Multiplex Integrated Control System: Removal & Installation Honda Civic IX

Communication Devices 18 illustrations ~408 words

Removal

SRS components are located in this area. Review the SRS component locations See SRS COMPONENT LOCATION INDEX ('12: EXCEPT NATURAL GAS MODELS) or SRS COMPONENT LOCATION INDEX ('12: NATURAL GAS MODELS) and the PRECAUTIONS AND PROCEDURES before doing repairs or service.

Scheme 56

Scheme 56: Removal

Scheme 57

Scheme 57

Scheme 58

Scheme 58

Scheme 59

Scheme 59

Scheme 60

Scheme 60

Scheme 61

Scheme 61

Scheme 62

Scheme 62

Scheme 63

Scheme 63

Scheme 64

Scheme 64
  1. Driver's Dashboard Lower Cover Remove the driver's dashboard lower cover (A).
  2. Dashboard Subdisplay Visor Remove the dashboard subdisplay visor (A).
  3. Front Door Opening Seal as Needed Remove the front door opening seal (A) as needed.
  4. A-Pillar Trim Both Pull out the A-pillar trim (A) to release the clips. Put a shop towel (A) in the opening between the A-pillar trim (B) and the dashboard to prevent dropping the A-pillar clips. Disconnect the connector (A), then remove the A-pillar trim (B). NOTE: The upper clip (C) will stay in the body. Remove the upper clip (A) from the body. Repeat on the opposite side.
  5. Dashboard Meter Visor Remove the dashboard meter visor (A).
  6. Multi-Information Display Unit Remove the multi-information display unit (A). Disconnect the connectors.

Installation

SRS components are located in this area. Review the SRS component locations See SRS COMPONENT LOCATION INDEX ('12: EXCEPT NATURAL GAS MODELS) or SRS COMPONENT LOCATION INDEX ('12: NATURAL GAS MODELS) and the PRECAUTIONS AND PROCEDURES before doing repairs or service.

Scheme 65

Scheme 65: Installation

Scheme 66

Scheme 66

Scheme 67

Scheme 67

Scheme 68

Scheme 68

Scheme 69

Scheme 69

Scheme 70

Scheme 70

Scheme 71

Scheme 71
  1. Multi-Information Display Unit Connect the connectors. Install the multi-information display unit (A).
  2. Dashboard Meter Visor Install the dashboard meter visor (A).
  3. A-Pillar Trim Both Carefully install the new upper clip (A) to the A-pillar trim (B). Connect the connector (A). Fit the clips into the holes in the A-pillar. Lightly push the A-pillar trim (B) into place, then install the trim. NOTE: Make sure the side curtain airbag is not tucked under the clips or the trim ribs. Do not push too hard on the A-pillar trim. If you push too hard, the clip will be damaged, and it will not hold the trim properly. Gently tug on the A-pillar trim to verify that all clips are securely fastened. Repeat on the opposite side.
  4. Front Door Opening Seal as Needed Install the front door opening seal (A).
  5. Dashboard Subdisplay Visor Install the dashboard subdisplay visor (A).
  6. Driver's Dashboard Lower Cover Install the driver's dashboard lower cover (A).

Scheme 72

Scheme 72: Multiplex Integrated Control System Component Location Index

Scheme 73

Scheme 73
AUDIO UNITRemoval and Installation (Without Premium Audio and Switch Panel) Removal and Installation (With Display Audio) Removal and Installation (With Premium Audio) Removal and Installation (With Switch Panel without Premium Audio)
AUDIO-NAVIGATION UNITREMOVAL AND INSTALLATION
CLIMATE CONTROL UNITRemoval and Installation
GAUGE CONTROL MODULE (Tach)Input Test See GAUGE CONTROL MODULE (SPEEDO) INPUT TEST or GAUGE CONTROL MODULE (TACH) INPUT TEST
Removal and Installation See GAUGE CONTROL MODULE (SPEEDO) REMOVAL AND INSTALLATION , GAUGE CONTROL MODULE (TACH) REMOVAL AND INSTALLATION or REWRITING THE ODO DATA AND TRANSFERRING THE MAINTENANCE MINDER™ DATA TO A NEW GAUGE CONTROL MODULE
HFL CONTROL UNITREMOVAL AND INSTALLATION
IMMOBILIZER-KEYLESS CONTROL UNIT (Has built into receiver)INPUT TEST
REGISTRATION
Removal and Installation See IMMOBILIZER-KEYLESS CONTROL UNIT REGISTRATION or IMMOBILIZER-KEYLESS CONTROL UNIT REMOVAL AND INSTALLATION
INFORMATION DISPLAYREMOVAL AND INSTALLATION
MICU (Built into the under-dash fuse/relay box)INPUT TEST
Removal and Installation (KA model with Keyless Access System) Removal and Installation (KA KX models without Keyless Access System) Removal and Installation (KC models without Keyless Access System) Removal and Installation (KC model with Keyless Access System)
Self-Diagnostic Function See MULTIPLEX INTEGRATED CONTROL SYSTEM SELF-DIAGNOSTIC FUNCTION (EXCEPT NATURAL GAS MODELS) or MULTIPLEX INTEGRATED CONTROL SYSTEM SELF-DIAGNOSTIC FUNCTION (NATURAL GAS MODELS)
Sleep and Wake-Up Mode Test ('12-'13: except Natural Gas models) Sleep and Wake-Up Mode Test ('12-'13: Natural Gas models)
MULTI-INFORMATION DISPLAYREMOVAL AND INSTALLATION
