting rod (B) with the arrow (C) and the embossed mark (D) on the same side. Install the piston pin (E).
5. Install the remaining snap ring (F).
6. Turn the snap rings in the ring grooves until the end gaps are positioned at the bottom of the piston.

Scheme 324

Scheme 325

Scheme 326

Scheme 327

Scheme 328

1. Remove the piston from the engine block (see «CRANKSHAFT AND PISTON REMOVAL»(ref-255533-S24156448642007060300000) ).
2. Using a ring expander (A), remove the old piston rings (B).
3. Clean all ring grooves thoroughly with a squared-off broken ring or ring groove cleaner with a blade to fit the piston grooves. The top and 2nd ring grooves are 1.2 mm (0.05 in.) wide. The oil ring groove is 2.0 mm (0.08 in.) wide. File down a blade if necessary. Do not use a wire brush to clean the ring grooves, or cut the ring grooves deeper with the cleaning tools. NOTE: If the piston is to be separated from the connecting rod, do not install new rings yet.
4. Using a piston that has its rings removed, push a new ring (A) into the cylinder bore 15-20 mm (0.6-0.8 in.) from the bottom.
5. Measure the piston ring end-gap (B) with a feeler gauge: If the gap is too small, check to see if you have the proper rings for your engine. If the gap is too large, recheck the cylinder bore diameter against the wear limits (see «BLOCK AND PISTON INSPECTION»(ref-255533-S01471911352007060300000) ). If the bore is beyond the service limit, the engine block must be rebored. Piston Ring End-Gap Top Ring: Standard (New): 0.20-0.35 mm (0.008-0.014 in.) Service Limit: 0.60 mm (0.024 in.) Second Ring: Standard (New): 0.50-0.65 mm (0.020-0.026 in.) Service Limit: 0.75 mm (0.030 in.) Oil Ring: Standard (New): 0.20-0.70 mm (0.008-0.028 in.)
6. Install the top ring and the second ring as shown. The top ring (A) has a 1R mark and the second ring (B) has a 2R mark. The manufacturing marks (C) must be facing upward.
7. Rotate the rings in their grooves to make sure they do not bind.
8. Position the ring end gaps as shown: About 90°
9. After installing a new set of rings, measure the ring-to-groove clearances. Top Ring Clearance Standard (New): 0.045-0.070 mm (0.0018-0.0028 in.) Service Limit: 0.13 mm (0.005 in.) Second Ring Clearance Standard (New): 0.040-0.065 mm (0.0016-0.0026 in.) Service Limit: 0.13 mm (0.005 in.)

Scheme 329

Scheme 330

Scheme 331

1. Set the crankshaft to bottom dead center (BDC) for each cylinder as its piston is installed.
2. Remove the connecting rod caps, then install the ring compressor. Check that the bearing is securely in place.
3. Apply new engine oil to the piston, inside of the ring compressor, and the cylinder bore, then attach the ring compressor to the piston/connecting rod assembly.
4. Position the mark (A) to face the cam chain side of the engine.
5. Position the piston in the cylinder, and tap it in using the wooden handle of a hammer (A). Push down on the ring compressor (B) to prevent the rings from expanding before entering the cylinder bore.
6. Stop after the ring compressor pops free, and check the connecting rod-to-crank journal alignment before pushing the piston into place.
7. Check the connecting rod bearing clearance with plastigage (see «CONNECTING ROD BEARING REPLACEMENT»(ref-255533-S31004953662007060300000) ).
8. Inspect the connecting rod bolts (see «CONNECTING ROD BOLT INSPECTION»(ref-255533-S27296995032007060300000) ).
9. Install the rod caps with bearings. Torque the bolts to 29 N.m (3.0 kgf.m, 22 lbf.ft).
10. Tighten the connecting rod bolts an additional 90 °. NOTE: Remove the connecting rod bolt if you tightened it beyond the specified angle, and go back to step 8 of the procedure. Do not loosen it back to the specified angle.

Scheme 332

Scheme 333

1. Remove the connecting rod caps, then install the ring compressor, and check that the bearing is securely in place.
2. Apply new engine oil to the piston, inside of the ring compressor, and the cylinder bore, then attach the ring compressor to the piston/connecting rod assembly.
3. Position the mark (A) to face the cam chain side of the engine.
4. Position the piston in the cylinder, and tap it in using the wooden handle of a hammer (A). Push down on the ring compressor (B) to prevent the rings from expanding before entering the cylinder bore.
5. Position all pistons at top dead center (TDC).

Scheme 334

1. Measure the diameter of each connecting rod bolt at point A and point B.
2. Calculate the difference in diameter between point A and point B. Point A-Point B = Difference in Diameter Difference in Diameter
3. If the difference in diameter is out of specification, replace the connecting rod bolt.
