Removal & Installation (Civic)
Remove mirror mount cover. Remove door grip cover and speaker cover. Remove screws behind door grip cover and speaker cover. Release clips holding door panel in place using a trim pad remover or other flat-blade tool. Remove door panel by pulling upward. Disconnect electrical connectors. To install, reverse removal procedures.
Removal & Installation (CR-V)
- Remove inner handle. Remove speaker cover. Remove 3 screws under speaker cover. Remove screws from armrest. Release clips holding door panel in place using a trim pad remover or other flat-blade tool. Remove door panel with as little bending as possible.
Removal & installation (Civic & CR-V)
- Remove door panel. See «DOOR PANEL»(ref-32719-S22354251332001010900000) . Remove plastic cover. Move glass to access bolts. Remove bolts and glass out through window slot. Disconnect window regulator connector. Detach harness clip. Remove regulator through opening in door. Scribe a line across sector gear and regulator. Remove motor from regulator.
- To install, reverse removal procedure. Grease all sliding surfaces of regulator. Ensure there is no clearance between glass and glass run channel when glass is closed. Adjust glass as necessary. See «DOOR GLASS»(ref-32719-S10082106502001010900000) under ADJUSTMENTS.
Removal & Installation (Civic, Odyssey & Oasis)
Pry out cap in pull pocket panel and remove screw. Release hooks at front and sides of switch assembly. Disconnect electrical connectors. To install, reverse removal procedure. Remove left front door panel. Unplug electrical connectors. Remove master switch mounting screws. Remove master switch. To install, reverse removal procedure.
Master power window switch is located in switch panel on left side of dash. Carefully pry switch panel from dash. Disconnect all electrical connectors. Remove master switch panel by pushing switch out from rear to disengage tang at rear of switch. To install, reverse removal procedure. Individual passenger power window switches may be removed from master switch panel in similar manner.
Removal & Installation (Odyssey & Oasis Front Door)
Remove door panel. Unplug electrical connectors. Remove 2 mounting screws. Remove power window switch. To install, reverse removal procedure.
Removal & Installation (Odyssey & Oasis Rear Door)
Remove door panel and inside handle case. Unplug electrical connectors. Remove 2 mounting screws. Remove power window switch from handle case. To install, reverse removal procedure.
